1.27 MM SINGLE ROW FEMALE GOLD PLATED PIN HEADER

Send Inquiry

Request To Call Back

1.27 MM SINGLE ROW FEMALE GOLD PLATED PIN HEADER

Price 10 INR/ Piece

Get a Price/Quote

MOQ : 1000 Pieces

1.27 MM SINGLE ROW FEMALE GOLD PLATED PIN HEADER Specification

Connector
Female Header

Temperature
-40°C to +105°C

Voltage Rating
250V AC/DC

Application
PCB Interconnect, Board-to-Board, Signal/Power Transmission

Connector Type
Single Row Female Header

Material
Phosphor Bronze / Brass Contacts with Thermoplastic housing

Female End Type
Socket, single row

Color
Black

Flame Resistance Level
UL94V-0

Length
Custom (as per requirement)

Insulation
High temperature thermoplastic, UL 94V-0

Row Configuration
Single Row

Contact Plating
Gold Plated

Pitch
1.27 mm

Durability
>= 300 cycles

Current Rating
1A

Contact Resistance
20 m

Insulation Resistance
1000 M at 500V DC

Packaging
Tube, Tape and Reel (as required)

Mounting Type
Through Hole or SMT

Insulator Color
Black

Number of Positions
Custom, typically 2 to 40

1.27 MM SINGLE ROW FEMALE GOLD PLATED PIN HEADER Trade Information

Minimum Order Quantity
1000 Pieces

Sample Available
Yes

Sample Policy
Sample costs shipping and taxes has to be paid by the buyer

Main Domestic Market
All India

About 1.27 MM SINGLE ROW FEMALE GOLD PLATED PIN HEADER

Size	2 mm
Number Of Pins	AS PER DEMAND
Color	BLACK
Circuit	YES
Material	PLASTIC
Application	BERG CONNECTOR
brand	NO
Connector Type	BERG STRIP
Minimum Order Quantity	100 Piece

Applications:
- Commonly used in computer hardware, such as connecting motherboard components.
- Suitable for wire-to-board and board-to-board connections.
Advantages:
- Reliable electrical connection.
- Easy to use and solder onto printed circuit boards (PCBs).
- Available in various pin counts and configurations to suit different needs.

Flexible Design for Precision Electronics

Customize your connector with up to 40 positions, tailored to the needs of advanced circuit designs. Its compact 1.27 mm pitch makes it especially suitable for space-constrained PCBs in signal and power transmission, assuring optimal alignment and electrical performance. The female socket design ensures secure mating with compatible male headers.

Superior Materials and Reliability

Constructed from gold-plated phosphor bronze or brass contacts, enclosed in a high-temperature thermoplastic housing, these headers deliver low contact resistance ( 20 m) and excellent insulation ( 1000 M at 500V DC). The robust build supports frequent operational cycles ( 300 cycles) and resists harsh environments, enhancing the longevity and stability of your electronic assemblies.

FAQs of 1.27 MM SINGLE ROW FEMALE GOLD PLATED PIN HEADER:

Q: How can I customize the number of positions for this single row female pin header?

A: The header offers a customizable number of positions, typically ranging from 2 to 40. You can specify your requirement when placing an order with the distributor, manufacturer, or trader in India. Custom lengths and configurations are accommodated to suit varied PCB layouts.

Q: What mounting options are available for these connectors?

A: This female header supports both through-hole and surface-mount technology (SMT), providing flexibility for different PCB assembly processes. Select the mounting type based on your preferred manufacturing workflow or application needs.

Q: When is it recommended to use gold-plated contacts for headers?

A: Gold-plated contacts are advisable whenever high reliability, low contact resistance, and corrosion resistance are required, especially in signal or power applications. This header is engineered to maintain performance in demanding environments and frequent mating cycles.

Q: Where is this pin header typically used?

A: These single row female headers are commonly deployed in PCB interconnects, board-to-board connections, and signal or power transmission assemblies across various electronics industries. Their socket configuration enables seamless integration in modular designs.

Q: What is the process for ordering this product with custom specifications?

A: To order, contact your preferred supplier, specifying the required number of positions, mounting type, packaging format, and length. Distributors, exporters, and manufacturers in India offer customization based on design and volume requirements.

Q: What are the main usage benefits of the headers UL 94V-0 flame-resistant housing?

A: The high-temperature thermoplastic housing rated UL 94V-0 enhances safety by reducing fire hazards and supporting compliance with industry standards. It ensures operation in elevated temperatures and improves overall durability in electronic assemblies.

Q: How does the headers durability affect its application in repeated connections?

A: With a durability rating of at least 300 mating cycles, these pin headers are suitable for applications requiring frequent plugging and unplugging, such as test interfaces, modular boards, and maintenance situations. This longevity ensures consistent electrical performance over time.
