1.27MM DUAL ROW MALE PIN HEADER

Price 10 INR/ Piece

Get a Price/Quote

MOQ : 100 Pieces

1.27MM DUAL ROW MALE PIN HEADER Specification

Connector
1.27mm Dual Row Male Pin Header

Voltage Rating
250V AC/DC

Temperature
-40C to +105C

Male End Type
Straight/Right Angle Male Pins

Connector Type
Male Header

Material
Phosphor Bronze/Brass (Pins), Thermoplastic (Housing)

Application
PCB Mounting, Board-to-Board Connections, Electronic Projects

Flame Resistance Level
UL94V-0

Length
Standard lengths or custom

Color
Black (Housing), Gold/Brass (Pins)

Insulation
Thermoplastic (UL94V-0 rated)

Pitch
1.27mm (0.05 inch)

Number of Pins
Customizable/6 to 80 pins typical

Operating Humidity
0% ~ 95% RH

Insulation Resistance
1000 M min @ 500V DC

Packing
Tray, Tube, or Tape & Reel

Current Rating
1A per contact maximum

Contact Plating
Gold plated or Tin over Nickel

Dielectric Withstanding Voltage
500V AC/minute

Storage Temperature
-40C to +105C

Contact Resistance
30 m max

Number of Rows
Dual Row

Mounting Type
Through Hole

1.27MM DUAL ROW MALE PIN HEADER Trade Information

Minimum Order Quantity
100 Pieces

Sample Available
Yes

Sample Policy
Sample costs shipping and taxes has to be paid by the buyer

Main Domestic Market
All India

About 1.27MM DUAL ROW MALE PIN HEADER

Size	2 mm
Number Of Pins	70
Color	AS PER DEMAND
Circuit	YES
Material	PLASTIC
Application	BERG CONNNECTOR
brand	NO
Connector Type	YES
Contact Resistance	10020
Minimum Order Quantity	100 Piece

Computer Motherboards: Used for connecting components like hard drives, optical drives, and other peripherals.
Consumer Electronics: Found in devices such as televisions, audio equipment, and gaming consoles.
Automotive: Used in vehicle electronics for various control systems and modules.
Industrial Equipment: Employed in control panels, sensors, and other industrial automation equipment

Versatile Pin Count and Mounting Options

This connector allows for full flexibility in your PCB design, with customizable pin counts from 6 to 80 and both straight or right-angle male pin options. It is ideal for board-to-board and various electronic applications, offering easy integration into different projects and layouts.

Reliable Electrical and Mechanical Performance

Designed for stability, the 1.27mm Dual Row Male Pin Header features high insulation (1000 M min at 500V DC) and low contact resistance (max 30 m). The gold or tin over nickel plating on the pins ensures strong conductivity and long-lasting durability, even in demanding conditions.

Robust Materials and Safety Standards

Manufactured using UL94V-0 flame-retardant thermoplastic for the housing and high-quality phosphor bronze or brass for the pins, this connector guarantees safety and endurance. It operates across a wide temperature and humidity range, making it suited for diverse and challenging applications.

FAQ's of 1.27MM DUAL ROW MALE PIN HEADER:

Q: How is the 1.27mm Dual Row Male Pin Header typically used in PCB assemblies?

A: This connector provides board-to-board and wire-to-board connections in electronic circuits. It's commonly employed in projects where space is limited and reliable signal or power transmission is essential, such as development boards, embedded systems, and industrial electronics.

Q: What are the options for pin count and pin orientation in this pin header?

A: The 1.27mm Dual Row Male Pin Header offers customizable pin counts from 6 up to 80 pins, with the option for either straight or right-angle male pin configurations to suit various design needs.

Q: Where can I use this connector regarding operating conditions and environments?

A: This connector is suitable for environments ranging from -40C to +105C and can handle humidity levels up to 95% RH, making it appropriate for a broad spectrum of applications, from industrial electronics to consumer gadgets.

Q: What is the process for mounting this header onto a PCB?

A: It is designed for through-hole mounting, which involves inserting the pins into pre-drilled PCB holes and soldering them, ensuring a solid mechanical and electrical connection.

Q: What are the available contact plating options and their benefits?

A: Available with either gold plating or tin over nickel plating, these finishes enhance conductivity and resistance to corrosion. Gold plating provides superior durability, while tin over nickel is a cost-effective, reliable choice.

Q: How does the flame resistance benefit the end application?

A: The UL94V-0 flame-rated thermoplastic housing adds an extra layer of safety, minimizing fire hazards and ensuring the connector meets international safety standards for reliable operation in sensitive or high-risk environments.
