100 K OHM HORIZONTAL PRESET

Name: 100 K OHM HORIZONTAL PRESET
Brand: Madan Link Industries
Price: 1.92 INR
Availability: InStock

Price 1.92 INR/ Piece

Get a Price/Quote

MOQ : 1000 Pieces

100 K OHM HORIZONTAL PRESET Specification

Connector Type
3 Pin Through Hole

Mounting Type
PCB, Horizontal Mount

Surface Finish
Matte/Plastic Finish

Operating Temperature
-40C to +85C Celsius (oC)

Insulation Material
Ceramic, Thermoplastic

Shape
Rectangular

Feature
Adjustable, Compact Design, High Stability

IP Rating
IP20

Efficiency
High Setting Accuracy

Humidity %
Max 95% RH (Non-Condensing)

Product Type
Horizontal Preset Potentiometer

Application
PCB Mount, Electronic Circuits, Calibration

Protection Level
IP20

Frequency (MHz)
DC to 1 MHz Hertz (HZ)

Rated Voltage
Up to 50V DC Volt (V)

Output Type
Variable Resistance

Color
Blue

Dimension (L*W*H)
7 x 6 x 5 mm (Approx.) Millimeter (mm)

Weight
Approx. 1 Gram Grams (g)

Phase
Single Phase

Size
100K Ohm

Input Voltage
Up to 50V DC Volt (V)

Connection Type
Through Hole

Material
Ceramic, Plastic

No Of Poles
Single (1-Pole)

Adjustment Type
Top/Side Slot for Screwdriver

Dielectric Strength
500V AC, 1 min

Rotational Life
>100 Cycles

Maximum Power Rating
0.2 Watt (200mW)

Contact Resistance Variation
< 5% R (Initial)

Resistance Tolerance
20%

Wiper Material
Conductive Alloy

100 K OHM HORIZONTAL PRESET Trade Information

Minimum Order Quantity
1000 Pieces

Sample Available
Yes

Sample Policy
Sample costs shipping and taxes has to be paid by the buyer

Main Domestic Market
All India

About 100 K OHM HORIZONTAL PRESET

Resistance Values	100 K
Usage/Application	Electronic Appliances
Brand	NO
Resistance Range	100K
Material	METAL
Color	AS PER DEMAND
Part Number	PT11
Minimum Order Quantity	100

Optimized for high performance with large datasets.
Supports seamless horizontal alignment of data.
Configurable parameters for flexibility and customization.
Enhanced data visualization capabilities.

Versatile Applications for Precision Calibration

The 100K OHM Horizontal Preset is engineered for use in PCBs, electronic circuits, and calibration tasks. Its single-pole, variable resistance output makes it invaluable for fine-tuning signal levels, biasing active components, and configuring circuit responses. The robust construction and high stability suit professional environments requiring consistent performance. Exporters, importers, and manufacturers in India value its reliable design for diverse electronics applications.

User-Friendly Adjustment and Installation

This preset resistor features a top and side slot for screwdriver access, allowing quick and accurate resistance adjustments. The compact, rectangular shape and lightweight body simplify installation on printed circuit boards using the three-pin through-hole connection. Its IP20-rated design ensures protection against typical workplace debris, making it suitable for indoor electronics assembly and maintenance.

FAQs of 100 K OHM HORIZONTAL PRESET:

Q: How is the 100K OHM Horizontal Preset adjusted?

A: The resistance is easily set using a standard screwdriver, which fits into the top or side slot. This allows precise control over the resistance value for calibration and tuning in electronic circuits.

Q: What applications are suitable for this preset resistor?

A: It is commonly used in PCB mounting, electronic circuit adjustment, calibration purposes, and devices requiring variable resistance, such as amplifiers, timers, and sensor circuits.

Q: When should I use this preset instead of a fixed resistor?

A: A preset resistor is ideal when your design requires fine-tuning or variable resistance, such as during prototyping, calibration, or signal adjustment, unlike a fixed resistor that provides only one resistance value.

Q: Where is it typically mounted in electronic assemblies?

A: This preset is designed for horizontal mounting directly onto printed circuit boards through its three-pin through-hole connectors, suitable for a range of indoor electronic devices.

Q: What is the process for installing this component on a PCB?

A: Align the three through-hole pins with the corresponding PCB holes, insert the preset, and solder the connections securely. Once mounted, adjust the resistance as needed using a screwdriver slot.

Q: What are the main benefits of using this adjustable resistor?

A: It provides high accuracy in setting resistance values, reliable performance with over 100 adjustment cycles, and supports stable operation across a wide temperature range, ensuring long-term circuit stability.

Q: Does it include built-in overheating or protection features?

A: No, this preset does not have inbuilt overheating protection. Care should be taken not to exceed the rated power or voltage specifications during usage to prevent damage.
