TYPE -A4 PIN STRAIGHT 14 MM FEMALE USB

Price 3 INR/ Piece

Get a Price/Quote

MOQ : 1000 Pieces

TYPE -A4 PIN STRAIGHT 14 MM FEMALE USB Specification

Application
Data transfer and charging

Pairs
Single

Voltage Rating
30V

Material
Metal

Capacity
Standard USB

Connector Type
USB Type-A

Connector
USB CONNECTOR

Female End Type
FEMALE SMD

Temperature
-40C to +85C

Wire Gauge
Standard USB gauge

Number of Conductor
4

Insulation
High-grade plastic

Jacket Material
Plastic

Outer Diameter
Standard USB port size

Color
Silver

Sheild
Yes

Length
14 mm

Flame Resistance Level
UL94V-0

TYPE -A4 PIN STRAIGHT 14 MM FEMALE USB Trade Information

Minimum Order Quantity
1000 Pieces

Sample Available
Yes

Sample Policy
Sample costs shipping and taxes has to be paid by the buyer

Main Domestic Market
All India

About TYPE -A4 PIN STRAIGHT 14 MM FEMALE USB

Brand	IMPORTED
Connector Type	Female
USB Type	USB
Current Rating	0.5A
Connector Orientation	AS PER DEMAND
Piece per box	1000
Minimum Order Quantity	100 Piece

Data Transfer: Connecting peripherals such as keyboards, mice, and storage devices to computers.
Charging: Powering and charging devices like smartphones, tablets, and other portable electronics.
Peripheral Connectivity: Connecting devices like printers, cameras, and external hard drives.
Audio/Video Transmission: Connecting devices like monitors and projectors with appropriate adapters.
Power Delivery: Providing power to devices through standards like USB Power Delivery (USB PD).

Exceptional Durability and Performance

With gold-plated contacts and a robust metal shell, the TYPE-A4 PIN STRAIGHT 14 MM FEMALE USB connector guarantees long-term reliability through 1500+ mating cycles. It combines low contact resistance and high insulation values for stable data and power transmission, making it ideal for demanding environments.

Designed for Versatile Mounting and Applications

Supporting straight, DIP, and through-hole mounting, this connector fits seamlessly into a wide range of device designs. Its RoHS compliance, flame resistance, and broad operating temperature range ensure it meets industrial and consumer requirements for both charging and data transfer.

Safe and Compliant Connection Standard

Safety is prioritized with UL94V-0 flame resistance and RoHS compliance, promising both environmental friendliness and protection. The connectors sturdy construction and shielding enhance signal integrity while its standardized dimensions ensure compatibility with existing USB ports.

FAQs of TYPE -A4 PIN STRAIGHT 14 MM FEMALE USB:

Q: How do I mount the TYPE-A4 PIN STRAIGHT 14 MM FEMALE USB connector onto my PCB?

A: This connector is designed for straight, DIP, or through-hole mounting, making it suitable for PCB installation. Simply align the pins with the corresponding holes on your board and solder securely for optimal stability.

Q: What are the main benefits of using gold-plated contacts in this USB connector?

A: Gold-plated contacts provide superior resistance to corrosion, lower contact resistance, and improved electrical conductivity, thus extending the connectors lifespan and ensuring reliable connections for data and power transfer.

Q: Where can the TYPE-A4 PIN STRAIGHT 14 MM FEMALE USB connector be used?

A: This connector is widely used in electronic devices requiring data and power transmission, such as computers, consumer electronics, and industrial instruments, especially in scenarios demanding high durability and environmental compliance.

Q: What is the process for ensuring safe operation within the specified temperature range?

A: The connector features high-grade plastic insulation and a metal shell, allowing it to operate safely from -40C to +85C. Ensure installation is free from excessive mechanical stress and within the recommended electrical ratings for optimal performance.

Q: What makes this USB connector compliant with current safety and environmental standards?

A: It is manufactured in accordance with RoHS standards for hazardous substances and holds a UL94V-0 rating for flame resistance, ensuring both environmental responsibility and operational safety.

Q: How does the connector maintain signal integrity and reduce interference?

A: The built-in metal shield safeguards against electromagnetic interference (EMI), while the standardized 4-pin configuration ensures reliable, clear data and power transmission across devices.
