5x20 mm Glass Tube Fuse Holder Panel

Name: 5x20 mm Glass Tube Fuse Holder Panel
Brand: Madan Link Industries
Price: 7 INR
Availability: InStock

Price 7 INR/ Piece

Get a Price/Quote

MOQ : 1000 Pieces

5x20 mm Glass Tube Fuse Holder Panel Specification

Insulation Material
Thermoplastic

Mounting Type
Panel-mounted

Humidity %
Up to 85% RH

Shape
Cylindrical

Product Type
Fuse Holder

Application
Glass fuse (5x20mm) for electronics, power supplies, industrial controls

Frequency (MHz)
50/60 Hz Hertz (HZ)

Rated Voltage
250V AC/DC Volt (V)

Color
Black

Dimension (L*W*H)
20mm length 10mm diameter Millimeter (mm)

Warranty
2 months

Operating Temperature
-20C to +85C Celsius (oC)

Phase
Single-phase

Material
Thermoplastic

No Of Poles
1 (Single pole)

Connection Type
Screw terminals

Features
- Cylindrical design for compact panel cutouts - Secure fuse retention - Flame-retardant

5x20 mm Glass Tube Fuse Holder Panel Trade Information

Minimum Order Quantity
1000 Pieces

Supply Ability
10000 Pieces Per Month

Delivery Time
2 Week

Sample Available
No

Sample Policy
Sample costs shipping and taxes has to be paid by the buyer

Packaging Details
1000 pieces per bag

Main Domestic Market
All India

About 5x20 mm Glass Tube Fuse Holder Panel

Compatibility: Designed for 5x20 mm glass fuses.
Type: Panel-mount fuse holder.
Color Options: Black
Dimensions: 5x20 mm (standard fuse size).
Application: Electrical/electronic circuits requiring glass fuse protection.
Mounting Type: Panel-mounted installation.

Secure and Flame-Retardant Design

The cylindrical 5x20 mm Glass Tube Fuse Holder is engineered for compact panel cutouts and ensures robust fuse retention. Its use of high-grade thermoplastic material not only provides insulation but also enhances flame-retardant capabilities, ensuring a safer electronic environment in demanding applications.

Versatile Applications Across Industries

This fuse holder is widely suitable for electronics, power supplies, and industrial control panels. Thanks to its compatibility with common 5x20mm glass fuses and standard 50/60 Hz frequency, it meets the needs of manufacturers, exporters, and system integrators across multiple sectors.

FAQs of 5x20 mm Glass Tube Fuse Holder Panel:

Q: How do I install the 5x20 mm Glass Tube Fuse Holder on a panel?

A: The fuse holder is panel-mounted by inserting it into an appropriately sized cylindrical cutout. Secure it using the mounting hardware provided, and connect wiring to the screw terminals for reliable electrical contact.

Q: What benefits does the thermoplastic insulation offer?

A: Thermoplastic insulation provides excellent electrical resistance, durability, and flame-retardant properties. This ensures enhanced safety and long-term performance, even in environments with higher humidity or varying temperatures.

Q: When is it recommended to use this fuse holder?

A: You should use this fuse holder whenever compact fuse installation with secure retention is required, such as in electronic devices, power supplies, or industrial control systems operating at up to 250V AC/DC and within -20C to +85C temperature ranges.

Q: Where is this fuse holder most commonly applied?

A: This fuse holder is most commonly used in electronics, panel assemblies, power distribution modules, and industrial controls, especially where space efficiency and safety are priorities.

Q: What is the process of fuse replacement using this holder?

A: To replace the fuse, disconnect power, unscrew or release the cap, remove the old glass fuse, insert a new 5x20mm fuse of the correct rating, and securely fasten the cap before restoring power.

Q: What are the main usage advantages of the cylindrical design?

A: The cylindrical design allows for space-saving panel cutouts, easy fuse alignment, and improved mechanical retention, reducing the risk of accidental dislodgement during operation.
