8 PIN 2.54MM PITCH MALE FEMALE REPLICATE CONNECTOR

About 8 PIN 2.54MM PITCH MALE FEMALE REPLICATE CONNECTOR

• Applications:
  • Used in battery connections, LED lighting, computer hardware, and hobby electronics.
  • Suitable for compact and lightweight electronic devices.
• Advantages:
  • Reliable and secure connections with locking mechanisms to prevent disconnection.
  • Compact and space-saving design.
  • Easy to assemble and disassemble without special tools.


Versatile Connectivity for Precision Applications

Engineered for dependable signal transmission, this connector is well-suited for PCB interconnections, development platforms, and rapid prototyping. It accommodates flat ribbon or discrete wire configurations and fits panel or through-hole mounting requirements, satisfying diverse project needs in research, manufacturing, and electronics design.


Robust Construction and Safety Standards

Built with high-quality plastic for the housing and copper for the pins, the connector provides mechanical durability alongside excellent electrical performance. The press-fit friction lock enhances stability, while PVC insulation meets UL 94V-0 flame resistance, ensuring safe operation under various temperatures and voltage conditions.



FAQs of 8 PIN 2.54MM PITCH MALE FEMALE REPLICATE CONNECTOR:




Q: How do I mount the 8 PIN 2.54MM PITCH MALE FEMALE REPLICATE CONNECTOR to a PCB?

A: You can install this connector using panel or through-hole mounting methods. Its standard 2.54mm pitch aligns with most PCB layouts, allowing easy soldering or press-fit assembly for both male and female versions.



Q: What applications are best suited for this connector?

A: This connector is ideal for board-to-board connections, development boards, prototyping, and low voltage data transmission in electronic devices. It is frequently used in PCB assembly, signal routing, and modular system interfacing.



Q: When should I consider using a replicate (male to female) 8 pin connector?

A: Use this connector when you need a reliable, secure interconnection between two circuit boards or modules, especially during prototyping, development, or when frequent mating/demating is required, as it offers up to 500 cycles of durability.



Q: Where can I source this connector with custom cable lengths?

A: As a standard or custom offering, distributors, exporters, importers, manufacturers, and traders across India provide this connector, with cable lengths tailored to specific requirements as per order specifications.



Q: What benefits does the friction lock mechanism provide?

A: The press-fit, friction lock design ensures a secure and stable connection, minimizing accidental disconnections and guaranteeing consistent electrical contact throughout its lifespan.



Q: How does the connector ensure safe operation in varying environments?

A: With a temperature range of -20C to 85C, a flame resistance level of UL 94V-0, and insulation resistance of at least 1000 M at 500V DC, the connector delivers reliable and safe performance even in demanding electronic environments.
