9.5 MM PITCH 9 PIN BARRIER TERMINAL CONNECTOR

Send Inquiry

Request To Call Back

9.5 MM PITCH 9 PIN BARRIER TERMINAL CONNECTOR

Price 15 INR/ Piece

Get a Price/Quote

MOQ : 1000 Pieces

9.5 MM PITCH 9 PIN BARRIER TERMINAL CONNECTOR Specification

Voltage Rating
300V

Material
Body: Thermoplastic, Screws: Steel with zinc plating, Terminals: Brass

Connector Type
Barrier Terminal Connector

Application
Wiring interconnections, industrial control, panel wiring, electrical equipment

Capacity
9 Pin connections

Temperature
-40C to +105C

Connector
Barrier Terminal Block

Length
Custom/Not Applicable

Flame Resistance Level
UL94V-0

Wire Gauge
Accepts 12-22 AWG

Color
Black

Insulation
Thermoplastic base

Number of Conductor
9

Pin Count
9

Current Rating
15A per contact

Dimensions (L x W x H)
(Pitch x 9) x Width x Height (varies by manufacturer, typically around 85.5mm x 15mm x 16mm)

Termination Style
Screw Clamps

Screw Size
M3

Insulation Resistance
500M at 500V DC

Mounting Type
PCB or Panel Mount

Dielectric Withstanding Voltage
Above 2000V AC/minute

Contact Resistance
20m

Pitch
9.5 mm

9.5 MM PITCH 9 PIN BARRIER TERMINAL CONNECTOR Trade Information

Minimum Order Quantity
1000 Pieces

Sample Available
Yes

Sample Policy
Sample costs shipping and taxes has to be paid by the buyer

Main Domestic Market
All India

About 9.5 MM PITCH 9 PIN BARRIER TERMINAL CONNECTOR

Material	PVC
Usage/Application	CONNECTOR
Packaging Type	BOX
Brand	IM[PORTED
Screw Material	METAL
Connection	BARRIER CONNECTOR
Minimum Order Quantity	100 Piece

Applications:
- Used in battery connections, LED lighting, computer hardware, and hobby electronics.
- Suitable for compact and lightweight electronic devices.
Advantages:
- Reliable and secure connections with locking mechanisms to prevent disconnection.
- Compact and space-saving design.
- Easy to assemble and disassemble without special tools.

Reliable Connections for Industrial Applications

Designed for critical interconnections, the 9.5 mm pitch 9 pin barrier terminal connector offers secure and consistent connectivity in demanding environments. With its robust screw clamp mechanism and high insulation resistance, it minimizes the risk of loose contacts or electrical faults, making it ideal for electrical panels, machinery, and automation equipment.

Versatile Mounting and Easy Installation

This connector is well-suited for both PCB and panel mounting, offering flexibility during installation. Its screw clamp termination style enables tool-assisted, secure wire fastening, accommodating 12-22 AWG wires. With clearly identified pins and sturdy design, installation is straightforwardideal for quick replacements or new projects.

FAQs of 9.5 MM PITCH 9 PIN BARRIER TERMINAL CONNECTOR:

Q: How do I install the 9.5 mm pitch 9 pin barrier terminal connector?

A: To install, mount the connector onto a PCB or panel using its base. Strip your wire to the appropriate length (within 1222 AWG), insert it into the respective terminal, and secure it using an M3 screw. Ensure all screws are tightened for optimal electrical contact.

Q: What are the primary benefits of using this barrier terminal connector?

A: This connector provides secure, high-current connections and exceptional flame resistance (UL94V-0). Its robust screw clamp design prevents wire loosening, while the 9-pin layout enables multiple connections in a compact spaceideal for panel wiring and industrial control systems.

Q: Where is this connector typically used?

A: It is widely used in industrial control panels, machinery wiring, distributor panels, and electrical equipment that require reliable, multi-point electrical interconnections. Its durable build makes it suitable for both commercial and heavy-duty environments.

Q: What types of wires and cables can be used with this connector?

A: The barrier terminal supports wire sizes from 12 to 22 AWG. Solid or stranded wires fitting these gauges can be securely fastened using the screw clamps, making it versatile for various wiring requirements.

Q: How does the connector ensure electrical safety and reliability?

A: The unit features a thermoplastic, flame-retardant body with high insulation resistance (500M at 500V DC) and a dielectric withstanding voltage above 2000V AC/minute. Its strong mechanical construction and low contact resistance (20m) further enhance safety and consistent performance.

Q: When should I choose a 9 pin barrier terminal connector over other options?

A: Select this connector for applications requiring secure, high-current connections (up to 15A per contact), reliable insulation, and easy field wiring changesespecially in environments where safety, quick installation, and reconfiguration are priorities.

Q: What is the process for replacing or maintaining this connector?

A: Disconnect power before servicing. Loosen the screws, remove wires, and unmount the connector if necessary. Install the new unit by following normal installation steps: mount to panel/PCB, insert wires, and tighten screws. Its modular design simplifies routine maintenance or replacement.
