DC 2.1 MM 3 PIN WITH SCREW/ CAP

Price 14 INR/ Piece

Get a Price/Quote

MOQ : 1000 Pieces

DC 2.1 MM 3 PIN WITH SCREW/ CAP Specification

Sealed
With Dust Cap

Surface Treatment
Nickel Plating

Cable Diameter
Fits up to 5.5mm cable

Thickness
Standard 10mm panel fit

Product Type
DC Power Jack

Material
ABS Body with Nickel-plated Brass Contacts

Application
Suitable for Power Supply, CCTV, DIY Electronics

Contact Resistance
50 m

Insulation Resistance
>= 100 M at 500V DC

Diameter
Outer Diameter: 10mm, Pin Diameter: 2.1mm

Terminal Socket
3 Pin Solder Type

Style
Panel Mount

Fittings
With screw and cap

Rated Voltage
DC 12V to 30V

Weight
Approx. 5 grams

Color
Black with metal contacts

DC 2.1 MM 3 PIN WITH SCREW/ CAP Trade Information

Minimum Order Quantity
1000 Pieces

Payment Terms
Cash in Advance (CID)

Sample Available
Yes

Main Domestic Market
All India

About DC 2.1 MM 3 PIN WITH SCREW/ CAP

Pin Type	Female
Telecom/Data/Network	YES
Usage/Application	Industrial
Electrical Fitting	YES
Material	PCB
Brand	NO
Minimum Order Quantity	100 Piece

Current Rating:Varies, commonly up to 5A or more depending on the model
Connector Size:Available in various sizes, commonly 2.1mm, 2.5mm, and 5.5mm inner diameter
Mounting Type:Panel mount, PCB mount, or cable mount options

Secure and Versatile Panel Mount Design

This socket is optimized for panel mounting, making it ideal for fixed installations in equipment housings. The rear nut and threaded cap provide extra stability and a dust-sealed connection, ensuring durability even in demanding environments. Suitable for CCTV, DIY projects, and commercial power supply applications.

Reliable Power Transmission and Safety

With 3 pin solder-type terminals, the socket supports stable power and signal transmission. The nickel-plated brass contacts offer low contact resistance, while high insulation resistance guarantees safety at voltages from 12V to 30V. The ABS body further adds to its robust design and electrical insulation.

FAQs of DC 2.1 MM 3 PIN WITH SCREW/ CAP:

Q: How do I install the DC 2.1 mm 3 pin socket into a panel?

A: To install, create a 10mm hole in your panel, insert the socket from the front, and secure it using the included rear nut. Solder your wires to the positive, negative, and ground screws, ensuring correct alignment, then attach the cap for dust protection.

Q: What are the main benefits of the threaded twist-on cap included with this socket?

A: The threaded twist-on cap safeguards the socket from dust, moisture, and accidental contact, maintaining a reliable connection and extending the product lifespan, especially in environments with high particulate exposure.

Q: Where is this socket commonly used?

A: This panel mount socket is widely used in power supply installations for CCTV systems, electronic DIY projects, and other low-voltage power connection applications, where secure and accessible DC input is critical.

Q: What is the current and voltage rating for this DC socket?

A: The socket supports up to 5A of current and is rated for DC voltages from 12V to 30V, providing flexibility for a broad range of low-voltage electronic devices.

Q: How can I ensure a reliable connection when soldering wires to the socket?

A: Use the 3 solder-type terminals, matching the positive, negative, and ground pins. Strip your wires, insert them into the corresponding pins, and solder securely to avoid loose connections. Avoid overheating the terminals to preserve insulation.

Q: What materials are used in the construction of this DC socket?

A: The socket features an ABS plastic body for insulation and durability, with contacts made of nickel-plated brass for enhanced conductivity and corrosion resistance. The overall build is designed for standard 10mm panels and frequent handling.

Q: Is the DC 2.1 mm 3 pin socket compliant with international safety standards?

A: Yes, this socket is RoHS compliant, ensuring it meets international standards for the restriction of hazardous substances and is safe for use in a variety of electronic assemblies.
