7 PIN 2.54MM PITCH MALE FEMALE REPLICATE CONNECTOR

Send Inquiry

Request To Call Back

7 PIN 2.54MM PITCH MALE FEMALE REPLICATE CONNECTOR

Price 50 INR/ Piece

Get a Price/Quote

MOQ : 1000 Pieces

7 PIN 2.54MM PITCH MALE FEMALE REPLICATE CONNECTOR Specification

Pairs
Single Row

Connector Type
Replicate Connector

Material
Brass/PBT for housing

Male End Type
Pin Header

Connector
7 pin male to 7 pin female

Application
PCB, Prototyping, Signal Transfer, DIY Electronics

Voltage Rating
300V

Female End Type
Receptacle

Temperature
-20C to +85C

Capacity
Low Voltage/Signal

Length
Customizable (standard 15cm)

Insulation
PVC

Sheild
Unshielded

Cable Type
Flat Ribbon Cable / Dupont Type

Color
Black

Wire Gauge
28 AWG

Outer Diameter
Approx. 1.27 mm x 2.54 mm per pin spacing

Number of Conductor
7

Flame Resistance Level
UL94V-0

Jacket Material
PVC

Cable Length
Standard 15cm, customizable

7 PIN 2.54MM PITCH MALE FEMALE REPLICATE CONNECTOR Trade Information

Minimum Order Quantity
1000 Pieces

Supply Ability
Piece

Sample Available
Yes

Sample Policy
Sample costs shipping and taxes has to be paid by the buyer

Main Domestic Market
All India

About 7 PIN 2.54MM PITCH MALE FEMALE REPLICATE CONNECTOR

Pitch	2.5 mm
Brand	IMPORTED
Part Number	JST14
Connector Gender	FEMALE
Contact Material	PLASTIC
Current Rating	STANDARD
Minimum Order Quantity	100 Piece

Applications:
- Used in battery connections, LED lighting, computer hardware, and hobby electronics.
- Suitable for compact and lightweight electronic devices.
Advantages:
- Reliable and secure connections with locking mechanisms to prevent disconnection.
- Compact and space-saving design.
- Easy to assemble and disassemble without special tools.

Flexible Prototyping and Versatile Applications

This 7 pin male to female replicate connector is frequently used in projects requiring quick PCB prototyping, signal transfers, and DIY electronic assemblies. Its cable/wire-to-board, solderless design streamlines installation and rework, while the compact 2.54 mm pitch enables it to fit standard breadboards and PCBs.

Exceptional Electrical Performance and Durability

Engineered with gold flash plating over nickel and crafted from brass/PBT, this connector maintains low contact resistance ( 20 m) and high insulation resistance ( 1000 M at 500V DC). With a robust operating range of -20C to +85C, and a retention force of 0.15kgf per pin, it delivers reliable connectivity even under demanding conditions.

FAQs of 7 PIN 2.54MM PITCH MALE FEMALE REPLICATE CONNECTOR:

Q: How is the 7 PIN 2.54MM Pitch Male Female Replicate Connector installed without soldering?

A: This connector utilizes a solderless, cable/wire-to-board design. Simply align the male and female ends with your circuit board or device and insert them directlyno soldering tools are required, which makes the installation process faster and more convenient for prototyping or frequent modifications.

Q: What applications are best suited for this connector?

A: The connector is ideal for PCB prototyping, signal transfer in electronic devices, DIY projects, and any assembly requiring flexible, low-voltage interconnections. Its single row, flat ribbon cable structure and customizable length also make it suitable for breadboards and development boards.

Q: When should I consider customizing the cable length?

A: Customization is recommended if your project demands a specific cable reach beyond the standard 15cm or for neatly organizing wiring layouts in tight spaces. Reach out to the supplier to discuss custom requirements for optimized integration.

Q: Where can this connector be used with respect to environmental conditions?

A: The connector operates effectively within a temperature range of -20C to +85C and up to 85% relative humidity, making it suitable for most indoor electronics settings but should not be used in extreme moisture or outdoor environments.

Q: What are the benefits of the gold flash over nickel contact plating?

A: Gold flash over nickel provides superior corrosion resistance and ensures consistent, low-resistance electrical connections. This increases the reliability and lifespan of the connector, especially important in signal transfer or low-voltage applications.

Q: How does the connector ensure secure and stable connections?

A: A retention force of 0.15kgf per pin ensures that the mating ends maintain a firm hold, preventing accidental disconnects, while the precise manufacturing tolerance (0.1 mm) guarantees a snug fit.
