12X12X21MM 4 PIN BLACK TACTILE SWITCH

Price 2 INR/ Piece

Get a Price/Quote

MOQ : 1000 Pieces

12X12X21MM 4 PIN BLACK TACTILE SWITCH Specification

Automation Grade
Manual

Response Time
<1ms

Circuit Type
SPST (Single Pole Single Throw)

Mechanical Life
100,000 cycles

Finish Type
Matte

Rated Voltage
12V DC

Max. Current
50mA

Protection Level
IP40

Temperature Range
-25C to +70C

Number of Module
1 Module

Product Type
Tactile Switch

Material
Plastic (Body), Metal (Contacts)

Insulation Resistance
100M min. at 500V DC

Contact Resistance
50m max.

Max. Voltage
12V DC

Operating Temperature
-25C to +70C

Stoke
2.5mm

Size
12x12x21 mm

Color
Black

Weight
Approx. 2g

Mounting Type
Through Hole

Current Rating
50mA

No Of Poles
1 Pole

Dielectric Strength
250V AC for 1 minute

Bounce Time
5ms

Terminal Type
4 Pin

Storage Temperature
-30C to +80C

Switch Function
Momentary

Switching Reliability
High

Contact Material
Silver-plated Alloy

Switch Travel
2.5mm

Initial Force
18050gf

Actuator Type
Round Button

RoHS Compliance
Yes

12X12X21MM 4 PIN BLACK TACTILE SWITCH Trade Information

Minimum Order Quantity
1000 Pieces

Sample Available
Yes

Main Domestic Market
All India

About 12X12X21MM 4 PIN BLACK TACTILE SWITCH

Mounting Type	SMD
Current Rating	3V
Voltage Rating	2A
ROHS Compliance	No
Material	PLASTIC
Switch Type	Tact
Minimum Order Quantity	1000 Piece

Applications: Ideal for industrial machinery, security systems, automotive applications, and sensitive electronic equipment.
Customization: Available in various key configurations, sizes, and mounting options to meet specific security needs.
Durability: Constructed with high-quality materials to withstand harsh environments and frequent use.

Compact and Durable Design

Engineered for long-term performance, this tactile switch features a robust plastic body combined with silver-plated alloy contacts. Its mechanical life spans up to 100,000 cycles, ensuring reliable actuation for repeated use in control panels, consumer devices, and industrial applications.

Precise Performance

With a controlled initial force of 18050gf and 2.5mm stroke, the switch delivers consistent tactile feedback. It boasts a bounce time of 5ms, a response time under 1ms, and high insulation resistance, making it suitable for demanding electronic circuits requiring accurate pulse signals.

Versatile Applications

This 4 pin round button tactile switch is designed for manual automation, offering SPST momentary action. Its through-hole mounting supports easy integration into PCBs, making it perfect for developers, manufacturers, and repair services across diverse industries. The switch operates reliably in temperatures ranging from -25C to +70C.

FAQs of 12X12X21MM 4 PIN BLACK TACTILE SWITCH:

Q: How is the 12X12X21MM 4 Pin Black Tactile Switch commonly used?

A: This tactile switch is widely used in electronic control systems for momentary switching applications, such as reset, start, or input functions in consumer electronics, industrial equipment, and DIY projects.

Q: What are the benefits of the silver-plated alloy contacts in this switch?

A: Silver-plated alloy contacts provide excellent conductivity and resistance to oxidation, ensuring low contact resistance, high signal integrity, and long-term reliability for the switch.

Q: When should this switch be selected over other types?

A: Choose this switch when you require a momentary SPST function with tactile feedback, a compact form factor, and reliable operation in moderate environmental conditions for up to 100,000 mechanical cycles.

Q: Where is the 12X12X21MM tactile switch typically installed?

A: It is generally mounted on printed circuit boards via through-hole technology in devices such as control panels, embedded systems, small appliances, and instrumentation.

Q: What process is involved in mounting the switch?

A: Installation involves placing the switchs four pins through matching PCB holes and securing it by soldering, ensuring stable electrical connection and mechanical retention.

Q: How does the switch perform under varying temperatures?

A: Engineered with robust materials, the switch can operate efficiently within a temperature range of -25C to +70C and can be safely stored from -30C to +80C without performance degradation.

Q: What advantages does its RoHS compliance offer?

A: RoHS compliance certifies that the switch is manufactured without hazardous substances, making it environmentally friendly and suitable for use in global markets adhering to strict safety regulations.
