3.5MM SOCKET 5 PIN WITH NUT

Price 4 INR/ Piece

Get a Price/Quote

MOQ : 1000 Pieces

3.5MM SOCKET 5 PIN WITH NUT Specification

Surface Treatment
Nickel plating on contacts

Thickness
Nut thickness approx. 2mm

Sealed
Not sealed; open type

Cable Diameter
Fits cable sizes 3.5mm to 5mm

Product Type
3.5mm socket, 5 pin with nut

Material
ABS plastic and nickel plated brass

Application
Panel mount audio and signal connection

Contact Resistance
Less than 50m

Insulation Resistance
Greater than 100M at 500V DC

Diameter
Outer socket diameter 3.5mm

Terminal Socket
5-pin female

Style
Panel mount socket

Fittings
Threaded nut fitting

Rated Voltage
50V AC/DC

Weight
Approx. 4 grams

Color
Black

3.5MM SOCKET 5 PIN WITH NUT Trade Information

Minimum Order Quantity
1000 Pieces

Sample Available
Yes

Sample Policy
Sample costs shipping and taxes has to be paid by the buyer

Main Domestic Market
All India

About 3.5MM SOCKET 5 PIN WITH NUT

Color	Black
Brand	Imported
Diameter	3.5mm
Material	ABS
Usage/Application	Headphone, Mobile phone, Computer, MP3/MP4
Gender	Female
Minimum Order Quantity	1000

3.5mm Audio Jacksare the most commonly used audio output connectors which are used widely in microphones, earphones and headphones all around the world. Even though recent shift to Bluetooth or Wi-Fi audio streaming devices, 3.5mm audio jacks are still very popular due to their easy-to-use applications and almostnil latency while playingany audio file which is very necessary when you are playing an online game like PUBG, COD where real time audio is critical and having latency can mean your defeat. This3.5mm Audio Female Stereo Socket - 5 Pinis female socket in which you can connect any male 3.5mm jack connector to give audio input to your DIY project like voice recognition program and audio control projects. This has rugged plastic construction and good electrical connections characteristics. It can tap in the signals like ground, stereo left and stereo right from an audio jack and provide it out through its pins. This 3.5mm Audio Socket supports two channel audio

Reliable Audio and Signal Connections

Designed for panel mount installation, this 5-pin female socket ensures consistent signal transmission for audio and communication devices. The nut fitting and high-grade materials provide a secure connection, ideal for professional and industrial applications. Its robust construction and quality materials maintain performance in a wide range of environmental conditions.

Built for Longevity and Safety

With a minimum electrical life of 10,000 cycles and a maximum current rating of 1A per pin, this socket is engineered for frequent and prolonged use. It meets flammability standard UL94V-0 and is RoHS compliant, supporting eco-friendly and safe installation. Nickel-plated brass enhances both contact reliability and anticorrosion properties.

FAQs of 3.5MM SOCKET 5 PIN WITH NUT:

Q: How do I mount the 3.5MM Socket 5 Pin with Nut on my panel?

A: The socket is designed for simple panel mounting through an 8mm hole using the included nickel-plated brass nut. Ensure the mounting environment is clean and dry, tighten the nut to secure the socket, and connect the necessary cables to the 5-pin female terminal.

Q: What applications is this 3.5MM 5 Pin Socket suitable for?

A: This connector is ideal for audio and signal connections in a variety of equipment, including professional audio devices, communication panels, instrumentation, and other industrial or commercial settings where panel-mounted signal input/output is required.

Q: When should I use a 5-pin socket instead of a standard 3-pin or stereo socket?

A: Choose the 5-pin socket when your application requires transmission of multiple signalssuch as balanced audio, stereo channels with ground, or other control signalsin a compact panel-mount form factor.

Q: Where can this panel mount socket be sourced?

A: The 3.5MM 5 Pin Socket with Nut is available through distributors, exporters, importers, manufacturers, and traders across India. Verify RoHS compliance and quality standards with your supplier before purchasing.

Q: What is the process for connecting wires to this socket?

A: Typically, cables are terminated to the five female pin sockets from the panel rear. Ensure that the cable diameter matches the 3.55mm range and that exposed wires or terminals are insulated as per your applications safety requirements.

Q: What are the benefits of using nickel-plated contacts and brass pins in this socket?

A: Nickel-plated contacts and brass pins enhance conductivity, reduce contact resistance (less than 50m), and offer superior corrosion resistance, resulting in stable, long-term signal integrity.

Q: Is this socket protected against dust or moisture?

A: This model is rated IP20, meaning it offers basic protection against solid objects but is not sealed against dust or moisture ingress. It is intended for use in indoor, clean, and dry environments.
