DC FEMALE CONNECTOR WITH WIRE

Price 4 INR/ Piece

Get a Price/Quote

MOQ : 1000 Pieces

DC FEMALE CONNECTOR WITH WIRE Specification

Product Type
DC Female Connector with Wire

Material
ABS plastic body with copper alloy contacts

Withstand Voltage
500V DC

Application
Widely used for power supply connections in electronics projects, CCTV cameras, LED lighting strips, and DIY circuits.

Insulation Resistance
100 M at 500V DC

Height
Approx. 15 mm

Weight
Approx. 12 grams

Color
Black

RoHS Compliance
Yes

Wire Length
15 cm

Connector Size
5.5 mm (outer diameter) x 2.1 mm (inner diameter)

Flame Retardant
Yes, UL94V-0 standard

Rated Current
2A Max

End Type
Wire Lead (tinned ends)

Mounting Type
Inline, soldered wire

Operating Temperature
-20C to +60C

Rated Voltage
12V DC

Contact Resistance
0.03

Polarity
Centre Positive

Cable Specification
2-core, 0.3mm2 (AWG 22)

DC FEMALE CONNECTOR WITH WIRE Trade Information

Minimum Order Quantity
1000 Pieces

Sample Available
Yes

Sample Policy
Sample costs shipping and taxes has to be paid by the buyer

Main Domestic Market
All India

About DC FEMALE CONNECTOR WITH WIRE

Current Rating	5 A
Black and Red	BLACK
Red & Black	BLACK
Country of Origin	Made in India
Minimum Order Quantity	1000 Piece

INTRODUCING OUR DC FEMALE CONNECTOR WITH WIRE .

Ensure reliable connections by soldering or crimping the wires securely to the connector terminals, minimizing the risk of loose connections or intermittent power supply.

Superior Connector Design

The 5.5 mm (outer) x 2.1 mm (inner) DC female connector provides reliable compatibility for a wide range of standard DC power sources. Its twin-core 0.3mm cable and soldered wire lead ensure enhanced electrical contact and long-lasting performance in demanding environments.

Safety and Compliance

This connector features flame-retardant ABS housing compliant with UL94V-0 and meets RoHS standards, making it a safe choice for professional and DIY projects. It offers excellent insulation resistance (100 M at 500V DC) and contact resistance (0.03 ), guaranteeing stable and secure connections.

Versatile Usage Across Industries

Widely utilized in electronics projects, CCTV installations, LED lighting strips, and custom circuitry, this inline connector supports global applications in manufacturing, distribution, exporting, and trading. Its centre positive designation and tinned wire ends facilitate easy connections for power supply solutions.

FAQs of DC FEMALE CONNECTOR WITH WIRE:

Q: How do I correctly connect the DC Female Connector with Wire to my power supply?

A: To connect, match the centre positive polarity of the connector to your power supply pinout. The tinned wire leads are ready for soldering or can be attached to screw terminals for a secure connection. Ensure the supply does not exceed 12V DC and 2A.

Q: What types of projects or devices commonly use this connector?

A: This DC female connector is widely employed in electronics projects, especially for powering CCTV cameras, LED lighting strips, and DIY circuits, due to its standardized size and robust electrical specifications.

Q: When is this connector the ideal choice for my application?

A: Opt for this connector when you need reliable 12V DC power connections in environments between -20C and +60C, and require flame-retardant, RoHS compliant components. Its suitable for inline connections with secure soldered wire ends.

Q: Where should I install the DC female connector for optimal safety and performance?

A: Install the connector in a ventilated area within the recommended temperature range. Avoid exposure to excessive moisture or corrosive substances to maintain insulation and contact integrity.

Q: What is the process for mounting and wiring this connector?

A: Mount this inline female connector by using its soldered wire leads. Strip the cables tinned ends as necessary and join to your circuitry via soldering or compatible terminals, ensuring proper alignment of positive and negative conductors.

Q: What are the benefits of choosing this flame-retardant, RoHS compliant connector?

A: Selecting this connector provides enhanced fire safety (UL94V-0), regulatory compliance (RoHS), and electrical reliability with high insulation resistance and low contact resistance, making it suitable for professional or DIY installations.

Q: How does the use of ABS plastic and copper alloy contacts enhance the connectors durability?

A: ABS plastic ensures a robust, flame-retardant enclosure, while copper alloy contacts offer excellent conductivity and corrosion resistance, resulting in prolonged service life and dependable power transmission.
