2 M OHM PRESET 205

Price 1.92 INR/ Piece

Get a Price/Quote

MOQ : 100 Pieces

2 M OHM PRESET 205 Specification

Product Type
Trimmer Potentiometer (Preset)

Material
Cermet/Plastic

Handles
Single Slot Adjuster

Withstand Voltage
600V AC for 1 minute

Application
Electronic circuits, calibration, and adjustment purposes

Insulation Resistance
1000 M Min. at 500V DC

Height
7 mm

Weight
Approx. 0.5 g

Color
Blue

Mounting Type
Through Hole

Operating Temperature Range
-25C to +85C

Rotational Life
200 cycles minimum

Tolerance
20%

Model
205

Power Rating
0.25W at 70C

Resistance Value
2 M (2,000,000 Ohms)

Adjustment Type
Top adjustment

Temperature Coefficient
250 ppm/C

2 M OHM PRESET 205 Trade Information

Minimum Order Quantity
100 Pieces

Payment Terms
Paypal, Cash in Advance (CID)

Sample Available
Yes

Sample Policy
Sample costs shipping and taxes has to be paid by the buyer

Main Domestic Market
All India

About 2 M OHM PRESET 205

Resistance Values	4.7 K
Usage/Application	Electronic Appliances
Brand	NO
Resistance Range	3K
Material	PLASTIC
Color	WHITE / BLUE
Part Number	PT04
Minimum Order Quantity	100

Applications: Used in electronic circuits for calibration, tuning, and adjustment
Usage: Ideal for setting reference voltages, adjusting signal levels, and other precision applications
Durability: Long lifespan with reliable performance over time
Compatibility: Suitable for use in a variety of electronic devices and projects
Packaging: Available in single units or bulk packaging for larger projects

Precise Circuit Calibration

The 2 M OHM PRESET 205 is specifically crafted for accurate circuit calibration and adjustment tasks. Its high resistance value and stable tolerance enable effortless fine-tuning of electronic parameters in a variety of devices, ensuring optimal performance and reliability for your projects.

Durable Design and Versatile Use

Made from a combination of cermet and plastic materials, this preset offers robust durability while remaining lightweight at only 0.5 grams. Its through-hole mounting and top adjustment design make it convenient for integration into most standard PCB configurations, serving a range of commercial and industrial applications.

FAQ's of 2 M OHM PRESET 205:

Q: How do I adjust the resistance value of the 2 M OHM PRESET 205?

A: You can adjust the resistance value using the top-access single slot adjuster. A screwdriver is typically used to turn the slot, enabling fine-tuning within the component's 20% tolerance range.

Q: What benefits does the cermet/plastic construction offer for this preset?

A: The cermet/plastic material combination provides enhanced durability and stability, resulting in consistent performance over its 200-cycle minimum rotational life and resistance to environmental changes during operation.

Q: Where can the 2 M OHM PRESET 205 be used in electronic circuits?

A: It is commonly used in calibration and adjustment applications within amplifiers, oscillators, sensor circuits, and other precision electronic devices requiring accurate resistance tuning.

Q: What is the process for mounting this preset onto a PCB?

A: The 2 M OHM PRESET 205 features a through-hole mounting design. Insert its leads into the corresponding holes on your PCB and solder them in place for secure and reliable connections.

Q: When should I consider using a preset with a tolerance of 20%?

A: A 20% tolerance is suitable for applications where extremely precise resistance values are not critical, but where adjustment flexibility and ease of calibration are essential.

Q: What safety features does this preset offer?

A: The preset has a high insulation resistance (1000 M min. at 500V DC) and can withstand voltages up to 600V AC for one minute, ensuring safe operation within electrical systems.

Q: What support is available for distributors and traders in India regarding this component?

A: As the product is sourced by manufacturers, traders, exporters, and distributors within India, reliable domestic supply chains and technical assistance are generally available to support your business needs.
