4 PIN 2.54 MM PITCH MALE FEMALE JST CONNECTOR

Send Inquiry

Request To Call Back

4 PIN 2.54 MM PITCH MALE FEMALE JST CONNECTOR

Price 15 INR/ Piece

Get a Price/Quote

MOQ : 1000 Pieces

4 PIN 2.54 MM PITCH MALE FEMALE JST CONNECTOR Specification

Connector
JST 4-Pin Male and Female

Voltage Rating
250V AC/DC

Temperature
-25°C to +85°C

Connector Type
Crimp Housing with Terminals

Material
PBT / PA66 (Connectors), Copper Tinned (Wire)

Female End Type
JST Housing Female Socket

Application
PCB Interconnection, LED Strips, Battery Packs, Electronics DIY

Male End Type
JST Housing Male Pin

Capacity
2A max per contact

Pairs
Single

Wire Gauge
26 AWG

Sheild
Unshielded

Insulation
PVC

Outer Diameter
Approx 1.2mm per wire

Cable Type
Flat Ribbon / Single Row Cable

Jacket Material
PVC

Length
Customizable (Standard: 15cm)

Flame Resistance Level
UL94V-0

Number of Conductor
4

Color
White / Black (Depends on cable)

Cable Length
15 cm (customizable)

Current Rating
2A per pin

Mating Cycles
500 times Min

Mounting Type
Wire to Wire / Wire to Board

Insulation Resistance
More than 1000 M

Contact Resistance
Less than 20 m

Locking Mechanism
Friction Fit

Contact Plating
Tin over Copper

Pitch
2.54 mm

Operating Frequency
Low frequency signal / power

4 PIN 2.54 MM PITCH MALE FEMALE JST CONNECTOR Trade Information

Minimum Order Quantity
1000 Pieces

Sample Available
Yes

Sample Policy
Sample costs shipping and taxes has to be paid by the buyer

Main Domestic Market
All India

About 4 PIN 2.54 MM PITCH MALE FEMALE JST CONNECTOR

Pitch	2.5 mm
Brand	NO
Part Number	JST07
Connector Gender	MALE/FEMALE
Contact Material	PLASTIC
Current Rating	STANDARD
Minimum Order Quantity	100 Piece

Applications:
- Used in battery connections, LED lighting, computer hardware, and hobby electronics.
- Suitable for compact and lightweight electronic devices.
Advantages:
- Reliable and secure connections with locking mechanisms to prevent disconnection.
- Compact and space-saving design.
- Easy to assemble and disassemble without special tools.

Reliable Connectivity for Electronics Projects

Designed with a 2.54 mm pitch and friction fit locking, this 4-pin JST connector offers stable and robust wire-to-wire or wire-to-board connections. The tin over copper contacts ensure low contact resistance and reliable performance, even through frequent mating cycles. Its unshielded, flat ribbon PVC cable supports multiple configurations and project needs.

Versatile Applications Across Devices

Commonly used for PCB interconnections, LED strip installations, battery packs, and DIY electronics, this connector fits diverse requirements. The customizable cable length and compatibility with 26 AWG wires make it suitable for compact or extended connections, delivering flexibility for manufacturers, traders, and hobbyists.

Durable Materials and Safe Operation

Constructed from PBT/PA66 for connectors and tinned copper wires, this JST connector meets rigorous safety with UL94V-0 flame resistance. Its insulation provides over 1000 M resistance, supporting safe operation at up to 250V AC/DC and 2A per contact. The temperature range ensures reliability in varied environments.

FAQs of 4 PIN 2.54 MM PITCH MALE FEMALE JST CONNECTOR:

Q: How can I use the 4 PIN 2.54 mm Pitch JST Connector for a wire-to-board connection?

A: To use this JST connector for wire-to-board applications, align the male pin housing with the receiving PCB socket and insert with gentle pressure until the friction fit locks the connection. Attach wires to the terminals using the crimp housing, ensuring a secure grip and reliable signal transfer.

Q: What are the benefits of the PBT/PA66 material in these connectors?

A: PBT/PA66 offers excellent durability, flame resistance (UL94V-0), and protection against mechanical stress and high temperatures, making it ideal for electronics where long-term reliability is essential.

Q: Where is this JST connector commonly applied?

A: It is widely used in PCB interconnections, LED strip installations, battery packs, and various DIY electronics projects for secure and flexible wiring solutions.

Q: What is the process for customizing cable length?

A: Cable length can be customized during ordering. Specify your required length, and cables will be produced to match your projects needs, with 15 cm as the standard option.

Q: How does the friction fit locking mechanism enhance security?

A: The friction fit locking mechanism provides a firm connection, minimizing accidental disconnections and ensuring stable operation throughout at least 500 mating cycles.

Q: What usage limitations should I keep in mind regarding current and voltage?

A: Each pin supports up to 2A and a maximum voltage of 250V AC/DC. Do not exceed these ratings to maintain safe operation and prevent damage to the connector or attached equipment.

Q: When should I use a flat ribbon or single row cable type with this connector?

A: Flat ribbon or single row cable configurations are recommended where neat, parallel wiring is needed, such as PCB connections or organized electronics assemblies. Choose based on your installation and space requirements.
