DC PIN RED

Price 15 INR/ Piece

Get a Price/Quote

MOQ : 1000 Pieces

DC PIN RED Specification

Product Type
DC Pin

Material
Brass with Nickel or Tin Plating

Withstand Voltage
Up to 250V DC

Application
Ideal for PCB mounting, circuit board connections, and low-voltage DC electrical projects

Insulation Resistance
100 M at 500V DC

Height
Approx. 17 mm

Weight
About 1 gram per pin

Color
Red

Flame Retardance
UL94V-0

Mounting Type
Through Hole / PCB Mount

Current Rating
5A DC

Pin Length
Approx. 17 mm

Pin Diameter
2 mm

Operating Temperature
-20C to +80C

Surface Finish
Nickel/Tin Plated Brass

Contact Resistance
5 m

Packaging Type
Polybag or Box

DC PIN RED Trade Information

Minimum Order Quantity
1000 Pieces

Sample Available
Yes

Sample Policy
Sample costs shipping and taxes has to be paid by the buyer

Main Domestic Market
All India

About DC PIN RED

Output Voltage	5 V
Material	ABS Plastic
Current	1 A
Port Type	Type D
Input Voltage	5v
Usage/Application	DC PIN
Operating temperature	STANDARD
Minimum Order Quantity	100 Piece

- Prevent ground loops in audio systems.
- Isolate and protect components from voltage spikes.
- Interface different audio equipment with varying impedances.
Advantages:
- Electrical isolation between input and output.
- Noise reduction and signal integrity improvement.
- Compatibility with various audio standards.

Durable and Safe Construction

Crafted from premium brass and layered with nickel or tin plating, the DC PIN RED ensures consistent electrical performance and resists environmental damage. The pin meets the flame retardance requirements of UL94V-0, providing added safety in high-demand circuits or professional projects.

Easy Integration with PCBs

Designed specifically for through-hole or PCB mount applications, this DC pin streamlines circuit assembly and secures dependable connections. Its standardized 2 mm diameter and 17 mm height simplify insertion and soldering, making it perfect for both manual and automated board production.

Ideal for Wide-Ranging Applications

From DIY hobbies to industrial electronics manufacturing, the DC PIN RED supports a broad spectrum of low-voltage DC projects. Reliable insulation resistance and a robust current rating make it an attractive choice for professionals and enthusiasts needing stable, safe circuit connections.

FAQs of DC PIN RED:

Q: How do I properly mount the DC PIN RED onto a printed circuit board?

A: To mount the DC PIN RED, insert the 2 mm diameter pin through the corresponding PCB hole and solder it securely in place. The through-hole design ensures a stable mechanical and electrical connection for both manual assembly and automated soldering processes.

Q: What are the main benefits of choosing the DC PIN RED for my electronic project?

A: The DC PIN RED offers excellent conductivity, low contact resistance (5 m), and high insulation (100 M at 500V DC). Its flame-retardant UL94V-0 rating, along with nickel/tin plating for corrosion protection, ensures long-term durability and safe operation in a variety of low-voltage DC applications.

Q: Where is the DC PIN RED typically used, and who are the ideal users?

A: The pin is widely implemented in PCB mounting and circuit board connections for electronics manufacturing, assembly, prototyping, and low-voltage DC projects. It is especially suited for distributors, exporters, importers, manufacturers, and traders in India looking for dependable PCB terminal solutions.

Q: What is the recommended operating temperature range for the DC PIN RED?

A: This pin is rated for reliable performance within a temperature range of -20C to +80C, making it suitable for use in environments with moderate thermal fluctuations.

Q: When should I consider using this specific DC pin model over alternatives?

A: Choose the DC PIN RED when your project requires secure, flame-retardant, low-resistance connections for DC circuits on PCBs, particularly where a 2 mm diameter and 5A current rating are needed. Its compatibility with automated assembly and robust physical properties make it a preferred option for both large-scale manufacturing and specialized builds.

Q: What process is followed for ensuring the quality and safety of these pins?

A: The DC PIN RED is manufactured using high-grade brass, coated with nickel or tin plating, and is tested for contact resistance, insulation resistance, flame retardance, and withstand voltage to guarantee compliance with industry standards, including UL94V-0 flame retardance.
