12X12X7.5MM (4PIN) SMD BLACK TACTILE SWITCH

Send Inquiry

Request To Call Back

12X12X7.5MM (4PIN) SMD BLACK TACTILE SWITCH

Price 2 INR/ Piece

Get a Price/Quote

MOQ : 1000 Pieces

12X12X7.5MM (4PIN) SMD BLACK TACTILE SWITCH Specification

Temperature Range
-20C to +70C

Response Time
<5ms

Circuit Type
SPST-NO (Single Pole Single Throw Normally Open)

Automation Grade
Manual

Rated Voltage
12V DC

Max. Current
50mA

Number of Module
Single

Mechanical Life
100,000 cycles typ.

Finish Type
Matte

Protection Level
IP40

Product Type
Tactile Switch

Material
Plastic (Black, Actuator)/Gold-plated Contact/Silver Alloy

Insulation Resistance
>=100M at 500V DC

Contact Resistance
100m

Max. Voltage
12V DC

Operating Temperature
-20C to +70C

Stoke
0.25mm 0.1mm

Size
12 x 12 x 7.5 mm

Color
Black

Weight
Approx. 0.8g

Mounting Type
Surface Mount (SMD)

Current Rating
50mA at 12V DC

No Of Poles
Single Pole

Switch Travel
0.25mm

Termination Style
Gull Wing SMD

Storage Temperature
-30C to +80C

Contact System
Momentary

Contact Material
Silver Alloy

Dielectric Strength
250V AC for 1 min

Environmental Compliance
RoHS Compliant

Operating Force
180gf 50gf

Soldering Temperature
Max. 260C for 5 sec

Actuator Type
Standard Round Plunger

12X12X7.5MM (4PIN) SMD BLACK TACTILE SWITCH Trade Information

Minimum Order Quantity
1000 Pieces

Sample Available
Yes

Main Domestic Market
All India

About 12X12X7.5MM (4PIN) SMD BLACK TACTILE SWITCH

Discover the trending 12X12X7.5MM (4PIN) SMD BLACK TACTILE SWITCH, a remarkable component for advanced electronics. Engineered with a top-ranking standard round plunger, silver alloy contacts, and protected by an IP40 rating, this switch is pivotal for reliable circuit operations. With its quick momentary action, RoHS compliance, and unbeatable price, it stands out for both quality and value. Buy online now from Indias leading distributor, exporter, and manufacturerguaranteed to meet professional and commercial needs!

Commercial Uses and Applications

The 12X12X7.5MM (4PIN) SMD BLACK TACTILE SWITCH is widely used in commercial electronics, including industrial controls, remote controls, consumer appliances, and medical instruments. Its compact size and robust build make it ideal for applications where space-saving and durability are essential. This tactile switch is frequently selected for keypads, panel interfaces, and precise momentary operation, making it a dependable solution for manufacturers, design engineers, and commercial assemblers alike.

Sample Policy and Payment Terms

We offer a transparent sample policy on the 12X12X7.5MM SMD TACTILE SWITCH to facilitate your decision-making. Samples are available upon request with a minimal outlay, ensuring you can evaluate product quality firsthand. Quick dispatch is ensured once your sample or product order is confirmed. Flexible payment terms are available to suit your procurement needs, furthering a streamlined purchasing experience for traders and industry professionals.

FAQs of 12X12X7.5MM (4PIN) SMD BLACK TACTILE SWITCH:

Q: How is the 12X12X7.5MM (4PIN) SMD BLACK TACTILE SWITCH mounted?

A: This tactile switch features a gull wing SMD (Surface Mount Device) termination style, designed for automated surface mounting on PCB assemblies.

Q: What are the main benefits of using this tactile switch in commercial products?

A: The switch offers a compact profile, reliable momentary action, long mechanical life (100,000 cycles typical), and RoHS compliance, making it ideal for professional and high-use applications.

Q: Where can this tactile switch be applied most effectively?

A: It is most effective in keypads, consumer appliances, remote controls, medical devices, and industrial control panels requiring responsive tactile feedback.

Q: What is the standard process for ordering a sample?

A: To order a sample, simply contact our sales team or use our online platform. Upon minimal payment, a quick dispatch of your requested sample will be initiated.

Q: How does the tactile switch ensure durability under various temperature conditions?

A: It is designed for an operating temperature range of -20C to +70C and a storage range of -30C to +80C, ensuring consistent functionality in diverse environments.
