12X12X17 MM 4 PIN BLACK TACTILE SWITCH

Name: 12X12X17 MM 4 PIN BLACK TACTILE SWITCH
Brand: Madan Link Industries
Price: 1 INR
Availability: InStock

Price 1 INR/ Piece

Get a Price/Quote

MOQ : 1000 Pieces

12X12X17 MM 4 PIN BLACK TACTILE SWITCH Specification

Automation Grade
Manual

Temperature Range
-25C to +70C Celsius (oC)

Number of Module
1

Max. Current
50mA Milliampere (mA)

Finish Type
Matte

Rated Voltage
2A Ampere (A)

Protection Level
IP40

Circuit Type
Single

Product Type
TACT SWITCH

Material
Polyamide + Copper Alloy

Insulation Resistance
100M at 500V DC

Contact Resistance
100m max Milliohm (m)

Max. Voltage
3V Volt (V)

Operating Temperature
-25C ~ +70C Celsius (oC)

Stoke
2.5mm

Size
12x12x17 mm

Color
Black

Weight
2g Grams (g)

Mounting Type
Through Hole

Current Rating
0.05A

No Of Poles
Single Pole

12X12X17 MM 4 PIN BLACK TACTILE SWITCH Trade Information

Minimum Order Quantity
1000 Pieces

Delivery Time
7 Days

Sample Available
Yes

Sample Policy
Sample costs shipping and taxes has to be paid by the buyer

Main Domestic Market
All India

About 12X12X17 MM 4 PIN BLACK TACTILE SWITCH

Mounting Type	SMD
Current Rating	3V
Voltage Rating	2A
ROHS Compliance	No
Material	PLASTIC
Switch Type	Tact
Minimum Order Quantity	1000 Piece

Data Transfer: Connecting peripherals such as keyboards, mice, and storage devices to computers.
Charging: Powering and charging devices like smartphones, tablets, and other portable electronics.
Peripheral Connectivity: Connecting devices like printers, cameras, and external hard drives.
Audio/Video Transmission: Connecting devices like monitors and projectors with appropriate adapters.
Power Delivery: Providing power to devices through standards like USB Power Delivery (USB PD).

Reliable and Durable Design

Engineered with a combination of polyamide and copper alloy materials, this square tactile switch ensures longevity and stability. Its silver-plated alloy contacts guarantee minimal resistance and responsiveness, even with frequent use. The robust construction and through-hole mounting make it suitable for demanding consumer electronic and DIY applications.

Versatile Applications

With a compact 12x12x17 mm profile and a straightforward square actuator, this switch integrates seamlessly into keyboards, control panels, and hobby projects. Its compliance with RoHS and wide operating temperature range allow it to function reliably in various environments, making it a go-to choice for manufacturers and artisans alike.

Easy Installation & Maintenance

Featuring four straight pins and through-hole mounting, the installation process is simple and secure. The switch supports a maximum soldering temperature of 260C for up to 5 seconds, and it is lightweight at just 2g. Its single pole circuit design ensures efficient and hassle-free connectivity in manual automation setups.

FAQs of 12X12X17 MM 4 PIN BLACK TACTILE SWITCH:

Q: How is the 12x12x17 mm 4 Pin Tactile Switch installed in a circuit?

A: This tactile switch features a through-hole mounting type with four straight pins. To install, simply position the switch on your PCB, solder each pin at a maximum temperature of 260C for no more than 5 seconds to ensure reliable connection and avoid damage.

Q: What benefits does the silver-plated contact material offer?

A: Silver-plated alloy contacts provide excellent conductivity and corrosion resistance, resulting in lower contact resistance (maximum 100m) and extended switch lifespan. This ensures responsive actuation and reliable performance, especially in high-use consumer electronic devices.

Q: Where can this tactile switch be used most effectively?

A: This switch is ideal for consumer electronics, DIY projects, and keyboard assemblies. Its robust design and RoHS compliance also make it suitable for professional manufacturing, exporting, and importing applications, particularly in settings that demand consistent, long-term performance.

Q: What is the process for ensuring safe usage during soldering?

A: To maintain switch integrity, solder at a maximum temperature of 260C for no longer than 5 seconds per pin. Prolonged exposure to higher temperatures can damage the switchs internal components or compromise its polyamide and copper alloy structure.

Q: When should this tactile switch be replaced?

A: The switch is designed for a minimum of 100,000 mechanical cycles. Replace the unit if you notice signs of inconsistent actuation, increased contact resistance, or if the switch fails to operate within the specified -25C to +70C temperature range.

Q: How does IP40 protection benefit the application?

A: An IP40 rating protects against solid objects larger than 1mm, making the switch suitable for indoor environments and standard electronic panels. However, it is not protected against water ingress, so its best used in clean, dry conditions.

Q: What advantages does the 2.5mm stroke provide in usage?

A: The 2.5mm stroke offers a comfortable tactile feedback and a responsive actuation suitable for user interfaces such as keyboards and control panels, enhancing the user experience by providing a noticeable press with each use.
