DB 9 FEMALE CONNECTOR

Price 10 INR/ Piece

Get a Price/Quote

MOQ : 1000 Perches

DB 9 FEMALE CONNECTOR Specification

Temperature
-55C to +105C

Female End Type
DB9 Female Socket

Pairs
Single

Connector
DB9 Female (D-Sub 9 pin)

Connector Type
D-Sub, Solder Type or Crimp Type

Voltage Rating
300V AC/DC max

Capacity
Up to 1A per Pin

Male End Type
Not Applicable (Connector Only)

Application
Serial Communication, Data Transfer, Networking, Industrial Control

Material
Thermoplastic, Metal Shell

Outer Diameter
Approx. 13 mm (including hood)

Flame Resistance Level
Standard (UL 94V-0 for Insulator)

Sheild
Yes, Metal Shielded

Insulation
PVC Insulation

Color
Blue (Main Body)

Wire Gauge
26 AWG (Appropriate for DB9 connectors)

Cable Type
Typically RS232/Serial Cable Compatible

Number of Conductor
9

Length
As Required/Customizable

Jacket Material
PVC

Cable Length
N/A (Connector Only)

Dimensions
Approx. 30 x 12 x 15 mm

Compliance
RoHS Compliant

Termination Style
Solder Cup

Humidity
Up to 95% RH

Insulation Resistance
>= 1000 M @ 500V DC

Shell Material
Steel, Nickel-Plated

Mounting Style
Panel Mount, with Through-Hole Solder Type

Contact Resistance
30 m maximum

Current Rating
5A per Contact Max

Housing Material
Thermoplastic, UL 94V-0 Rated

Pin Plating
Gold Flash over Nickel

DB 9 FEMALE CONNECTOR Trade Information

Minimum Order Quantity
1000 Perches

Sample Available
Yes

Sample Policy
Sample costs shipping and taxes has to be paid by the buyer

Main Domestic Market
All India

About DB 9 FEMALE CONNECTOR

Number Of Pins	9 PINS (AS PER DEMAND)
Color	AS PER ODER
Circuit	YES
Material	METAL
Application	MONITER/CPU ETC.
brand	IMPORTED
Connector Type	DB CONNECTOR
Minimum Order Quantity	100 Piece

Applications:
- Commonly used in computer hardware, such as connecting motherboard components.
- Suitable for wire-to-board and board-to-board connections.
Advantages:
- Reliable electrical connection.
- Easy to use and solder onto printed circuit boards (PCBs).
- Available in various pin counts and configurations to suit different needs.

Reliable Construction for Industrial Applications

Built with a metal shield and high-grade thermoplastic housing, the DB9 Female Connector offers superior EMI/RFI protection and physical resilience for demanding settings. Its insulation resistance of 1000 M ensures minimal current leakage, and the steel shell with a gold flash contact surface elevates both corrosion resistance and conductivity in serial data transfers.

Versatile Mounting and Flexible Integration

Designed with a panel-mount style and through-hole solder type, the connector enables secure installation on devices and control panels. The solder cup termination accommodates 26 AWG wires, which is standard for DB9 connectors, allowing for quick and reliable assembly in custom cable or PCB configurations.

Comprehensive Compliance and Safety Features

Certified to meet RoHS environmental guidelines and built with UL 94V-0 flame-retardant materials, this DB9 connector supports safe operation across a range of environments. Suitable for use in data transfer, serial communication, and networking, it withstands temperatures from -55C up to 105C and up to 95% relative humidity.

FAQ's of DB 9 FEMALE CONNECTOR:

Q: How do I mount and solder the DB9 Female Connector onto my panel?

A: The DB9 Female Connector utilizes a panel mount design with through-hole solder type terminals. For installation, align the connector on your panel's cutout, secure it with mounting screws, and solder the wires to the solder cup terminals following the appropriate pinout for your application.

Q: What applications is this DB9 Female Connector suitable for?

A: This connector is ideal for RS232 serial communication, networking devices, industrial control systems, and custom data transfer projects. Its robust construction and compliance standards make it suitable for environments with high humidity, temperature fluctuations, and the need for reliable, shielded connections.

Q: When should I choose a gold flash over nickel pin plating connector?

A: Gold flash over nickel plating is preferred when you require enhanced corrosion resistance, low contact resistance, and stable data transmission. It also minimizes oxidation, ensuring reliable performance in industrial and networking environments with frequent connections and disconnections.

Q: Where can I use this connector regarding voltage and current ratings?

A: The connector is rated for up to 300V AC/DC and supports a current of up to 5A per contact (with a general capacity of up to 1A per pin under standard usage), making it suitable for most signal and low-power data applications in equipment panels, industrial automation, and communication systems.

Q: What process should I follow to ensure proper termination and insulation?

A: To ensure a secure connection, strip the 26 AWG wire to the appropriate length, insert it into the solder cup, and solder thoroughly. Use PVC insulation sleeves if needed, and verify there's no exposed conductor. The housing's UL 94V-0 rating guarantees flame resistance during operation.

Q: What are the key benefits of using this DB9 Female Connector?

A: Key advantages include high durability due to its metal shield and thermoplastic body, excellent electrical performance (high insulation, low contact resistance), easy panel installation, wide temperature tolerance, and compliance with RoHS and UL 94V-0 standards for safety and environmental responsibility.
