Oval Rocker Switch 3 Pin Red Light On Off, SPST

Send Inquiry

Request To Call Back

Oval Rocker Switch 3 Pin Red Light On Off, SPST

Name: Oval Rocker Switch 3 Pin Red Light On Off, SPST
Brand: Madan Link Industries
Price: 15.0 INR
Availability: InStock

Price 15.0 INR/ Piece

Get a Price/Quote

MOQ : 200 Pieces

Oval Rocker Switch 3 Pin Red Light On Off, SPST Specification

Temperature Range
-25C to +85C

Finish Type
Matte

Circuit Type
SPST (Single Pole Single Throw)

Response Time
Instant

Automation Grade
Manual

Mechanical Life
10,000 cycles

Max. Current
6A

Number of Module
1

Protection Level
IP20

Rated Voltage
250V AC

Product Type
Oval Rocker Switch

Material
Plastic housing, Copper contacts

Insulation Resistance
100 M at 500 VDC

Contact Resistance
50 m

Max. Voltage
250V AC

Operating Temperature
-25C to +85C

Stoke
ON-OFF (SPST)

Size
30mm oval

Color
Red (illuminated)

Weight
8g approx.

Mounting Type
Panel Mount

Current Rating
6A

No Of Poles
Single Pole

Panel Cutout
Approx. 20mm x 13mm

Application
Electrical Appliances, Power Supplies, Instruments

Body Shape
Oval

Terminal Type
Solder Lug/Quick Connect

Switch Action
Rocker

Compliance
RoHS Compliant

Switch Function
On-Off

Illumination
Red LED Indicator

Oval Rocker Switch 3 Pin Red Light On Off, SPST About

Switch Function	SPST
Pole Configuration	SPST
Size Category	Standard
Shape	Round
Switch Operation	On-Off
Number of Pins	3 pin
Rated Voltage	125 V AC
Current Rating	10 A
Illumination	illuminated
Rocker Shape	Round
Color	Red
Contact Material	Copper Alloy
View in Hindi	3 , SPST

The KCD1-9-101N LED Rocker Switch is a miniature switch designed for use in a wide variety of applications. It has a SPST contact configuration and an ON-OFF switch operation, making it ideal for a variety of uses. It has 3 pins, with brass terminals that are silver-plated for added durability. This switch has a rating of 10A 125VAC/6A 250VAC, contact resistance of 35mOhm max, and a temperature range of -25C+85C. It also has an insulation resistance of 100mOhm min (500VDC), a dielectric strength of 1500VAC for 1 minute, and an electrical life of >= 10,000 cycles. Additionally, it has a mechanical life of >= 100,000 cycles, making it a reliable and durable option.

Terminal Brass with sliver plated
Button color: red, green, yellow, blue, or white
Rating: 10A 125VAC/6A 250VAC
Housing color: Standard black
Contact Configuration: SPST
Switch Operation: (ON-OFF)
Contact Resistance: 50 m max
Operating Temperature: -25+85
Insulation Resistance: 100m min (500VDC)
Electrical Life: 10,000 Cycles
Dielectric strength: 1500VAC 1 minute
Mechanical Life: 100,000 Cycles

Reliable Performance with Illuminated Clarity

This rocker switch combines instant response with clear ON-OFF indication via its red LED. Rated for 250V AC and up to 6A, it's ideal for numerous electrical applications demanding rapid functionality and visible feedback. The SPST circuit toggles devices effortlessly, enhancing operational convenience.

Durable Construction for Long-Term Use

Manufactured from high-quality plastic and copper, this switch resists wear and environmental stress. Designed to operate between -25C and +85C with an IP20 protection level, it's suited for most indoor electrical installations. The matte finish delivers a sleek look with robust performance.

Straightforward Installation and Versatile Application

Thanks to solder lug and quick connect terminals, installation is user-friendly for both professionals and DIY enthusiasts. The oval 30mm body fits standard panel cutouts, making it adaptable for appliances, power supplies, and instrumentation panels across industries.

FAQ's of Oval Rocker Switch 3 Pin Red Light On Off, SPST:

Q: How do I correctly install the Oval Rocker Switch 3 Pin Red Light On Off?

A: Install the switch by fitting it into a 20mm x 13mm panel cutout and connecting wires to the solder lug or quick connect terminals. Ensure power is off beforehand and follow wiring diagrams compatible with SPST switches.

Q: What appliances and devices can benefit from using this illuminated rocker switch?

A: This switch is suitable for electrical appliances, power supplies, instrumentation panels, and devices requiring ON-OFF control with visual status indication through the red LED illumination.

Q: When is the red LED indicator illuminated on the switch?

A: The red LED lights up when the switch is in the ON position, providing immediate visual confirmation that the connected appliance or device is powered.

Q: Where should this switch primarily be used given its protection level?

A: With an IP20 protection rating, it is best suited for indoor environments where protection against moisture and dust is not critical, such as labs, workshops, and home appliances.

Q: What is the lifecycle and reliability of this rocker switch?

A: It is engineered for a mechanical life of up to 10,000 cycles, ensuring consistent performance over extended use and compliance with safety standards like RoHS.

Q: How does the SPST (Single Pole Single Throw) function work in this switch?

A: The SPST configuration allows the switch to either complete or break a single electrical circuit when toggled between ON and OFF, making it ideal for simple, direct power switching.

Q: What are the main benefits of using this panel-mounted oval rocker switch?

A: Key advantages include clear illuminated feedback for status, reliable ON-OFF control, easy panel mounting, and suitability for a wide range of electrical and electronic applications.
