3.5 MM SOCKET 5 PIN W/ONUT

Price 4 INR/ Piece

Get a Price/Quote

MOQ : 1000 Pieces

3.5 MM SOCKET 5 PIN W/ONUT Specification

Sealed
NO

Surface Treatment
Nickel Plated Contacts

Cable Diameter
Up to 5 mm

Thickness
Standard 3.5 mm

Product Type
3.5 mm Audio Socket

Material
ABS Plastic & Metal Alloy

Application
Audio Equipment, Electronic Devices

Contact Resistance
<30m

Insulation Resistance
>100M (at 500V DC)

Diameter
3.5 mm

Terminal Socket
5 Pin

Style
Straight

Fittings
Panel Mount

Rated Voltage
30V DC

Weight
Approx. 10 grams

Color
Black

3.5 MM SOCKET 5 PIN W/ONUT Trade Information

Minimum Order Quantity
1000 Pieces

Sample Available
Yes

Sample Policy
Sample costs shipping and taxes has to be paid by the buyer

Main Domestic Market
All India

About 3.5 MM SOCKET 5 PIN W/ONUT

Color	Black
Brand	Imported
Diameter	3.5mm
Material	ABS
Usage/Application	Headphone, Mobile phone, Computer, MP3/MP4
Gender	Female
Minimum Order Quantity	1000

3.5mm Audio Jacksare the most commonly used audio output connectors which are used widely in microphones, earphones and headphones all around the world. Even though recent shift to Bluetooth or Wi-Fi audio streaming devices, 3.5mm audio jacks are still very popular due to their easy-to-use applications and almostnil latency while playingany audio file which is very necessary when you are playing an online game like PUBG, COD where real time audio is critical and having latency can mean your defeat. This3.5mm Audio Female Stereo Socket - 5 Pinis female socket in which you can connect any male 3.5mm jack connector to give audio input to your DIY project like voice recognition program and audio control projects. This has rugged plastic construction and good electrical connections characteristics. It can tap in the signals like ground, stereo left and stereo right from an audio jack and provide it out through its pins. This 3.5mm Audio Socket supports two channel audio

Versatile Panel Mount Design

Designed for easy integration into various audio and electronic applications, this 3.5 mm socket features a panel mount fitting that ensures firm placement. The included fixing nut simplifies the installation process, offering reliable connectivity without the need for additional accessories. Its stylish straight profile and standard 3.5 mm thickness suit most contemporary setups.

Reliable Performance & Safety

Achieve robust performance with a rated voltage of 30V DC and a maximum current rating of 1A. The socket incorporates UL 94V-0 flammability rating and is manufactured with ABS plastic and metal alloy for added durability. High insulation resistance and nickel-plated contacts further enhance operational reliability, catering to stringent electronic safety requirements.

Quality Construction for Longevity

With contacts made from brass with nickel plating and a thermoplastic insulation shell, this socket is engineered for longevity, delivering more than 5,000 cycles of mating and unmating. The combination of premium materials ensures consistent connectivity, minimal contact resistance, and stability in varying operating temperatures from -20C to 70C.

FAQ's of 3.5 MM SOCKET 5 PIN W/ONUT:

Q: How is the 3.5 MM SOCKET 5 PIN W/ONUT installed into a panel?

A: The socket is designed for panel mounting and fits into a 6 mm cutout. Installation is simplified by the included fixing nut, which secures the socket firmly to the panel surface.

Q: What applications are suitable for this 5 pin socket?

A: This socket is ideally used in audio equipment and electronic devices, providing dependable multi-pin connections for signals or low-power circuits.

Q: When should I select this socket for my project?

A: Opt for this socket when your design requires a straight, panel-mount female connector with 5 pins, high durability, and compliance with RoHS safety standards.

Q: Where can I source this socket in India?

A: You can procure this socket from authorized distributors, exporters, importers, manufacturers, and traders across India who specialize in quality electronic components.

Q: What are the key benefits of using this socket?

A: Benefits include reliable contact via nickel-plated brass pins, robust insulation, RoHS compliance, and long-lasting performance for frequent mating/unmating cycles.

Q: How does the product ensure safety and durability?

A: Safety is ensured by high insulation resistance, a flammability rating of UL 94V-0, and the quality of ABS plastic and metal alloy materials, supporting at least 5,000 cycles.

Q: What is involved in the process of connecting cables to this socket?

A: The socket accommodates cable diameters up to 5 mm. Wires are soldered to each of the five pin terminals, providing secure electrical connections for your application.
