DC 1.1 003 SOCKET

Price 1 INR/ Piece

Get a Price/Quote

MOQ : 1000 Pieces

DC 1.1 003 SOCKET Specification

Cable Diameter
2.1mm - 2.5mm accepted

Thickness
Standard (approx. 7mm)

Sealed
Not sealed

Surface Treatment
Nickel plated contacts

Product Type
DC Socket

Material
ABS Body, Nickel Plated Contacts

Application
Audio/Video, Adapter & Power supply

Contact Resistance
<= 50m

Insulation Resistance
>= 100M at 500V DC

Diameter
Outer: 8.0mm, Center Pin: 2.1mm

Terminal Socket
Solder Lug

Style
Straight Socket

Fittings
Panel Mount

Rated Voltage
30V DC

Weight
Approx. 2.5g

Color
Black

DC 1.1 003 SOCKET Trade Information

Minimum Order Quantity
1000 Pieces

Sample Available
Yes

Sample Policy
Free samples available with shipping and taxes paid by the buyer

Main Domestic Market
All India

About DC 1.1 003 SOCKET

Current Rating	0.5A
Brand	NO
Part Number	DC11
Material	PLASTIC
Application	FOR DC JACK
Color	BLACK
Minimum Order Quantity	100 Piece

Current Rating:Varies, commonly up to 5A or more depending on the model
Connector Size:Available in various sizes, commonly 2.1mm, 2.5mm, and 5.5mm inner diameter
Mounting Type:Panel mount, PCB mount, or cable mount options

Durable Construction and Safety

Built with a black ABS body and nickel-plated copper alloy contacts, the DC 1.1 003 Socket excels in durability and safety. Its UL94V-0 flammability rating and RoHS compliance meet international safety and environmental standards. The socket can endure harsh conditions, remaining reliable in operating temperatures from -20C to +70C, and is well suited for both commercial and industrial uses.

Versatile Application Fit

This socket supports panel mount fittings and is engineered for audio/video devices, adapters, and power supplies. Its straight socket style and compact 8mm outer diameter make it adaptable for a wide range of electronic devices. Accepting cables from 2.1mm to 2.5mm diameter, it ensures compatibility across different assemblies, offering flexibility for manufacturers and end users alike.

FAQs of DC 1.1 003 SOCKET:

Q: How do I mount the DC 1.1 003 Socket to a panel?

A: To mount the socket, simply create a 7.5mm diameter hole in your panel, insert the socket through the hole, and secure it in place. The panel mount fitting ensures a stable installation, ideal for permanent, robust power connections.

Q: What type of plug is compatible with this socket?

A: The DC 1.1 003 Socket is compatible with plugs having a 2.1mm inner diameter and 5.5mm outer diameter, making it suitable for many standard power adapters used in audio, video, and electronics.

Q: When is it beneficial to use this product in my design?

A: Choose this socket when you require a reliable, long-lasting DC power connection for panel-mounted equipment, especially when dealing with devices needing up to 1A and 30V DC, with moderate insulation and contact resistance for frequent connections.

Q: Where should this socket be used for optimal performance?

A: Use it in controlled environments within the operating temperature range of -20C to +70C. It is ideal for embedded applications in power supply units, audio/video devices, and adapters where panel mounting is needed.

Q: What is the process for soldering wires to this socket?

A: Prepare your wires for soldering, then attach them to the sockets solder lug terminals by heating and applying solder to create a solid, reliable electrical connection. This method ensures low contact resistance and lasting performance.

Q: How does the product ensure safety and durability?

A: The socket features a flame-retardant ABS body (UL94V-0 rated), RoHS compliance for environmental safety, and nickel-plated copper alloy contacts for corrosion resistance, supporting over 5,000 electrical cycles.

Q: What are the main benefits of using this DC socket?

A: Its benefits include easy panel mounting, secure solder type terminals, high insulation resistance, and compatibility with standard power plugs, all contributing to a reliable, long-life connection for electronic applications.
