12 MM MRS 7 PIN connector

Price 20 INR/ Piece

Get a Price/Quote

MOQ : 999 Pieces

12 MM MRS 7 PIN connector Specification

Capacity
Up to 7 signal channels

Pairs
7 single conductors

Application
Industrial automation, sensor connectivity

Voltage Rating
300V

Female End Type
Socket

Material
Brass (pins), Plastic (body)

Temperature
-25C to +80C

Male End Type
Plug

Connector Type
Circular

Connector
MRS 7 Pin

Length
Available in custom lengths

Wire Gauge
24 AWG

Color
Black (Jacket), Multiple (Wires)

Flame Resistance Level
UL94V-0

Number of Conductor
7

Insulation
PVC

Cable Type
Multi-core, shielded

Jacket Material
PVC

Outer Diameter
12 mm

Sheild
Yes, Metal shielding

Cable Length
Custom, up to 30 meters

12 MM MRS 7 PIN connector Trade Information

Minimum Order Quantity
999 Pieces

Sample Available
Yes

Main Domestic Market
All India

About 12 MM MRS 7 PIN connector

No. of Pins	4
Material	Copper
Telecom/Data/Network	YES
Electrical Fitting	YES
Year	AS PER USE
Minimum Order Quantity	100 Piece

It is a GX-16 4-Pin Metal Aviation Plug Male and Female Panel Connector. The connector is mostly used to transmit signals or power. This type of connector is used in places where a watertight connection is required, and also in harsh environments. Professional GX16-4 Pin air plug socket.Made of solid material, more durable. One set includes one male and one female Connector.
The connector is ideal for panel mounting and has got separate male and female pins. The cable can be soldered directly on them

Reliable Performance for Industrial Environments

Engineered for demanding industrial environments, the 12 MM MRS 7 PIN connector combines high current capacity, excellent shielding, and strong ingress protection. Its robust construction ensures stable operation, even in harsh conditions, while the threaded coupling mechanism provides a secure connection. Operating safely between -25C and +80C, it offers consistent performance year-round.

Flexible Installation Options

With both panel and field cable mounting compatibility, this connector offers flexibility for new installations or retrofits. Its customizable cable lengths (up to 30 meters) and support for 7 individual signal channels make it ideal for complex machine wiring or sensor networks. The simple yet reliable threaded coupling allows for quick assembly and dismantling.

FAQs of 12 MM MRS 7 PIN connector:

Q: How is the 12 MM MRS 7 PIN connector typically installed?

A: This connector supports both panel mount and field cable mount installation. The threaded coupling system allows for secure attachment, while the customizable cable length makes installation possible in various layouts and distances.

Q: What advantages does the IP67 ingress protection offer in industrial applications?

A: IP67 certification ensures the connector is dust-tight and protected against temporary immersion in water. This makes it ideal for environments exposed to moisture, dust, or splashes, maintaining reliable connections in demanding conditions.

Q: When should I use the 12 MM MRS 7 PIN connector in my setup?

A: Use this connector when you need to transmit up to 7 signal channels with robust shielding and high current capacity (5A per pin), especially in industrial automation, sensor connectivity, or harsh environments requiring IP67 protection.

Q: Where can custom cable lengths be ordered for the 12 MM MRS 7 PIN connector?

A: Custom cable lengths at up to 30 meters can be ordered directly from authorized distributors, exporters, importers, manufacturers, or traders in India, depending on your specific project requirements.

Q: What is the benefit of nickel or gold contact plating for this connector?

A: Nickel or gold plating on contacts enhances corrosion resistance and ensures reliable, low-resistance connections, even after many mating cycles. This results in long-term performance and reduced maintenance in industrial settings.

Q: How does the metal shielding improve signal quality?

A: The metal shielding minimizes electromagnetic interference, protecting transmitted signals from external noise. This is especially important for applications involving sensitive data or control signals in multi-core, shielded cables.

Q: What safety and compliance standards does the connector meet?

A: The connector complies with RoHS and CE directives and meets flame resistance level UL94V-0, ensuring it is safe and environmentally responsible for industrial use.
