AC POWER SOCKET SCREW WITH FUSE AND SWITCH

Price 28 INR/ Piece

Get a Price/Quote

MOQ : 1000 Pieces

AC POWER SOCKET SCREW WITH FUSE AND SWITCH Specification

Cable Diameter
6-9 mm

Thickness
Standard 1.2mm flange

Surface Treatment
Matte Finish

Sealed
NO

Product Type
AC Power Inlet Socket with Fuse and Switch

Material
PVC

Application
Suitable for power supply connections

Contact Resistance
<30m

Insulation Resistance
>100 M at 500V DC

Diameter
22mm mounting hole for switch

Terminal Socket
3 Pin (IEC 320 C14)

Style
Rectangular, Inline Switch

Fittings
Panel Mount, Screw Type

Rated Voltage
16A Ampere (A)

Weight
Approx. 30g

Color
Black

AC POWER SOCKET SCREW WITH FUSE AND SWITCH Trade Information

Minimum Order Quantity
1000 Pieces

Sample Available
Yes

Sample Policy
Sample costs shipping and taxes has to be paid by the buyer

Main Domestic Market
All India

About AC POWER SOCKET SCREW WITH FUSE AND SWITCH

Pin Type

3 Pin Socket

Material	PVC
Socket With Shutter	No
Warranty	NO
Color	BLACK
Current Rating	16A
Size	STANDARD
Minimum Order Quantity	1000 Piece

Durability:High durability with secure and stable connection
Compatibility:Suitable for various AC-powered devices like household appliances, office equipment, and industrial machines
Insulation Resistance:High insulation resistance to prevent short circuits

Secure Power Connections with Integrated Protection

This power socket offers a combination of protection and convenience, thanks to its integrated fuse holder and rocker switch. Designed for panel mounting, it ensures a reliable connection and quick access to fuse replacement. With a flammability rating of UL 94V-0 and insulation resistance above 100 M, safety is prioritized for demanding electrical environments.

Robust & Compliant Industrial Design

Manufactured from durable PVC and meeting IEC and RoHS requirements, this socket is built to last. The mounting method ensures firm installation, while the matte black finish offers a professional look. With a wide temperature range and secure screw fastening, its suitable for use in a diversity of power supply setups.

FAQs of AC POWER SOCKET SCREW WITH FUSE AND SWITCH:

Q: How do I install the AC Power Socket Screw with Fuse and Switch in my device?

A: To install, align the socket with your panels mounting hole (50mm x 28mm required) and secure it using screws. Connect the terminals according to the wiring diagram, ensuring the IEC C14 inlet matches your cord set. The switch and fuse holder are built-in for straightforward wiring and operation.

Q: What type and size of fuse does this power socket support?

A: This socket is compatible with 5x20mm glass tube fuses, easily accessible through the integrated fuse holder. The fuse acts as a protective measure against overcurrent, safeguarding your equipment.

Q: When should I use this socket in my electrical setup?

A: Use this socket for applications requiring reliable power input, protection, and manual switchingsuch as power supplies, control panels, or industrial equipmentwhere panel mounting and IEC C14 connections are standard.

Q: Where can this power socket be used?

A: Its suitable for industrial, commercial, or laboratory environments within the operating temperature range of -25C to +85C. Ensure the application matches its 16A/250V rating and supports IEC C14 devices.

Q: What are the benefits of the integrated fuse and ON/OFF rocker switch?

A: The built-in fuse protects your equipment from electrical faults, while the ON/OFF rocker switch allows for safe, convenient control of the connected device. These features simplify installation and enhance safety.
