2 M Preset 205 - Top Performance at Affordable Price

जांच भेजें

Request To Call Back

Price 1.92 आईएनआर/ टुकड़ा

मूल्य/उद्धरण प्राप्त करें

MOQ : 100 टुकड़ाs

Specification

प्रॉडक्ट टाइप
Trimmer Potentiometer (Preset)

मटेरियल
Cermet/Plastic

हैंडल
Single Slot Adjuster

वोल्टेज का सामना करें
600V AC for 1 minute

एप्लीकेशन
Electronic circuits, calibration, and adjustment purposes

इन्सुलेशन प्रतिरोध
1000 MΩ Min. at 500V DC

ऊंचाई
7 mm

वज़न
Approx. 0.5 g

रंग
Blue

Power Rating
0.25W at 70°C

Model
205

Resistance Value
2 MΩ (2,000,000 Ohms)

Adjustment Type
Top adjustment

Tolerance
±20%

Operating Temperature Range
-25°C to +85°C

Temperature Coefficient
±250 ppm/°C

Mounting Type
Through Hole

Rotational Life
200 cycles minimum

Trade Information

Minimum Order Quantity
100 टुकड़ाs

भुगतान की शर्तें
,

नमूना उपलब्ध
Yes

नमूना नीति

मुख्य घरेलू बाज़ार

About

Resistance Values	4.7 K
Usage/Application	Electronic Appliances
Brand	NO
Resistance Range	3K
Material	PLASTIC
Color	WHITE / BLUE
Part Number	PT04
Minimum Order Quantity	100

Applications: Used in electronic circuits for calibration, tuning, and adjustment
Usage: Ideal for setting reference voltages, adjusting signal levels, and other precision applications
Durability: Long lifespan with reliable performance over time
Compatibility: Suitable for use in a variety of electronic devices and projects
Packaging: Available in single units or bulk packaging for larger projects

Precise Circuit Calibration

The 2 M OHM PRESET 205 is specifically crafted for accurate circuit calibration and adjustment tasks. Its high resistance value and stable tolerance enable effortless fine-tuning of electronic parameters in a variety of devices, ensuring optimal performance and reliability for your projects.

Durable Design and Versatile Use

Made from a combination of cermet and plastic materials, this preset offers robust durability while remaining lightweight at only 0.5 grams. Its through-hole mounting and top adjustment design make it convenient for integration into most standard PCB configurations, serving a range of commercial and industrial applications.

FAQ's of 2 M OHM PRESET 205:

Q: How do I adjust the resistance value of the 2 M OHM PRESET 205?

A: You can adjust the resistance value using the top-access single slot adjuster. A screwdriver is typically used to turn the slot, enabling fine-tuning within the component's 20% tolerance range.

Q: What benefits does the cermet/plastic construction offer for this preset?

A: The cermet/plastic material combination provides enhanced durability and stability, resulting in consistent performance over its 200-cycle minimum rotational life and resistance to environmental changes during operation.

Q: Where can the 2 M OHM PRESET 205 be used in electronic circuits?

A: It is commonly used in calibration and adjustment applications within amplifiers, oscillators, sensor circuits, and other precision electronic devices requiring accurate resistance tuning.

Q: What is the process for mounting this preset onto a PCB?

A: The 2 M OHM PRESET 205 features a through-hole mounting design. Insert its leads into the corresponding holes on your PCB and solder them in place for secure and reliable connections.

Q: When should I consider using a preset with a tolerance of 20%?

A: A 20% tolerance is suitable for applications where extremely precise resistance values are not critical, but where adjustment flexibility and ease of calibration are essential.

Q: What safety features does this preset offer?

A: The preset has a high insulation resistance (1000 M min. at 500V DC) and can withstand voltages up to 600V AC for one minute, ensuring safe operation within electrical systems.

Q: What support is available for distributors and traders in India regarding this component?

A: As the product is sourced by manufacturers, traders, exporters, and distributors within India, reliable domestic supply chains and technical assistance are generally available to support your business needs.
