Rotary Encoder 6 Pin

Price 500 INR/ Piece

Get a Price/Quote

MOQ : 1000 Pieces

Rotary Encoder 6 Pin Specification

Surface Finish
Nickel Plated

Overheating Protection
NO

Efficiency
High Accuracy

Operating Temperature
-20°C to +70°C

Shape
Cylindrical

IP Rating
IP40

Humidity %
0-95% RH

Feature
360° Rotation, Detent

Mounting Type
PCB Mount

Insulation Material
Plastic

Connector Type
Solder Pin

Product Type
Rotary Encoder

Application
Industrial Automation, Audio Equipment, Robotics

Protection Level
IP40

Frequency (MHz)
DC Only

Rated Voltage
5V DC

Energy Consumption
Low Power

Output Type
Digital Incremental

Color
Blue and Silver

Dimension (L*W*H)
20mm x 15mm x 25mm

Weight
7 grams

Phase
Single Phase

Input Voltage
5V DC

Size
Shaft Diameter 6mm

Material
Metal and Plastic

No Of Poles
Single Pole

Connection Type
6-Pin Solder Type

Minimum Order Quantity
10 pieces

RoHS Compliant
Yes

Insulation Resistance
100 M at 250V DC

Electrical Life
30,000 cycles

Environmental Compliance
Lead-Free

Shaft Length
15 mm

Storage Temperature
-30C to +80C

Pulse Per Rotation
20 pulses

Contact Resistance
100 m

Number of Detents
20 positions per revolution

Rotation Angle
Continuous 360

With Switch
Yes (Push Button Switch)

Output Signal
2 Channels (A & B), Quadrature

Rotary Encoder 6 Pin Trade Information

Minimum Order Quantity
1000 Pieces

Sample Available
Yes

Sample Policy
Sample costs shipping and taxes has to be paid by the buyer

Main Domestic Market
All India

About Rotary Encoder 6 Pin

Encoder Type	Rotary
Shaft Type	Solid
Usage/Application	Industrial
Color	Black
Power Supply Voltage	STANDARD
Multi Turn	NO
Single Turn	YES
Storage Environment	AS PER USE
Minimum Order Quantity	1000 Piece

Consumer Electronics: Power switches in radios, flashlights, and toys.Industrial Equipment: Control switches for machinery and equipment.Automotive: Control switches for lights, wipers, and other systems.Telecommunication Devices: Signal routing and selection.Computers and Peripherals: Mode selection, reset switches, and power control.

Precision and Reliability

Engineered for high accuracy, this rotary encoder provides 20 distinct positions with robust contact and insulation resistance, ensuring dependable data output for sensitive control systems. Its continuous 360 rotation and precise detent mechanism make it ideal for precise adjustment tasks.

Versatile Applications

Suitable for industrial automation, audio equipment, and robotics, the encoders compact cylindrical shape and PCB mount compatibility allow flexible integration into diverse environments. Its IP40 rating offers basic protection, and the 6-pin solder type connection simplifies installation.

Durability and Compliance

With an electrical life of up to 30,000 cycles and compliance with RoHS and lead-free standards, this component ensures longevity and environmental responsibility. Its nickel-plated finish adds to its corrosion resistance, promising sustained fidelity even in demanding conditions.

FAQs of Rotary Encoder 6 Pin:

Q: How is the Rotary Encoder 6 Pin installed in a circuit?

A: The encoder features a 6-pin solder type connection and is designed for PCB mounting. Simply align the pins with the PCB ports and solder firmly in place, ensuring reliable electrical contacts for output signal channels and the integrated push button switch.

Q: What are the practical benefits of using a 20-position rotary encoder in automation systems?

A: With 20 detents per revolution and high accuracy, this rotary encoder allows for precise control and reliable feedback in automation tasks. It enables accurate incremental input, improving responsiveness and adjustment fidelity in industrial, audio, and robotic systems.

Q: When should I use the integrated push button switch on this encoder?

A: The integrated push button switch is ideal for applications requiring dual-input options, such as confirming selections or triggering secondary actions within user interfaces or control systems. It enhances versatility in process control and machine operation design.

Q: Where can this rotary encoder be utilized for optimal performance?

A: Its design caters to industrial automation, audio processing equipment, and robotics. You can implement it in machinery controls, sound mixers, or robot position feedback modules, thanks to its high accuracy, low contact resistance, and robust construction.

Q: What process should be followed for maintaining environmental compliance with this product?

A: The encoder is RoHS compliant and lead-free. To maintain environmental standards, ensure that disposal procedures adhere to electronic recycling practices and avoid exposure to temperatures outside the storage range of -30C to +80C.

Q: How do the dual output channels (A & B) improve signal processing?

A: The quadrature output (Channels A & B) provides precise digital incremental signals, allowing for accurate direction and pulse counting. This feature enhances feedback systems by enabling both position tracking and rotational direction sensing.
