DC 2.1 MM METAL BODY 3 PIN

Price 2 INR/ Piece

Get a Price/Quote

MOQ : 1000 Pieces

DC 2.1 MM METAL BODY 3 PIN Specification

Sealed
Non-Sealed

Cable Diameter
2.1 mm (Inner Pin)

Thickness
Metal body thickness approx. 1 mm

Surface Treatment
Nickel Plated

Product Type
DC Power Socket

Material
Nickel-Plated Brass

Application
Electronics, LED Lighting, CCTV

Contact Resistance
30 m

Insulation Resistance
100 M at 500V DC

Diameter
2.1 mm (Inner Pin), 5.5 mm (Outer Barrel)

Terminal Socket
3 Pin

Style
Round Barrel

Fittings
Panel Mount

Rated Voltage
DC 12V to 24V

Weight
5 g (approx)

Color
Silver

DC 2.1 MM METAL BODY 3 PIN Trade Information

Minimum Order Quantity
1000 Pieces

Sample Available
Yes

Sample Policy
Sample costs shipping and taxes has to be paid by the buyer

Main Domestic Market
All India

About DC 2.1 MM METAL BODY 3 PIN

Current Rating	5 A
Voltage rating	24 V
Mounting	Panel
Gender Type	Female jack
Brand	IMPORTED
Minimum Order Quantity	1000 Piece

DC socket is a special power supply and computer display matching socket, it is composed of transverse socket, longitudinal socket, insulating base, fork contact shrapnel, directional keyway, two fork contact shrapnel positioning in the center of the base, into a vertical and horizontal arrangement is not connected to each other. One end of the fork-type contact spring is a wiring port, which is exposed on the top surface of the base cylinder for connecting the input power cord or cable. The other end of the fork-type contact spring is composed of two elastic arms of the matrix interconnection. It is arranged in the insulation base jack of the DC plug insertion direction, and it is used for the computer monitor to make it work normally.

Reliable and Versatile Panel Mount Design

Designed for robust applications, this connector is easily mounted onto panels using the provided nut. Its strong nickel-plated brass body and compact size make installation straightforward, even in limited spaces. The 3-pin solder lug arrangement supports versatile circuit configurations, offering reliable performance across a range of electronics projects.

Wide Operating Range and Applications

With an operating temperature from -20C to +70C and a current rating up to 2A, this connector is suited for demanding environments. It is commonly used in DIY assemblies, industrial equipment, commercial electronics, LED lighting set-ups, and CCTV systems, ensuring seamless power connections for a wide spectrum of devices.

FAQs of DC 2.1 MM METAL BODY 3 PIN:

Q: How do I mount the DC 2.1 MM Metal Body 3 Pin connector to a panel?

A: To mount the connector, insert it through the designated panel hole (6.35 mm diameter), then secure it using the included nut. Solder your wires to the lug terminals, ensuring a firm and stable connection.

Q: What is the benefit of using a nickel-plated brass body in this connector?

A: A nickel-plated brass construction enhances durability, offers corrosion resistance, and ensures superior conductivity, making it ideal for enduring various electrical and environmental conditions.

Q: When should I use a panel mount DC connector instead of an inline type?

A: Panel mount connectors are recommended when you want a fixed, reliable power socket for devices such as control panels, enclosures, or stationary equipment, offering a cleaner and more secure interface compared to inline connectors.

Q: Where can this 3-pin connector be applied effectively?

A: This connector is widely used in electronics projects, LED lighting systems, industrial control units, and CCTV installations, providing secure DC power input connections wherever panel-mounting is advantageous.

Q: What process should I follow for proper wiring and installation?

A: After mounting the connector, strip and tin the wires, then solder each wire securely to the appropriate solder lug. Double-check the pinout and ensure there are no shorts before final assembly and powering up.

Q: Is this connector compliant with safety and environmental standards?

A: Yes, the connector is RoHS compliant, meaning it is manufactured without hazardous substances, making it suitable for modern, eco-conscious electronic designs.

Q: What advantages does the 2.1 mm inner pin and 3-pin configuration provide?

A: The 2.1 mm inner pin is a widely recognized standard for DC power connections, and the 3-pin design offers flexibility for additional grounding or control options, supporting more intricate circuit requirements.
