3 PIN ON-OFF BLACK KNOB WITHOUT SCREW POWER SWITCH

Send Inquiry

Request To Call Back

3 PIN ON-OFF BLACK KNOB WITHOUT SCREW POWER SWITCH

Price 15 INR/ Piece

Get a Price/Quote

MOQ : 1000 Pieces

3 PIN ON-OFF BLACK KNOB WITHOUT SCREW POWER SWITCH Specification

Response Time
Instantaneous

Number of Module
Single

Max. Current
6A

Finish Type
Matte

Circuit Type
ON-OFF

Temperature Range
-20C to +85C

Mechanical Life
10,000 cycles

Rated Voltage
250V AC

Protection Level
IP20

Automation Grade
Manual

Product Type
3 Pin ON-OFF Power Switch

Material
Polycarbonate, Copper Contacts

Insulation Resistance
100 M at 500V DC

Contact Resistance
30 m (initial)

Max. Voltage
250V AC

Operating Temperature
-20C to +85C

Stoke
Short Throw

Size
21mm x 15mm x 23mm (approx)

Color
Black

Weight
Approx 6g

Mounting Type
Panel Mount (Snap-In, Without Screw)

Current Rating
6A at 250V AC

No Of Poles
Single Pole Double Throw (SPDT)

Application
Power Control for Electronic Devices, Equipment, Power Strips

Contact Material
Silver Alloy

Switch Function
Maintained ON/OFF

Flame Retardant Grade
UL94-V0

Storage Temperature
-40C to +90C

Terminal Type
3 Solder Pins (Tab)

Actuator Type
Rocker (Black Round Knob)

Panel Cutout Size
19mm x 13mm

Dielectric Strength
1500V AC for 1 Minute

3 PIN ON-OFF BLACK KNOB WITHOUT SCREW POWER SWITCH Trade Information

Minimum Order Quantity
1000 Pieces

Main Domestic Market
All India

About 3 PIN ON-OFF BLACK KNOB WITHOUT SCREW POWER SWITCH

Material	Brass
Ideal For	POWER
Shape	Rectangle
Styles	POWER SWITCH
Product Type	SWITCH
Color	YELLOW
Finishing	GOOD
Size	STANDARD
Brand	NO
Quantity Per Pack	100
Minimum Order Quantity	100 Piece

6 PIN ON-OFF YELLOW KNOB WITHOUT SCREW.

6-pin on-off power switch featuring a distinctive yellow knob design.
Screwless installation for quick and hassle-free setup.
Provides easy on-off functionality for various electronic devices

Robust Construction and Safety

Engineered with flame-retardant polycarbonate and copper materials, the switch provides excellent mechanical durability and reliable operation. It meets UL94-V0 standards for fire safety and offers insulation resistance 100 M at 500V DC, ensuring secure handling and long-term reliability even under demanding conditions.

Efficient and Simple Installation

The panel mount, snap-in (without screw) design simplifies installation, accommodating a cutout size of 19mm x 13mm. Its compact footprint and solder pin terminals make it an excellent choice for upgrading or integrating into confined electronic panels without the need for additional hardware.

Versatile Usage Across Devices

Suited for power strips, electronic devices, and a variety of powered equipment, this switch excels in applications needing straightforward ON/OFF maintained control. With a wide operating temperature range and IP20 protection, it offers consistent performance in many indoor environments.

FAQs of 3 PIN ON-OFF BLACK KNOB WITHOUT SCREW POWER SWITCH:

Q: How do I install the 3 PIN ON-OFF BLACK KNOB POWER SWITCH without screws?

A: Installation is straightforward due to its snap-in panel mount design. Simply cut a 19mm x 13mm slot in your panel, align the switch, and firmly press it into place until it clicks and holds securelyno screws or additional mounting hardware are required.

Q: What devices or applications is this power switch suitable for?

A: This switch is ideal for electronic devices, power control panels, equipment, and particularly suited for power strips or devices that require maintained ON/OFF control. Its robust build and electrical ratings make it versatile for various professional and consumer settings.

Q: What is the benefit of the flame-retardant UL94-V0 material used in this switch?

A: UL94-V0 materials offer high resistance to flames, ensuring that the switch is safer and less likely to facilitate the spread of fire. This makes the switch suitable for environments where safety and compliance are critical.

Q: How is the switch connected electrically?

A: The switch uses three solder pin terminals in a tab configuration. You can solder wires directly to the tabs for firm, low-resistance connections to your circuit, ensuring reliable performance.

Q: What are the operating and storage temperature ranges for this switch?

A: The switch operates reliably between -20C to +85C and can be stored safely between -40C to +90C, making it suitable for various environmental conditions.

Q: What advantages does the silver alloy contact material provide?

A: Silver alloy contacts offer excellent conductivity and reduced contact resistance (30 m initially), which improves electrical efficiency and long-term durability even at higher current loads.

Q: Does this switch provide any water or dust protection?

A: With an IP20 rating, the switch offers basic protection against contact with fingers or small objects, but it is not suitable for exposure to water or excessive dust. Ideal use is in dry indoor environments.
