1.27MM DUAL ROW MALE RIGHT ANGLE PIN HEADER

Send Inquiry

Request To Call Back

1.27MM DUAL ROW MALE RIGHT ANGLE PIN HEADER

Price 10 INR/ Piece

Get a Price/Quote

MOQ : 1000 Pieces

1.27MM DUAL ROW MALE RIGHT ANGLE PIN HEADER Specification

Application
PCB Connections, Board-to-Board, Board-to-Wire

Connector Type
Dual Row Right Angle Male Pin Header

Male End Type
Right Angle Male

Temperature
-40C to +105C

Voltage Rating
250V AC/DC

Connector
Pin Header

Material
Phosphor Bronze (pins), PBT or Nylon (housing)

Insulation
High-temperature thermoplastic UL94V-0

Length
Customizable/As per request

Flame Resistance Level
UL94V-0

Color
Black (insulator), Gold/Nickel (pins)

Pitch
1.27 mm

Insulator Color
Black

Contact Resistance
20 m Max

Mounting Type
Through Hole

Current Rating
1.0A per contact

Durability
500 cycles Min

Contact Plating
Gold Flash or Tin over Nickel

Operating Humidity
95% RH

RoHS Compliant
Yes

Number of Pins
Customizable (commonly 8 to 80 pins per header)

Insulation Resistance
1000 M Min at 500V DC

Number of Rows
Dual (2 Rows)

1.27MM DUAL ROW MALE RIGHT ANGLE PIN HEADER Trade Information

Minimum Order Quantity
1000 Pieces

Sample Available
Yes

Sample Policy
Sample costs shipping and taxes has to be paid by the buyer

Main Domestic Market
All India

About 1.27MM DUAL ROW MALE RIGHT ANGLE PIN HEADER

Size	2 mm
Number Of Pins	AS PER DEMAND
Color	BLACK
Circuit	YES
Material	PLASTIC
Application	BREG CONNECTOR
brand	IMPORTED
Connector Type	BERG
Minimum Order Quantity	100 Piece

Computer Motherboards: Used for connecting components like hard drives, optical drives, and other peripherals.
Consumer Electronics: Found in devices such as televisions, audio equipment, and gaming consoles.
Automotive: Used in vehicle electronics for various control systems and modules.
Industrial Equipment: Employed in control panels, sensors, and other industrial automation equipment.

Optimized for High-Density PCB Designs

With a compact 1.27mm pitch and dual-row layout, this pin header supports high-density connections on printed circuit boards. Its right angle design facilitates easy integration in applications where space is limited, enhancing layout flexibility and allowing for complex routing in modern electronic devices.

Customizable Pin Count and Length Options

Adapt the pin header to your unique requirements with customizable pin numbers (8 to 80) and tailored lengths. Options for gold flash or tin over nickel plating ensure optimal performance under different usage environments, making it suitable for a variety of industrial, consumer, or automotive applications.

Durable, Reliable, and Safe to Use

Engineered with phosphor bronze pins and housed in high-temperature thermoplastic (UL94V-0 rated), this header offers excellent contact durability (500 cycles minimum) and high insulation resistance (1000 M min at 500V DC). It is RoHS compliant, ensuring safety and eco-friendliness in electronic assemblies.

FAQ's of 1.27MM DUAL ROW MALE RIGHT ANGLE PIN HEADER:

Q: How is the 1.27MM Dual Row Male Right Angle Pin Header typically used?

A: This pin header is commonly used for board-to-board and board-to-wire connections in electronic devices. Its right angle male configuration makes it ideal for connecting components at a 90-degree angle to the PCB, optimizing space and layout.

Q: What customization options are available for the pin header's size and pin count?

A: You can request headers with a customizable number of pins, typically ranging from 8 to 80 per header. The length of the pins and the overall dimensions can also be tailored to meet specific application needs.

Q: Where can this connector be reliably operated?

A: The connector is designed to perform in environments with temperatures between -40C and +105C and up to 95% relative humidity. Its robust construction and material choices make it suitable for industrial, automotive, and consumer electronics across various sectors.

Q: What are the benefits of gold flash or tin over nickel contact plating?

A: Gold flash plating offers superior corrosion resistance and enhanced conductivity, ideal for sensitive or high-reliability circuits. Tin over nickel is more cost-effective and provides adequate protection for standard use-cases, ensuring longevity of connections.

Q: How durable is this right angle pin header under repeated use?

A: Thanks to its construction with high-quality phosphor bronze pins and PBT or Nylon housing, the header supports at least 500 mating cycles, making it robust for regular connections or prototyping applications.

Q: What process should be followed for mounting this pin header?

A: This pin header is designed for through-hole mounting, where pins are inserted into PCB holes and soldered for a secure mechanical and electrical connection. This ensures stability and reliability, particularly in environments subject to vibration or frequent handling.

Q: Why is UL94V-0 flame resistance important for this connector?

A: A UL94V-0 rating guarantees that the high-temperature thermoplastic housing will self-extinguish within 10 seconds after being exposed to flame, minimizing the risk of fire propagation in electronic assemblies for enhanced safety.
