2PIN 2.54 MM PITCH MALE FEMALE REPLICATE CONNECTOR

About 2PIN 2.54 MM PITCH MALE FEMALE REPLICATE CONNECTOR

• Applications:
  • Used in battery connections, LED lighting, computer hardware, and hobby electronics.
  • Suitable for compact and lightweight electronic devices.
• Advantages:
  • Reliable and secure connections with locking mechanisms to prevent disconnection.
  • Compact and space-saving design.
  • Easy to assemble and disassemble without special tools.


Versatile Applications

Tailored for general electronics, battery connections, and prototyping, this connector streamlines cable-to-cable assembly in low voltage setups. Its 2-pin configuration allows for straightforward integration in devices requiring up to 3A and 250V AC/DC, making it optimal for rapid builds and testing environments.


Robust Construction and Safety

Combining copper conductors with nylon housings and PVC insulation, the connector delivers durability and resilience. Its engineered with UL94V-0 flame resistance and RoHS compliance, suitable for use in environments that demand safety and adherence to international standards.


Customizable for Your Needs

With a standard length of 150 mm and option for customization, this connector adapts to different project requirements. The cable features red and black strands for easy polarity identification, enhancing user convenience during assembly and maintenance.



FAQs of 2PIN 2.54 MM PITCH MALE FEMALE REPLICATE CONNECTOR:




Q: How do I install the 2PIN 2.54 mm pitch male-female replicate connector?

A: To install, align the polarized male pin header and female socket ends and gently push together until fully mated. The cable-to-cable mounting type allows quick linkage without complicated tools.



Q: What are the typical usage scenarios for this connector?

A: It is commonly used in general electronics, battery connections, prototyping setups, and low voltage power circuits, offering reliable, modular solutions for distributed system designs.



Q: When should I consider customizing the cable length?

A: Customization of the standard 150 mm cable length is recommended when specific applications require unique routing or spatial constraints, ensuring optimal wiring management and device fit.



Q: Where can this connector be used in temperature-critical environments?

A: With its wide storage and operating temperature range (-40C to +85C for storage and -20C to +80C for use), the connector suits environments like labs, field projects, or devices exposed to fluctuating temperatures.



Q: What is the advantage of using this connectors UL94V-0 flame-resistant and RoHS-compliant design?

A: UL94V-0 flame resistance enhances safety by reducing fire risk, while RoHS compliance ensures environmental friendliness and adherence to restriction of hazardous substances in electrical components.



Q: How frequently can the connector be mated and unmated?

A: It supports a minimum of 500 mating cycles, ensuring dependable performance even in prototyping or modular setups where connectors are routinely disconnected and reconnected.



Q: What process can I follow for safe and optimal usage of the connector?

A: Use the connector within the specified current (up to 3A) and voltage (250V AC/DC) limits, match red/black wires for correct polarity, and ensure both ends are properly aligned before connecting to maintain safe operation and longevity of the assembly.
