12X12X11 MM 4 PIN BLACK TACTILE SWITCH

Price 2 INR/ Piece

Get a Price/Quote

MOQ : 1000 Pieces

12X12X11 MM 4 PIN BLACK TACTILE SWITCH Specification

Number of Module
1

Automation Grade
Manual

Temperature Range
-25C to +70C

Circuit Type
SPST-NO (Single Pole Single Throw - Normally Open)

Response Time
<10 ms

Mechanical Life
>= 100,000 cycles

Finish Type
Matte

Protection Level
IP40

Max. Current
50mA

Rated Voltage
DC 12V

Product Type
Tactile Switch

Material
Plastic and Metal

Insulation Resistance
>= 100 M at 500V DC

Contact Resistance
100 m

Max. Voltage
DC 12V

Operating Temperature
-25C to +70C

Stoke
0.25 0.1 mm

Size
12 x 12 x 11 mm

Color
Black

Weight
Approx. 1g

Mounting Type
Through Hole

Current Rating
50mA @ 12V DC

No Of Poles
Single Pole

12X12X11 MM 4 PIN BLACK TACTILE SWITCH Trade Information

Minimum Order Quantity
1000 Pieces

Sample Available
Yes

Main Domestic Market
All India

About 12X12X11 MM 4 PIN BLACK TACTILE SWITCH

Ace your design projects with this potent 12X12X11 MM 4 PIN BLACK TACTILE SWITCH. Featuring a round actuator button and soaring reliability, this switch is your Last Chance for a hot deal in automation, control panels, and consumer electronics. Boasting a robust 160gf actuation force, silver-plated contacts, and RoHS compliance, it stands strong even in the toughest environments. Its compact Markdown and IP40 protection deliver precise operation, while mechanical life exceeds 100,000 cycles. Secure this high-performance switch before stock flies off the shelf!

Feature-Rich Tactile Switch for Advanced Applications

The 12X12X11 MM 4 PIN BLACK TACTILE SWITCH excels with a 0.25 mm travel, durable silver-plated contacts, and IP40 protection level. Commercially, its ideal for instrumentation, consumer electronics, control panels, and keypads. Enhanced by a fast <10 ms response time and matte finish, it ensures reliable operation. Extra features include high insulation resistance, RoHS compliance, and straight lead mountingmaking it an ace component for assembly lines and automation systems.

Expansive Markets & Streamlined Order Processing

Serving both the Main Domestic Market and prominent Export Markets like India and beyond, this switch benefits from a Quick Dispatch promise and efficient Order Processing. Our Sample Policy is designed for distributors, exporters, and tradersproposals are processed promptly, and small sample quantities are available upon confirmation of proposal amount. Trust this tactile switch for reliability whether youre outfitting local machinery or international electronic systems.

FAQs of 12X12X11 MM 4 PIN BLACK TACTILE SWITCH:

Q: How do I mount the 12X12X11 MM 4 PIN BLACK TACTILE SWITCH?

A: This tactile switch features a through-hole mounting type, making it straightforward to install on PCBs using standard soldering methods.

Q: What commercial applications is this switch best suited for?

A: It is ideal for consumer electronics, control panels, instrumentation, and keypads due to its reliable actuation and long mechanical life.

Q: When should I use a 160gf actuation force switch?

A: Choose this 160gf switch when you need enhanced tactile feedback and minimal risk of accidental activation in your electronic design.

Q: Where can I export or order this component?

A: We supply the switch throughout India and to various international markets. For exports, contact us directly with your requirements.

Q: What is the benefit of the switchs IP40 protection level?

A: IP40 protection ensures resistance to solid objects larger than 1 mm, making the switch suitable for general indoor environments without excessive dust or moisture.
