TYPE A 4 PIN STRAIGHT (SMD) 10MM FEMALE USB

Price 1.50 INR/ Piece

Get a Price/Quote

MOQ : 1000 Pieces

TYPE A 4 PIN STRAIGHT (SMD) 10MM FEMALE USB Specification

Connector Type
USB Type A, SMD, Straight

Voltage Rating
30V AC (max)

Connector
USB Type A Female

Female End Type
4 Pin Type A Female Socket

Temperature
-40C to +85C (operating)

Material
Phosphor bronze (contacts), stainless steel (shell)

Application
PCB mounting, USB device interface

Sheild
Yes, with metal shield

Number of Conductor
4-pin

Outer Diameter
Approx. 14.5 mm x 7.0 mm (housing)

Flame Resistance Level
UL94V-0 rated plastic

Length
10 mm (body length)

Color
Silver

Insulation
Plastic and metal construction

TYPE A 4 PIN STRAIGHT (SMD) 10MM FEMALE USB Trade Information

Minimum Order Quantity
1000 Pieces

Main Domestic Market
All India

About TYPE A 4 PIN STRAIGHT (SMD) 10MM FEMALE USB

Brand	NO
Connector Type	Female
USB Type	USB
Current Rating	0.5A
Mounting Type	STANDARD
Piece per box	100
Minimum Order Quantity	100 Piece

Data Transfer: Connecting peripherals such as keyboards, mice, and storage devices to computers.
Charging: Powering and charging devices like smartphones, tablets, and other portable electronics.
Peripheral Connectivity: Connecting devices like printers, cameras, and external hard drives.
Audio/Video Transmission: Connecting devices like monitors and projectors with appropriate adapters.
Power Delivery: Providing power to devices through standards like USB Power Delivery (USB PD).

Enhanced Durability and Reliability

With a minimum of 1500 insertion/removal cycles and a sturdy construction featuring phosphor bronze contacts and a stainless steel shield, this USB connector guarantees long-lasting performance in wear-prone environments. The UL94V-0 flame-resistant plastic housing and RoHS compliance ensure safety and environmental friendliness.

Designed for Secure Mounting

This USB Type A female connector is designed as a surface mount device (SMD), allowing for direct and secure attachment to printed circuit boards (PCBs). Its compact dimensions and silver finish make it suitable for high-density assemblies in modern electronic devices.

Superior Signal Integrity

The gold-flash over nickel plating on contacts ensures excellent conductivity and corrosion resistance, while low contact resistance ( 30 m) and high insulation resistance ( 1000 M at 500V DC) help maintain reliable signal transmission even under challenging conditions.

FAQs of TYPE A 4 PIN STRAIGHT (SMD) 10MM FEMALE USB:

Q: How is the TYPE A 4 PIN STRAIGHT (SMD) 10MM FEMALE USB mounted onto a PCB?

A: This connector is a Surface Mount Device (SMD) and is designed to be soldered directly onto the printed circuit board (PCB) using compatible soldering techniques, ensuring a secure and flat connection.

Q: What types of devices and applications can use this USB connector?

A: It is commonly used in electronic devices requiring a USB interface, such as embedded systems, development boards, consumer electronics, and custom PCB assemblies where a Type A USB connection is essential.

Q: When should I choose a straight SMD USB Type A female connector over a right-angled version?

A: Choose the straight SMD version when your PCB layout or enclosure design requires the USB port to be parallel to the board for efficient use of space and straightforward device connections.

Q: Where does the metal shield provide value in this connector?

A: The integrated metal shield enhances electromagnetic compatibility (EMC) by minimizing interference, and it adds mechanical strength and protection to the connector, especially in high-density circuit environments.

Q: What are the benefits of gold-flash over nickel contact plating in this USB connector?

A: Gold-flash over nickel provides excellent electrical conductivity, improves corrosion resistance, and ensures low contact resistance for stable, high-quality signal transmission over the lifespan of the connector.

Q: How durable is this connector during repeated use?

A: It is rated for a minimum of 1500 mating cycles, meaning it can handle frequent connection and disconnection without significant wear or degradation in performance.

Q: Is this connector safe for use in high-temperature or industrial environments?

A: Yes, it is designed to operate reliably within a wide temperature range of -40C to +85C and features UL94V-0 flame-resistant plastic, making it suitable for demanding or industrial applications.
