BNC FEMALE GREEEN

Price 6 INR/ Piece

Get a Price/Quote

MOQ : 1000 Pieces

BNC FEMALE GREEEN Specification

Product Type
BNC Female Connector

Material
Brass with nickel plating and PVC insulation

Withstand Voltage
1500V AC/minute

Application
CCTV cameras, test equipment, electronic devices, video and audio signal transmission

Insulation Resistance
1000 M at 500V DC

Height
Approx. 28 mm

Weight
6 g

Color
Green

BNC FEMALE GREEEN Trade Information

Minimum Order Quantity
1000 Pieces

Sample Available
Yes

Sample Policy
Sample costs shipping and taxes has to be paid by the buyer

Main Domestic Market
All India

About BNC FEMALE GREEEN

Type of Connector	BNC
Current Rating	2.5 A
Brand	IMPORTED
Color	Black
Material	Aluminum
Black and Red	AS PER DEMAND
Red & Black	AS PER ODER
Current (A)	AS PER ODER
Size (L X W X H)	STANDARD
Minimum Order Quantity	100 Piece

Applications:
- Used in battery connections, LED lighting, computer hardware, and hobby electronics.
- Suitable for compact and lightweight electronic devices.
Advantages:
- Reliable and secure connections with locking mechanisms to prevent disconnection.
- Compact and space-saving design.
- Easy to assemble and disassemble without special tools.

Versatility Across Impedance Needs

The BNC Female Green connector supports both 50 Ohm and 75 Ohm impedance, making it a flexible choice for a range of electronic, video, and audio signal transmission setups. Its compatibility smooths integration into various systems without compromise on quality or performance.

Robust Construction for Demanding Environments

Engineered with brass and nickel plating, gold-plated pins, and insulated in PVC, this connector endures harsh temperature ranges from -40C to +85C and withstands voltages up to 1500V AC/minute. Its bayonet coupling ensures solid locking and reliability in critical installations.

Reliable Shielding and Safety Compliance

Advanced shielding ensures electromagnetic compatibility, critical for minimizing interference in sensitive equipment. RoHS compliance makes it a safe choice for sustainable and regulatory-approved applications, positioning it as a future-ready connector for distributors and manufacturers.

FAQs of BNC FEMALE GREEEN:

Q: How is the BNC Female Green connector installed in a panel mount application?

A: This connector utilizes a panel mount design and solder-type wire connection, where the user solders the wire onto the connector and secures it onto the mounting panel using its bayonet coupling for a reliable and durable fit.

Q: What benefits does the gold-plated brass center pin offer for signal transmission?

A: The gold-plated brass center pin provides enhanced conductivity and corrosion resistance, ensuring minimal signal loss and longevity, which is vital for video, audio, and test equipment accuracy.

Q: Where can the BNC Female Green connector be used effectively?

A: It is well-suited for CCTV camera systems, test and measurement devices, electronic equipment, and professional video or audio signal transmission, supporting installation in both commercial and industrial environments.

Q: What is the process for ensuring electromagnetic compatibility with this connector?

A: Built-in shielding within this connector mitigates electromagnetic interference. To maximize compatibility, ensure proper panel mounting and grounding during installation, which preserves signal integrity.

Q: When should you choose the BNC Female Green connector with dual impedance compatibility?

A: Select this connector when you require seamless integration with systems supporting either 50 Ohm or 75 Ohm impedance, such as mixed-signal setups in broadcast, surveillance, or instrumentation.

Q: What safety standards does this BNC connector meet?

A: It is RoHS compliant, ensuring restricted hazardous substances in construction, and supports insulation resistance 1000 M and withstands up to 1500V AC/minute for enhanced safety.

Q: How does the bayonet locking mechanism enhance its usage?

A: The bayonet coupling provides a secure and quick-locking interface, preventing accidental disconnects and guaranteeing stable connections, which is especially important in environments subject to vibration or frequent handling.
