Rotary Encoder 4 Pin

Name: Rotary Encoder 4 Pin
Brand: Madan Link Industries
Price: 450.00 INR
Availability: InStock

Price 450.00 INR/ Piece

Get a Price/Quote

MOQ : 1000 Pieces

Rotary Encoder 4 Pin Specification

Product Type
ROTARY ENCODER 4 PIN

Application
Industrial

Rated Voltage
3.0 - 3.6 Volt (V)

Output Type
Electrical

Color
Red

Size
Small

Material
Aluminum Oxide (Al2O3) Ceramic Substrate, Silicone Encapsulation

Rotary Encoder 4 Pin Trade Information

Minimum Order Quantity
1000 Pieces

Sample Available
No

Main Domestic Market
', l, l, ', All India

About Rotary Encoder 4 Pin

ncoder Type	Rotary
Shaft Type	Solid
Usage/Application	Industrial
Color	Gray
Hollow Shaft Diameter	STANDARD
Power Supply Voltage	AS PER USE
Multi Turn	SINGLE
Operating Temperature Range	AS PER USE
Output Circuit	AS PER USE
Single Turn	YES
Storage Temperature Range	AS PER USE
Features	ROTARY
Maximum Rotation Speed	STANDARD
Weight (packed state)	LITE
Cable And Connector	NO
Minimum Order Quantity	1000 Piece

Arotary encoder,also called ashaft encoder, is an electro-mechanical device that converts the angular position or motion of a shaft or axle to analog or digital output signals.

Engineered for Industrial Environments

Crafted with an aluminum oxide ceramic base and protected by silicone encapsulation, the 4-pin rotary encoder stands up to the harsh conditions typical of industrial applications. Its compact form factor and electrical output compatibility make it easy to integrate into automated systems where precision and reliability are essential.

Optimized Electrical Performance

Rated for use within a voltage range of 3.0 to 3.6 V, this encoder delivers consistent and accurate output. It is well-suited for real-time feedback control in a wide range of equipment, maintaining stable operation and supporting the complex needs of industrial automation.

FAQs of Rotary Encoder 4 Pin:

Q: How is the 4-pin rotary encoder installed in industrial machinery?

A: The compact design of the 4-pin rotary encoder allows for easy mounting in tight spaces on control panels or motor assemblies. It can be connected directly to the control circuitry using its four pins, with straightforward integration into existing systems due to its electrical output interface.

Q: What are the primary benefits of using an aluminum oxide (Al2O3) ceramic substrate in this encoder?

A: Aluminum oxide ceramic provides high electrical insulation, thermal stability, and mechanical strength. These properties enhance durability, prolong the service life of the encoder, and ensure reliable performance in challenging industrial environments.

Q: When should silicone encapsulation be considered significant for encoder applications?

A: Silicone encapsulation is crucial when the encoder is exposed to moisture, dust, or vibration. It protects the internal components from environmental stress, thereby ensuring consistent output and extending the operational lifespan of the device in rugged industrial settings.

Q: Where can this rotary encoder be sourced in India?

A: This rotary encoder is available through verified distributors, exporters, importers, manufacturers, and traders across India, making it easily accessible for local and international buyers seeking reliable components for industrial automation.

Q: What is the process of interfacing the encoders electrical output with a control system?

A: The encoders electrical output can be interfaced by connecting its four pins to the designated inputs on a microcontroller, PLC, or other control hardware. Ensure the supply voltage is within 3.03.6 V, and follow conventional wiring diagrams for proper signal communication and performance.

Q: How can this encoder be used for enhancing automation efficiency?

A: By providing precise position and rotational feedback, the encoder optimizes machine control, reduces errors, and improves overall automation efficiency. Its accurate data enables real-time adjustment for motors and actuators, promoting productivity and reducing downtime.
