à¤¡à¥à¤¸à¥ 2.1 à¤®à¤¿à¤®à¥ à¤¬à¥à¤ 3 à¤ªà¤¿à¤¨

Price 3 आईएनआर/ टुकड़ा

मूल्य/उद्धरण प्राप्त करें

MOQ : 1000 टुकड़ाs

à¤¡à¥à¤¸à¥ 2.1 à¤®à¤¿à¤®à¥ à¤¬à¥à¤ 3 à¤ªà¤¿à¤¨ Specification

मोटाई
Standard

केबल का व्यास
2.1 mm

मुहरबंद

सतह का उपचार

प्रॉडक्ट टाइप

मटेरियल

एप्लीकेशन
Electronics Power Connectors

संपर्क प्रतिरोध
≤30mΩ

इन्सुलेशन प्रतिरोध
100MΩ Min at 500V DC

व्यास
2.1 mm

टर्मिनल सॉकेट
Through Hole, 3 Pins

स्टाइल
Barrel Socket

फिटिंग्स
Panel Mount

रेटेड वोल्टेज
12V DC

वज़न
Approx. 2 g

रंग

à¤¡à¥à¤¸à¥ 2.1 à¤®à¤¿à¤®à¥ à¤¬à¥à¤ 3 à¤ªà¤¿à¤¨ Trade Information

Minimum Order Quantity
1000 टुकड़ाs

नमूना उपलब्ध
Yes

मुख्य घरेलू बाज़ार
ऑल इंडिया

Specification:-

No. of Pin: 3
Rated load: DC 30V / 1.0A
Contact resistance: 0.03
Insulation Resistance (M): 100
Operating Temperature (): -30 ~ +70
Material: Copper, Metal, Plastic

The 5.5 x 2.1mm Female 3-Pin 30V DC Power Jack Socket is a reliable and durable connector designed for PCB panel mounting. It features a standard 5.5mm outer diameter and 2.1mm inner pin, making it compatible with most DC power adapters. This connector is widely used in electronic projects, power supplies, LED lighting systems, audio devices, and other DC-powered equipment. Constructed from high-quality plastic and metal, this power jack ensures high conductivity, minimal power loss, and long-term durability. The 3-pin PCB mount design provides a stable and secure connection, reducing the risk of loose contacts or power fluctuations. It is rated for up to 30V DC, making it suitable for a wide range of applications. The panel mount feature allows for easy installation on enclosures, ensuring a neat and professional appearance in electronic projects. Its secure fit design prevents accidental disconnections, ensuring reliable power delivery at all times. This DC power jack is easy to solder and integrate, making it an excellent choice for DIY enthusiasts, technicians, and engineers.

Features:-
- 3-Pin PCB Mount
- High Conductivity
- Panel Mount Design
- Durable Construction
- Stable Power Input

Efficient Power Connectivity

The DC 2.1 MM Back 3 Pins connector delivers consistent power transfer for electronics, thanks to its high-grade copper alloy contacts and nickel plating. Designed for straightforward installation on both PCB and chassis, it ensures secure and efficient connections for a wide range of electronic projects and devices.

Long-Lasting & Reliable Design

Engineered for durability, this connector supports over 5,000 insertion cycles and withstands temperatures from -20C to +70C. Its UL94V-0 flammability rating and RoHS compliance enhance safety and environmental friendliness, making it a dependable choice for manufacturers and hobbyists alike.

FAQs of DC 2.1 MM BACK 3 PINS:

Q: How can the DC 2.1 MM Back 3 Pins connector be mounted?

A: This connector is designed for both PCB and chassis mounting, and it features panel mount fittings for secure and flexible installation options in various electronic devices.

Q: What makes this connector suitable for electronics power applications?

A: With its 12V DC rated voltage, 1A maximum current, insulation resistance of 100M min at 500V DC, and durable nickel-plated copper alloy contacts, it ensures reliable and efficient power delivery for a range of electronic devices.

Q: When should I choose this connector over other barrel sockets?

A: Opt for this connector when you need a compact, robust, and RoHS compliant solution capable of at least 5,000 insertion cycles, especially if safety (UL94V-0 rating) and compatibility with standard 2.1 mm cables are priorities.

Q: Where is this connector commonly used?

A: It is widely used in electronic gadgets, power supply units, consumer electronics, and any projects requiring secure and dependable DC power connections.

Q: What is the typical installation process for this connector?

A: Install the connector onto the PCB or chassis using through-hole terminals and panel mount fittings, then solder the pins according to the circuit requirements for a solid connection.

Q: How does the product benefit manufacturers and distributors?

A: Its RoHS compliance, robust design, and long lifespan make it a reliable, safe, and eco-friendly choice for manufacturers, exporters, and distributors in the electronics industry.
