JOINT TERMINAL GOLD PLATED

About JOINT TERMINAL GOLD PLATED

• Data Transfer: Connecting peripherals such as keyboards, mice, and storage devices to computers.
• Charging: Powering and charging devices like smartphones, tablets, and other portable electronics.
• Peripheral Connectivity: Connecting devices like printers, cameras, and external hard drives.
• Audio/Video Transmission: Connecting devices like monitors and projectors with appropriate adapters.
• Power Delivery: Providing power to devices through standards like USB Power Delivery (USB PD).


Precision Gold Plating

Each JOINT TERMINAL features a meticulously applied gold layer with a thickness between 0.1 and 0.3 m. This gold surface treatment improves conductivity and resistance to oxidation, ensuring reliable long-term operation in demanding environments.


Versatile and Reliable Connections

Adaptable for both crimp or solder fittings, this terminal accepts 1.5-2.5 mm cables and integrates seamlessly into standard terminal housings. The 0.4 mm thick, flat joint lug design provides secure, low-resistance connections for a range of technical uses.


Adapted for Multiple Applications

Withstanding temperatures from -40C to +120C and certified RoHS compliance, the terminal is suitable for exports, trading, and manufacturing in India and abroad. Useful in industrial, automotive, and electronic projects, it offers dependable performance without flame retardant properties.



FAQs of JOINT TERMINAL GOLD PLATED:




Q: How should the JOINT TERMINAL GOLD PLATED be installed for optimal performance?

A: The terminal can be fitted using crimp or solder processes, depending on your application requirements. Ensure the cable diameter is between 1.5 and 2.5 mm, and that it is inserted securely into the lug before crimping or soldering to maintain consistent contact and low resistance.



Q: What is the primary benefit of the gold plating thickness on these terminals?

A: The gold plating, applied at 0.1 to 0.3 m thickness, provides enhanced electrical conductivity and corrosion resistance. This ensures stable connections with minimal oxidation, making the terminal suitable for high-reliability environments and long-term performance.



Q: When should you select these terminals for your project?

A: Choose JOINT TERMINAL GOLD PLATED when you require robust electrical connections in industrial, automotive, or electronic applications, especially where resistance to corrosion and low contact resistance are critical and RoHS compliance is needed.



Q: Where are these terminals commonly applied within electrical systems?

A: They are widely used in wiring harnesses, industrial machinery, control panels, automotive electrical setups, and electronic devices where reliable, durable, and efficient electrical connections are essential.



Q: What are the packaging options available for these joint terminals?

A: You can choose between bulk pack for large-scale installation purposes or tape & reel to facilitate automated assembly, depending on your distribution and manufacturing needs.



Q: How does the insulation resistance and contact resistance specification affect terminal usage?

A: The high insulation resistance (1000 M at 500V DC) prevents leakage currents and ensures safety, while the low contact resistance (5 m) guarantees efficient current flow, minimizing energy loss in critical applications.
