2 PIN 2.54 MM PITCH MALE FEMALE JST CONNECTOR

Send Inquiry

Request To Call Back

2 PIN 2.54 MM PITCH MALE FEMALE JST CONNECTOR

Price 4 INR/ Piece

Get a Price/Quote

MOQ : 1000 Pieces

2 PIN 2.54 MM PITCH MALE FEMALE JST CONNECTOR Specification

Pairs
1 Pair (Male + Female)

Connector Type
Wire to Wire

Capacity
2 Pins

Temperature
-25C to +85C

Male End Type
JST Male Plug

Material
Connector Housing: PA66 / Contacts: Phosphor Bronze, Tin Plated

Female End Type
JST Female Socket

Application
Battery, LED, Small Electronics, RC, DIY Projects

Connector
JST 2 Pin Male and Female

Voltage Rating
Up to 250V AC/DC

Sheild
Unshielded

Length
Customizable, typically 150mm 250mm

Color
White / Red / Black (varies)

Number of Conductor
2

Outer Diameter
Approx. 1.3 to 1.7 mm per conductor

Cable Type
Flat ribbon or discrete cable

Jacket Material
PVC

Wire Gauge
AWG 24-28

Flame Resistance Level
UL94V-0

Insulation
PVC Insulated

Cable Length
150250 mm (custom options on request)

Operating Frequency
Low Frequency (<30MHz)

RoHS Compliant
Yes

Lead Orientation
Straight

Pitch
2.54 mm

Contact Resistance
20 m

Pin Plating
Tin Plated

Packaging
Bulk polybag or custom as required

Mounting Type
Free Hanging / Cable Mount

Locking Feature
Friction Lock Snap Fit

Typical Lifespan
30 Mating Cycles

Current Rating
2A max per contact

Manufacturer Standard
JST/XH Standard

Compatibility
Works with JST-XH 2.54mm series sockets

Insulation Resistance
100 M at 500V DC

Humidity Tolerance
95% RH, non-condensing

2 PIN 2.54 MM PITCH MALE FEMALE JST CONNECTOR Trade Information

Minimum Order Quantity
1000 Pieces

Sample Available
Yes

Sample Policy
Sample costs shipping and taxes has to be paid by the buyer

Main Domestic Market
All India

About 2 PIN 2.54 MM PITCH MALE FEMALE JST CONNECTOR

Pitch	1 mm
Brand	IMPORTED
Connector Gender	MALE / FEMALE
Contact Material	PLASTIC
Maximum Operating Temperature	STANDARD
Current Rating	NORMAL
Mounting Type	PCB
Minimum Order Quantity	500 Piece

Applications:
- Used in battery connections, LED lighting, computer hardware, and hobby electronics.
- Suitable for compact and lightweight electronic devices.
Advantages:
- Reliable and secure connections with locking mechanisms to prevent disconnection.
- Compact and space-saving design.
- Easy to assemble and disassemble without special tools

Versatile Applications

This JST connector is ideal for a variety of low-frequency electronic applications such as battery packs, LED modules, small electronics, RC hobbies, and DIY projects. Its secure fit and reliable build make it a top choice among makers, engineers, and hobbyists who frequently require stable, adaptable connections.

Reliable Performance

Equipped with tin-plated contacts and PVC insulation, the connector offers exceptional contact and insulation resistance, ensuring safe performance at up to 250V AC/DC and 2A per contact. Designed for harsh conditions, it tolerates up to 95% relative humidity (non-condensing) and temperatures from -25C to +85C.

FAQs of 2 PIN 2.54 MM PITCH MALE FEMALE JST CONNECTOR:

Q: How do I properly use the 2 PIN JST connector for my electronics project?

A: To use the 2 PIN JST connector, align the male plug with the female socket, then push together until the friction lock snap fit engages. Ensure wires are of AWG 2428 and securely crimped or soldered to the terminals before mating. This process offers stable, low-resistance connections for devices like LEDs, battery packs, or RC units.

Q: What are the benefits of using a JST-XH 2.54 mm connector over other types?

A: JST-XH 2.54 mm connectors provide high reliability, compact size, and a secure friction lock mechanism. Their UL94V-0 flame resistance and RoHS compliance combine safety with eco-friendliness, while flexible cable lengths and various color options suit multiple project requirements.

Q: When should I consider customizing the cable length or color for my application?

A: Customization is recommended when you need specific wiring lengths to fit enclosures, panels, or circuit layouts, or particular color coding for identification. Custom cable lengths (150250 mm) and colors (white, red, black) can be requested to optimize installation, organization, or troubleshooting.

Q: Where is the 2 PIN JST connector typically used?

A: These connectors are commonly found in battery-powered devices, LED arrays, remote-control models, and DIY electronics kits. Their free-hanging design and strong locking mechanism make them suitable for portable or modular builds across consumer, industrial, and hobbyist sectors.

Q: What process is recommended for mounting the connector?

A: The 2 PIN JST connector is designed for free-hanging or cable mount installation. Simply terminate your wire ends (AWG 24-28) by crimping or soldering to the tin-plated contacts, then assemble the connector housing. The friction lock ensures secure mating without additional tools.

Q: Is this connector suitable for use in high-humidity environments?

A: Yes, this connector operates reliably in humidity levels up to 95% RH (non-condensing) due to its PA66 housing and robust PVC insulation. This feature ensures consistent performance in electrically demanding or physically challenging environments.

Q: What advantage does the UL94V-0 flame resistance offer?

A: UL94V-0 flame resistance indicates the connector material will self-extinguish within ten seconds after ignition, enhancing safety in electronic assemblies by reducing fire hazards associated with electrical faults or overheating.
