5.8X5.8MM 6 PIN WITH LOCK VTR SWITCH, ON/OFF

Send Inquiry

Request To Call Back

5.8X5.8MM 6 PIN WITH LOCK VTR SWITCH, ON/OFF

Price 4 INR/ Piece

Get a Price/Quote

MOQ : 1000 Pieces

5.8X5.8MM 6 PIN WITH LOCK VTR SWITCH, ON/OFF Specification

Rated Voltage
125V AC

Protection Level
IP40

Response Time
10ms

Mechanical Life
10,000 Cycles

Circuit Type
SPST

Temperature Range
-10C to +60C

Number of Module
1

Max. Current
2A

Finish Type
Matte

Automation Grade
Manual

Product Type
VTR Switch with Lock

Material
High-Grade Plastic and Metal Alloy Contacts

Insulation Resistance
100M at 500VDC

Contact Resistance
50m

Max. Voltage
250V AC

Operating Temperature
-10C to +60C

Stoke
2.00.2mm

Size
5.8 x 5.8mm

Color
Black

Weight
Approx. 2g

Mounting Type
Through Hole

Current Rating
2A at 125V AC

No Of Poles
Single Pole

Switch Function
ON/OFF Latching with Lock

Pin Configuration
6 Pins

Dielectric Strength
AC 1000V (50/60Hz for 1 min)

Panel Cutout
Standard 5.8x5.8mm

Actuator Type
Square Button, Lockable

Contact Material
Silver Alloy

Soldering Temperature
Max. 260C for 3 seconds

Application
VTR, AV Devices, Industrial Equipment, Control Panels

Storage Temperature
-25C to +75C

5.8X5.8MM 6 PIN WITH LOCK VTR SWITCH, ON/OFF Trade Information

Minimum Order Quantity
1000 Pieces

Sample Available
Yes

Main Domestic Market
All India

About 5.8X5.8MM 6 PIN WITH LOCK VTR SWITCH, ON/OFF

Switch Function	ON/OFF
ROHS Compliant	No
Switch Type	push button,Material/Body
Switch Throw Type	SPDT
Minimum Order Quantity	1000

Applications: Ideal for industrial machinery, security systems, automotive applications, and sensitive electronic equipment.Customization: Available in various key configurations, sizes, and mounting options to meet specific security needs.Durability: Constructed with high-quality materials to withstand harsh environments and frequent use.

x5.8mm 6-pin VTR switch with lock is a type of push button switch that features a self-locking mechanism, allowing it to stay in the "on" or "off" position until pressed again. Here are some key details about this switch:

Key Features:

- Switch Type: Push Button Switch with self-locking mechanism

- Pin Count: 6 pins

- Switch Size: 5.8x5.8mm

- Action Type: Self-locking

- Contact Resistance: 0.03 max

- Insulation Resistance: 100M min

- Rating: 0.1A 30VDC

- Dielectric Strength: 1500V AC for 1 minute

- Operating Temperature: -25C to +70C

- Electrical Life: 10,000 cycles

Specifications:

- Material: Plastic and metal

- Button Type: High head or flat head

- Pin Spacing: Long: 4.6mm, Short: 2mm

- Pin Size: 4 x 0.5mm

Durability and Performance

Built with high-grade plastic and metal alloy contacts, the VTR switch offers a mechanical life exceeding 10,000 cycles and ensures stable operation across a temperature range of -10C to +60C. The contact resistance remains under 50m, offering efficient current transfer and minimized power loss in demanding environments.

Flexible Applications

Suited for VTR, AV devices, industrial machinery, and control panels, this lockable ON/OFF switchs compact 5.8x5.8mm size and standard panel cutout facilitate flexible design integration. Its through-hole mounting simplifies assembly and maintenance across various control and automation setups.

FAQs of 5.8X5.8MM 6 PIN WITH LOCK VTR SWITCH, ON/OFF:

Q: How is the 5.8x5.8mm 6-pin VTR switch typically used in control and AV equipment?

A: This switch offers lockable ON/OFF control in VTR, AV devices, and industrial panels, acting as a reliable single-pole switch to safely connect or isolate electrical circuits.

Q: What mounting process is recommended for installing this switch on a panel?

A: The switch is designed for through hole mounting and fits a standard 5.8x5.8mm panel cutout. Simple solderingat up to 260C for three secondssecures the 6 pins, ensuring firm adhesion to circuit boards or panels.

Q: When should the VTR switchs lock function be used?

A: The locking feature is ideal when accidental operation must be prevented, adding an extra layer of security to ON/OFF functions in sensitive or critical systems.

Q: What benefits do silver alloy contacts provide in this switch?

A: Silver alloy contacts minimize contact resistance (50m), promoting efficient current flow and enhancing switch longevity even in frequent switching applications.

Q: Where is this switch suited for operation and storage?

A: It operates reliably from -10C to +60C, with a broader storage range of -25C to +75C, making it suitable for environments typical to control panels and electronic equipment rooms.

Q: How does the switch ensure safety during operation?

A: The switch maintains a dielectric strength of AC 1000V for one minute and insulation resistance of 100M at 500VDC, ensuring robust safety against electrical surges and leakage.
