5 WAY DIP SWITCH

Price 9 INR/ Piece

Get a Price/Quote

MOQ : 1000 Pieces

5 WAY DIP SWITCH Specification

Power Rating
250VA

Insulation Resistance
10⁶ M min.

Max. Voltage
250 Volt (V)

Size
14.5mm x 8.0mm x 5.0mm (Typical)

Mounting Type
PCB (Printed Circuit Board)

5 WAY DIP SWITCH Trade Information

Minimum Order Quantity
1000 Pieces

Sample Available
Yes

Sample Policy
Sample costs shipping and taxes has to be paid by the buyer

Main Domestic Market
All India

About 5 WAY DIP SWITCH

Number of Positions	2
Current Rating	5A
ROHS Compliance	No
Mounting Type	DIP
Switch Type	DIP
Minimum Order Quantity	25 Piece

DIP switch, short for Dual In-line Package switch, offers a compact and versatile solution for configuring electronic circuits.
This 5 Way DIP SPST Switch is the simplest type of switch in which a single toggle either connects or disconnects a single terminal from other

Designed for Versatile Applications

This 5 WAY DIP SWITCH is ideal for customization in electronic circuits, allowing users to set device configurations easily. Designed for seamless integration onto printed circuit boards, its compact footprint makes it suitable for space-constrained modules used in automation, communication equipment, and consumer electronics.

Reliable Performance and High Standards

With a maximum voltage rating of 250V and an insulation resistance of at least 1,000,000 M, this DIP switch supports consistent, durable operation even under demanding conditions. It meets stringent quality benchmarks, making it a preferred choice for industrial users and electronics manufacturers all over India.

FAQs of 5 WAY DIP SWITCH:

Q: How is the 5 WAY DIP SWITCH typically installed on a circuit board?

A: The 5 WAY DIP SWITCH is designed for PCB mounting. Installation involves soldering the switch terminals directly onto a printed circuit board, ensuring a secure and stable connection for reliable operation.

Q: What are the main benefits of using a 5 WAY DIP SWITCH in electronic circuits?

A: The primary advantage of this DIP switch is its ability to offer multiple configuration selections in a compact format. Users can quickly change circuit settings without modifying the board design, enhancing versatility and simplifying troubleshooting or customization.

Q: When should I use a DIP switch instead of other types of switches?

A: A DIP switch is most suitable when frequent, manual configuration changes are expected, especially during setup, testing, or maintenance phases. They provide easy access and high reliability, making them preferable in control panels and embedded systems.

Q: Where are 5 WAY DIP SWITCHES commonly used?

A: These switches are widely used in industrial control equipment, automation systems, communication devices, and consumer electronics to select operational modes or set parameters directly on the hardware.

Q: What is the maximum electrical rating for this DIP switch model?

A: This 5 WAY DIP SWITCH supports a maximum voltage of 250V and a power rating up to 250VA, making it suitable for a broad range of standard electronic and industrial applications.

Q: How does the insulation resistance benefit device longevity and safety?

A: With insulation resistance of at least 10 M, this DIP switch minimizes leakage currents, reducing the risk of short circuits and prolonging the lifespan of electronic assemblies while maintaining high safety standards.

Q: What is the process for exporting or importing this DIP switch in India?

A: Distributors and traders typically follow standard electronic component export and import regulations in India, including compliance with customs and quality assurance checks, to ensure reliable product delivery nationwide and internationally.
