10 PIN 2.54 MM PITCH MALE FEMALE JST CONNECTOR

Send Inquiry

Request To Call Back

10 PIN 2.54 MM PITCH MALE FEMALE JST CONNECTOR

Price 15 INR/ Piece

Get a Price/Quote

MOQ : 1000 Pieces

10 PIN 2.54 MM PITCH MALE FEMALE JST CONNECTOR Specification

Material
Nylon (Connector Housing), Tin-plated Phosphor Bronze (Contacts)

Pairs
Single Row

Female End Type
JST-XH Female Housing 10 Pin

Capacity
Up to 3A per pin

Connector Type
Male-Female

Temperature
-25°C to +85°C

Voltage Rating
250V AC/DC

Connector
JST-XH (2.54 mm pitch)

Application
PCB Connection, Prototyping, Battery Connections

Male End Type
JST-XH Male Header 10 Pin

Sheild
No

Cable Type
Discrete Wire to Board

Outer Diameter
1.1 mm per wire

Length
150 mm (typical)

Number of Conductor
10

Jacket Material
PVC

Insulation
PVC

Flame Resistance Level
UL 94V-0

Color
Black (Housing), Multi-color Wires

Wire Gauge
26 AWG

Cable Length
150 mm

Wire Type
Tinned copper

Pitch
2.54 mm

Contact Resistance
10m

Gender
Male Plug to Female Socket

RoHS Compliance
Yes

Locking Mechanism
Friction lock

Suitable PCB Thickness
1.6 mm

Current Rating
3A max per contact

Mounting Type
Through Hole (for Male Header)

Insulation Resistance
1000M at 500V DC

Mating Cycles
50 cycles typical

10 PIN 2.54 MM PITCH MALE FEMALE JST CONNECTOR Trade Information

Minimum Order Quantity
1000 Pieces

Sample Available
Yes

Sample Policy
Sample costs shipping and taxes has to be paid by the buyer

Main Domestic Market
All India

About 10 PIN 2.54 MM PITCH MALE FEMALE JST CONNECTOR

Pitch	2.5 mm
Brand	IMPORTED
Part Number	JST20
Connector Gender	MALE/FEMALE
Contact Material	PLASTIC
Current Rating	STANDARD
Minimum Order Quantity	1000 Piece

Applications:
- Used in battery connections, LED lighting, computer hardware, and hobby electronics.
- Suitable for compact and lightweight electronic devices.
Advantages:
- Reliable and secure connections with locking mechanisms to prevent disconnection.
- Compact and space-saving design.
- Easy to assemble and disassemble without special tools.

Versatile PCB Connectivity

Superior Electrical Performance

FAQs of 10 PIN 2.54 MM PITCH MALE FEMALE JST CONNECTOR:

Q: How do I install the 10 PIN 2.54 MM PITCH MALE FEMALE JST CONNECTOR on a PCB?

A: To install, solder the male JST-XH header onto the PCB with 1.6 mm thickness using through-hole pads. Then, plug the corresponding female end onto the male header, securing the connection with the built-in friction lock.

Q: What applications is this JST connector suitable for?

A: It is ideal for PCB connections, prototyping, battery interfaces, and other wire-to-board requirements in consumer electronics, robotics, and industrial controls.

Q: When should I use a JST-XH 2.54 mm pitch connector over other types?

A: Choose this connector for compact, reliable connections where a 2.54 mm pitch suits your board design and when current per pin requirements do not exceed 3A.

Q: Where can this connector be sourced from in India?

A: As a widely distributed product, it is available through major electronics distributors, exporters, importers, manufacturers, and traders across India.

Q: What is the connection and locking process?

A: The connection is made by inserting the female plug into the male header, where a friction-lock mechanism holds them together firmly, ensuring stable contact during use.

Q: How does this connector benefit electronic projects?

A: It streamlines cabling and module replacements, offers secure mating, supports high current, and provides clear pin identification through multi-color wires, thereby improving assembly reliability and ease of maintenance.
