6X6X5 MM 4 PIN RED TACTILE SWITCH

Name: 6X6X5 MM 4 PIN RED TACTILE SWITCH
Brand: Madan Link Industries
Price: 2 INR
Availability: InStock

Price 2 INR/ Piece

Get a Price/Quote

MOQ : 1000 Pieces

6X6X5 MM 4 PIN RED TACTILE SWITCH Specification

Temperature Range
-20+70 Celsius (oC)

Product Type
tectile switch

Insulation Resistance
100M Min. at 100VDC

Contact Resistance
: MAX 100 m Megaohm (M)

Operating Temperature
: -20+70 Celsius (oC)

Mounting Type
Through Hole

6X6X5 MM 4 PIN RED TACTILE SWITCH Trade Information

Minimum Order Quantity
1000 Pieces

Sample Available
Yes

Main Domestic Market
All India

About 6X6X5 MM 4 PIN RED TACTILE SWITCH

Description

Practical Temperature--25~85
Withstand Voltage-AC250V(50Hz/60Hz)/min
Actuating Force-2.5+/-0.5N
Contact Resistance-=<50m ohm
Life-100000Times
Insulation Resistance->=100M ohm
Humidity range-85% RH.MAX
Electrical specifications-DC524V 150mA
Appearance-No scratches, soil, rust or discoloration shall be observed

Robust Design for Diverse Environments

This 4-pin red tactile switch is engineered to withstand wide temperature fluctuations from -20C up to +70C. Its solid insulation resistance and secure through-hole mounting make it dependable for varied climates and operating conditions, making it a top choice for applications needing longevity and stability.

Quick and Easy Installation

Designed for through-hole assembly, this tactile switch can be smoothly integrated into most printed circuit boards. Its standardized 6x6x5 mm dimensions and 4-pin structure streamline the soldering process, ensuring efficient mass production or repairs for engineers and manufacturers.

Broad Market Reach in India

Available through multiple channels such as distributors, exporters, importers, manufacturers, and traders nationwide, this switch is accessible to businesses across India. Its wide distribution network ensures timely supply and convenient procurement for your next electronic project.

FAQs of 6X6X5 MM 4 PIN RED TACTILE SWITCH:

Q: How do I mount the 6X6X5 mm 4-Pin Red Tactile Switch to my PCB?

A: This tactile switch uses a through-hole mounting type, meaning its pins are inserted into pre-drilled holes on the PCB and then soldered in place, providing strong mechanical and electrical connections.

Q: What is the typical insulation resistance of this tactile switch?

A: The switch offers a minimum insulation resistance of 100 megaohms at 100VDC, ensuring effective isolation between contacts for safe operation in electronic circuits.

Q: When should I choose this tactile switch for my project?

A: Opt for this switch if you require a compact, reliable, and robust solution suitable for temperature ranges between -20C and +70C, such as in industrial controls or consumer electronics.

Q: Where can I source the 6X6X5 mm 4-Pin Red Tactile Switch in India?

A: You can acquire this product from various distributors, exporters, importers, manufacturers, and traders across India, making it easily accessible for both small-scale and bulk requirements.

Q: What process should I follow to ensure correct installation?

A: Begin by aligning the switchs pins with the PCB holes, insert the pins fully, and solder each one securely to guarantee stable contact and long-lasting performance.

Q: What are the advantages of using this red tactile switch?

A: Its low contact resistance, high insulation resistance, and wide operating temperature range ensure reliability, safety, and durability, making it well-suited for demanding applications.

Q: How can this tactile switch benefit my electronic application?

A: By providing consistent tactile feedback and reliable switching in a compact form, this switch enhances user interface functionality while maintaining electrical integrity, benefitting assemblies where space and reliability are critical.
