12X12X10 MM 4 PIN BLACK TACTILE SWITCH

Name: 12X12X10 MM 4 PIN BLACK TACTILE SWITCH
Brand: Madan Link Industries
Price: 2 INR
Availability: InStock

Price 2 INR/ Piece

Get a Price/Quote

MOQ : 1000 Pieces

12X12X10 MM 4 PIN BLACK TACTILE SWITCH Specification

Finish Type
Matte

Response Time
<5 ms

Max. Current
50 mA

Circuit Type
SPST

Protection Level
IP40

Mechanical Life
100,000 cycles

Automation Grade
Manual

Temperature Range
-25C to +70C

Number of Module
1

Rated Voltage
12V DC

Product Type
Tactile Switch

Material
Plastic (Housing), Metal (Contacts)

Insulation Resistance
100 M min at 500V DC

Contact Resistance
50 m max

Max. Voltage
12V DC

Operating Temperature
-25C to +70C

Stoke
1.5 mm

Size
12X12X10 MM

Color
Black

Weight
Approx. 2 g

Mounting Type
Through Hole

Current Rating
50 mA

No Of Poles
Single Pole

Pin Number
4

Switch Travel
1.5 mm

Flammability Rating
UL94V-2

Contact Type
Momentary

Operating Force
160-260 gf

Actuator Height
10 mm

RoHS Compliance
Yes

Lead Pitch
5.08 mm

Button Shape
Square

Storage Temperature
-30C to +80C

Dielectric Strength
250V AC for 1 minute

12X12X10 MM 4 PIN BLACK TACTILE SWITCH Trade Information

Minimum Order Quantity
1000 Pieces

Sample Available
Yes

Main Domestic Market
All India

About 12X12X10 MM 4 PIN BLACK TACTILE SWITCH

Hot deal alert! Our new release 12X12X10 MM 4 PIN BLACK TACTILE SWITCH is a blue-ribbon choice for electronics professionals. This matchless, valuable momentary switch features a 4-pin square design with a 10 mm actuator height and stable 1.5 mm travel. Engineered with UL94V-2 flammability rating and IP40 protection, it delivers reliability in demanding environments. RoHS compliant, it boasts low contact resistance, high insulation, and a robust mechanical life of 100,000 cycles. Ideal for manufacturers, distributors, and developers seeking a trusted, efficient solution for their electronic devices. Dont miss out on this exceptional offersuitable for automation and manual activation, this switch meets rigorous international standards and is ready to elevate your product design.

Experience Versatility with the 12X12X10 MM 4 PIN BLACK TACTILE SWITCH

The 12X12X10 MM 4 PIN BLACK TACTILE SWITCH is perfect for both specific automation projects and general electronic applications. Its unique square button and reliable momentary contact make it suitable for keypads, control panels, and consumer devices. Featuring a matte finish, quick response time, and broad operating temperature range, it delivers precise control and seamless operation in various environments, adding significant value to any machinery or device where reliable manual input is required.

Samples, Packaging, and Export Markets: Streamlined for You

Estimate your next project with confidencesamples of the 12X12X10 MM 4 PIN BLACK TACTILE SWITCH are available upon request. Our logistics are tailored for secure, efficient delivery with thoughtfully designed packaging to reduce outlay from damage or loss. This switch is actively exported to global markets including Asia, Africa, and the Middle East, supported by a reliable supply chain and responsive service for manufacturers, distributors, and traders across regions.

FAQs of 12X12X10 MM 4 PIN BLACK TACTILE SWITCH:

Q: How can the 12X12X10 MM 4 PIN BLACK TACTILE SWITCH be integrated into automation projects?

A: The switch is designed with momentary contact and a 4-pin layout, making it easy to install in automation circuits, control panels, and custom devices through standard through-hole mounting.

Q: What are the primary benefits of using this tactile switch in electronic assemblies?

A: This switch offers quick response time, durable mechanical life of 100,000 cycles, consistent actuation, and RoHS compliance, providing reliable performance for both specific and general electronic uses.

Q: When should I consider choosing this model for my device design?

A: Select this model when you require a compact switch with solid click feedback, moderate operating force, and high voltage insulation for applications ranging from consumer electronics to industrial controls.

Q: Where is the 12X12X10 MM 4 PIN BLACK TACTILE SWITCH primarily exported?

A: The switch is exported to diverse markets including Asia, Middle East, and Africa, reaching various manufacturers, importers, and traders globally.

Q: What is the process to request samples or place bulk orders?

A: Simply contact your distributor, exporter, or manufacturer directly with your request. Samples can be dispatched promptly to estimate suitability, and logistics for bulk orders are arranged to ensure timely delivery.

Q: How does the operating temperature range benefit device performance?

A: With a temperature range of -25C to +70C, the switch maintains reliable operation in challenging, varying environments, making it suitable for numerous industrial and consumer applications.
