9 PIN 2.54 MM PITCH MALE FEMALE JST CONNETCOR

About 9 PIN 2.54 MM PITCH MALE FEMALE JST CONNETCOR

• Applications:
  • Used in battery connections, LED lighting, computer hardware, and hobby electronics.
  • Suitable for compact and lightweight electronic devices.
• Advantages:
  • Reliable and secure connections with locking mechanisms to prevent disconnection.
  • Compact and space-saving design.
  • Easy to assemble and disassemble without special tools.


Reliable Electrical Performance

Engineered with low contact resistance (20 m) and high insulation resistance (1000 M at 500V DC), the JST 2.54mm connector provides secure electrical connectivity for both power and signal applications. Its 3A-per-pin current rating suits it for a range of low-current interconnections across electronics modules.


Ease of Mounting & Integration

Thanks to its single-row, through-hole, or panel-mount options, this connector can be swiftly implemented into printed circuit boards or custom panels. The friction/detent locking mechanism ensures stable connections, making it easy to assemble and maintain even in demanding environments.



FAQs of 9 PIN 2.54 MM PITCH MALE FEMALE JST CONNETCOR:




Q: How do I properly prepare wires for installation into this 9-pin JST 2.54mm connector?

A: For optimal connection, strip the wire insulation to a length between 2.5 and 3 mm as recommended. Use AWG 2824 gauge wires for best compatibility, then insert into the terminal and ensure secure crimping or soldering as per installation guidelines.



Q: What are the typical applications for this connector?

A: This JST-style connector is widely used for PCB connections, signal routing, power lines, and module-to-module interconnections. Its suitable for low-current electrical circuits requiring reliable detachable connections in consumer electronics, industrial control devices, and embedded systems.



Q: What benefits does the friction/detent locking mechanism provide?

A: The friction or detent locking mechanism helps secure the connector pair in place, minimizing accidental disconnection due to vibration or movement. It also enables quick assembly and disassembly while maintaining a solid electrical connection even after multiple mating cycles.



Q: When should I choose an unshielded connector like this for my project?

A: Unshielded connectors such as this are ideal when signal integrity is not heavily impacted by environmental EMI or where cost and space savings are priorities. For low-current and non-critical signal lines, they provide a reliable, compact choice.



Q: What is the maximum voltage and current rating for this connector?

A: The JST 2.54mm 9-pin connector is rated for up to 250V AC/DC and delivers a maximum current of 3A per pin. This makes it appropriate for most signaling and lower-power distribution applications.



Q: How many mating cycles is this connector designed to withstand?

A: This connector is rated for at least 50 mating cycles, ensuring reliable performance in situations requiring periodic disconnection and reconnection, such as maintenance or equipment upgrades.



Q: Where can I customize the cable length or color for my order?

A: Cable length and color customization can be arranged directly with the manufacturer, distributor, or authorized supplier. Specify your requirementssuch as custom lengths (10 cm to 1 m) or special colorto obtain the configuration best suited to your application.
