6X6X7 MM 2 PIN VERTICAL BLACK TACTILE SWITCH

Send Inquiry

Request To Call Back

6X6X7 MM 2 PIN VERTICAL BLACK TACTILE SWITCH

Price 2 INR/ Piece

Get a Price/Quote

MOQ : 1000 Pieces

6X6X7 MM 2 PIN VERTICAL BLACK TACTILE SWITCH Specification

Mechanical Life
100,000 cycles

Rated Voltage
12V DC

Temperature Range
-20C to +70C

Circuit Type
Single Pole Single Throw (SPST)

Protection Level
IP40

Automation Grade
Manual

Max. Current
50 mA

Finish Type
Matte

Number of Module
1

Response Time
<1 ms

Product Type
Tactile Switch

Material
Plastic (housing), Stainless Steel (contacts)

Insulation Resistance
100 M min at 500V DC

Contact Resistance
50 m max

Max. Voltage
12V DC

Operating Temperature
-20C to +70C

Stoke
0.25 mm

Size
6x6x7 mm

Color
Black

Weight
Approx 0.5 g

Mounting Type
Through Hole (THT)

Current Rating
50 mA @ 12V DC

No Of Poles
Single Pole

Application
Consumer Electronics, Appliances, Controllers

Moisture Level
Level 1 (per J-STD-020D)

Contact Material
Silver plated

RoHS Compliant
Yes

Number of Pins
2

Operating Humidity
95% RH

Storage Temperature
-40C to +85C

Actuation Force
180 90gf

Dielectric Strength
250V AC for 1 min

Soldering Temperature
260C (max 5 s)

Switch Function
Momentary (Push to Make)

Button Shape
Round

Contact Configuration
Normally Open (NO)

Height from PCB
7 mm

6X6X7 MM 2 PIN VERTICAL BLACK TACTILE SWITCH Trade Information

Minimum Order Quantity
1000 Pieces

Sample Available
Yes

Main Domestic Market
All India

About 6X6X7 MM 2 PIN VERTICAL BLACK TACTILE SWITCH

Utilise this glorious offer on the 6X6X7 MM 2 Pin Vertical Black Tactile Switchwhere fresh design meets optimum performance! Engineered with a robust silver-plated contact material, this redoubtable component delivers a precise actuation force of 180 90gf. The switch boasts a momentary (push-to-make) function and a round black button, with reliable insulation resistance (100 M) and a durable matte finish. Operating flawlessly from -20C to +70C, its ideal for consumer electronics, appliances, and controllers. Avail this deal for a steadfast, RoHS-compliant control solutionimported, exported, and distributed across India.

Versatile Switch for Precision Usage

The 6X6X7 MM 2 Pin Vertical Black Tactile Switch is purpose-built for manual actuation in consumer electronics, controllers, and appliances. Featuring a compact through-hole design, optimum response time of under 1 ms, and redoubtable mechanical endurance above 100,000 cycles, this component excels in demanding applications. Its moisture protection, quick tactile feedback, and single pole single throw configuration offer glorious practicality for circuit integration.

Efficient Domestic Distribution and Secure Samples

This vertical tactile switch is widely distributed across Indias main domestic markets, assuring seamless access for manufacturers and traders. Secure shipping practices are utilised for each order, and sample units are available upon asking price request. Every switch is packaged securely to protect against transit damage, ensuring customers receive pristine condition components delivered right to their address for hassle-free integration.

FAQs of 6X6X7 MM 2 PIN VERTICAL BLACK TACTILE SWITCH:

Q: How can the 6X6X7 MM 2 Pin Vertical Black Tactile Switch be used in electronic projects?

A: The switch is ideal for initiating or interrupting circuits in devices like consumer electronics, controllers, and appliances, offering momentary push-to-make functionality.

Q: What makes this tactile switch a reliable choice for demanding environments?

A: Its robust construction, silver-plated contacts, high insulation resistance, and compliance with IP40 and RoHS standards make it suitable for consistent performance under varied temperature and humidity conditions.

Q: When is it best to utilise this switch in your designs?

A: This switch excels when compactness, quick response (less than 1 ms), and mechanical durability (100,000 cycles) are required in your product design.

Q: Where is the main domestic market for this tactile switch?

A: The primary domestic market is India, with reliable distribution channels ensuring widespread availability for project developers, distributors, and manufacturers.

Q: What is the packaging and sample delivery process for this product?

A: Loose or bulk packaging options are available, all following secure shipping standards. Samples can be requested at the asking price and are delivered promptly to your specified address.

Q: What benefits can users expect from the vertical black tactile switch?

A: Users benefit from a sturdy, highly responsive switching option that integrates seamlessly, maintains excellent contact reliability, and withstands extensive mechanical use.
