5 K OHM PRESET 502

Price 1.92 INR/ Piece

Get a Price/Quote

MOQ : 1000 Pieces

5 K OHM PRESET 502 Specification

Product Type
Variable Resistor - Trimmer Potentiometer

Material
Cermet (Resistive Element), Plastic (Housing)

Handles
Single slot adjustment screw

Withstand Voltage
500 V AC for 1 minute

Application
Electronic circuits, trimming and adjustment of resistance values

Insulation Resistance
1000 M minimum at 500 V DC

Height
5 mm (approx.)

Weight
1 g (approx.)

Color
Blue

Number of Turns
Single Turn

Tolerance
20%

Adjustment Type
Top

Dimensions
Length: 6.5 mm, Width: 4.8 mm (approx.)

Power Rating
0.25W (W)

Resistance Value
5 K Ohm

Operating Temperature Range
-55C to +125C

Model Number
502

Mounting Type
Through Hole (PTH)

5 K OHM PRESET 502 Trade Information

Minimum Order Quantity
1000 Pieces

Payment Terms
Paypal, Cash in Advance (CID)

Sample Available
Yes

Sample Policy
Sample costs shipping and taxes has to be paid by the buyer

Main Domestic Market
All India

About 5 K OHM PRESET 502

Resistance Values	5 K
Usage/Application	Electronic Appliances
Brand	NO
Resistance Range	5K
Material	PLASTIC
Color	WHITE / BLUE
Part Number	PT06
Minimum Order Quantity	100

Applications: Used in electronic circuits for calibration, tuning, and adjustment
Usage: Ideal for setting reference voltages, adjusting signal levels, and other precision applications
Durability: Long lifespan with reliable performance over time
Compatibility: Suitable for use in a variety of electronic devices and projects
Packaging: Available in single units or bulk packaging for larger projects

Versatile Precision for Circuit Adjustment

Designed for integration into electronic circuits, the 5 K OHM PRESET 502 offers precise resistance control with a 20% tolerance. The single-turn mechanism allows for efficient trimming, ensuring stable performance in diverse environments, thanks to its wide operating temperature range and robust construction.

Reliable and Durable Material Selection

Constructed with a high-quality cermet resistive element and durable plastic housing, this preset combines reliability with lightweight design. Its insulation resistance of 1000 M at 500 V DC ensures greater safety and longevity, making it a preferred choice for manufacturers, distributors, and exporters.

FAQ's of 5 K OHM PRESET 502:

Q: How is the 5 K OHM PRESET 502 commonly used in electronic circuits?

A: The 5 K OHM PRESET 502 is primarily used for trimming and precise adjustment of resistance values in electronic circuits. This preset allows engineers to fine-tune circuit parameters during prototyping or product calibration.

Q: What are the key benefits of using this cermet preset over standard resistors?

A: This preset offers greater precision, adjustability, and reliability, especially in applications requiring regular calibration. The cermet resistive element resists temperature fluctuations and provides improved stability compared to standard carbon film resistors.

Q: Where should the 5 K OHM PRESET 502 be mounted on a PCB?

A: It is designed for through-hole (PTH) mounting. Insert it into the designated position on the printed circuit board (PCB), typically marked for variable resistors, and solder the leads from the bottom side.

Q: When is adjustment needed for the 5 K OHM PRESET 502 in circuit operation?

A: Adjustment is usually performed during initial testing or maintenance to achieve desired resistance levels or to recalibrate the circuit due to component aging or environmental changes.

Q: How do you adjust the resistance value on this preset?

A: Use a compatible screwdriver on the single-slot adjustment screw located on the top of the preset. Turn gently to increase or decrease resistance as needed, monitoring with a multimeter if precision is required.

Q: What process should be followed to ensure safe installation and operation?

A: Always power off the circuit before installation or adjustment. Ensure correct orientation and secure soldering of all leads. Confirm electrical ratings are compatible with your application to prevent overloading.

Q: What makes this preset suitable for a wide range of industrial applications?

A: Its broad operating temperature range, robust insulation resistance, and ability to withstand high voltages make it reliable in various industrial environments, making it attractive to distributors, manufacturers, and traders across India.
