BANANA SOCKET

Price 3 INR/ Piece

Get a Price/Quote

MOQ : 1000 Pieces

BANANA SOCKET Specification

Thickness
Body approx. 6 mm

Sealed
Non-sealed

Surface Treatment
Nickel Plated

Cable Diameter
Up to 4 mm

Product Type
Banana Socket

Material
Brass body with ABS insulation

Application
Test equipment connections

Contact Resistance
10 m

Insulation Resistance
1000 M

Diameter
Outer: 11 mm, Inner: 4 mm

Terminal Socket
4 mm Banana Socket

Style
Standard

Fittings
Panel Mount

Rated Voltage
250V AC/DC

Weight
Approx. 5 g

Color
Red, Black, Yellow, Blue, Green

Connection Method
Solder / Screw

Pack Size
50/100 pieces per pack

Mounting Hole Size
6 mm

RoHS Compliant
Yes

Storage Condition
Dry, dust-free area

Temperature Range
-20C to +70C

Current Rating
10A max

Flame Retardant
Yes (Conforms to UL94V-0)

BANANA SOCKET Trade Information

Minimum Order Quantity
1000 Pieces

Main Domestic Market
All India

About BANANA SOCKET

Size	4 mm
Type	Female socket banana
Plug Size	4MM
Material	METAL PLASTIC
Color	RED & WHITE
Body	PLASTIC
RATED CURRENT	5AMP
Minimum Order Quantity	1000 Piece

4mm Banana Socket Jack for Banana Plug Terminal Connector is a 4mm banana plug spade connector. The connector is a nickel-plated aluminium alloy core with a hard plastic shell for insulation. This makes it durable and has stable performance.

The wire can be soldered directly on to the connector. This connector is suitable for spade terminals, banana plugs or bare wires; which is easier to install and use.

Also, the connector has color-coding for maintaining the polarity.

Exceptional Durability and Safety

Engineered with a flame-retardant ABS shell and a sturdy brass body, the BANANA SOCKET offers excellent insulation resistance ( 1000 M) and low contact resistance ( 10 m), ensuring safe and consistent performance. The nickel-plated surface enhances corrosion resistance and longevity, making it suitable for demanding environments.

Versatile Installation Options

This standard-style socket provides both screw and solder terminals, allowing for flexible and secure connections. With a simple panel-mount fitting and compatibility with 4 mm banana plugs, installation is quick and convenient for most test equipment configurations.

Compliance and Application

Fully compliant with RoHS and adhering to UL94V-0 flame-retardancy standards, the BANANA SOCKET ensures both user safety and environmental responsibility. Its widely suited for use in laboratories, electronics manufacturing, and educational facilities for efficient test device connectivity.

FAQs of BANANA SOCKET:

Q: How is the BANANA SOCKET typically installed?

A: The BANANA SOCKET is installed using a 6 mm mounting hole and is panel-mounted. You can connect wires by either the screw or solder terminals, accommodating cables up to 4 mm in diameter for flexible setup.

Q: What is the recommended application for this banana socket?

A: It is primarily used for establishing secure connections on electrical and electronic test equipment. Its robust construction and safety certifications make it ideal for laboratory, educational, and industrial environments.

Q: When should I consider using this socket over alternative connectors?

A: Choose the BANANA SOCKET when you require a reliable, color-coded, panel-mounted solution for frequent test instrument connections, especially where high current rating (up to 10A) and safety compliance are important.

Q: Where should I store these sockets before installation?

A: Store the sockets in a dry, dust-free area to preserve their electrical and mechanical integrity. This ensures optimal performance and longevity once installed.

Q: What process is recommended for connecting wires to this socket?

A: You may use either the screw terminal for quick attachment or soldering for a more permanent connection. Always ensure compatibility with cable diameters up to 4 mm for a secure fit.

Q: How does being RoHS compliant and UL94V-0 flame retardant benefit users?

A: RoHS compliance guarantees that the socket is free of hazardous substances, supporting environmental safety. The UL94V-0 flame retardancy ensures the material resists ignition, providing added protection in high-risk environments.
