9.5 MM PITCH 6 PIN BARRIER TERMINAL CONNECTOR

Send Inquiry

Request To Call Back

9.5 MM PITCH 6 PIN BARRIER TERMINAL CONNECTOR

Price 15 INR/ Piece

Get a Price/Quote

MOQ : 1000 Pieces

9.5 MM PITCH 6 PIN BARRIER TERMINAL CONNECTOR Specification

Male End Type
PCB Pin

Connector
Barrier Strip

Capacity
Up to 16A per Pin

Application
Electrical Panel, PCB, Industrial Control

Female End Type
Screw Clamp

Temperature
-40C to +105C

Connector Type
Barrier Terminal Block

Voltage Rating
300V AC/DC

Material
Polycarbonate Body, Brass Contacts

Length
Panel Mount, n/a Cable

Color
Black Body

Insulation
Thermoplastic Insulation Base

Number of Conductor
6

Flame Resistance Level
UL 94V-0

Wire Gauge
Accepts 16-22 AWG

Contact Plating
Nickel Plated

Insulation Resistance
1000M

Contact Resistance
20m

Screw Size
M3 Steel

Width
62mm

Pitch
9.5mm

Torque
0.5 Nm (max, Screw)

Height
23mm

Depth
17.5mm

Mounting Type
Through Hole, Surface Screw Mount

Poles
6

9.5 MM PITCH 6 PIN BARRIER TERMINAL CONNECTOR Trade Information

Minimum Order Quantity
1000 Pieces

Sample Available
Yes

Sample Policy
Sample costs shipping and taxes has to be paid by the buyer

Main Domestic Market
All India

About 9.5 MM PITCH 6 PIN BARRIER TERMINAL CONNECTOR

Material	Brass
Usage/Application	Electronics
Size	STANDARD
Brand	IMPORTED
Packaging Size	STANDARD
Length Range	NORMAL
Number Of Holes	6
Number Of Piece	100
Minimum Order Quantity	100 Piece

Applications:
- Used in battery connections, LED lighting, computer hardware, and hobby electronics.
- Suitable for compact and lightweight electronic devices.
Advantages:
- Reliable and secure connections with locking mechanisms to prevent disconnection.
- Compact and space-saving design.
- Easy to assemble and disassemble without special tools.

Durable Construction for Industrial Use

Built with a thermoplastic insulation base and a tough polycarbonate housing, this terminal block provides exceptional flame resistance (UL 94V-0) and operates reliably in temperatures from -40C to +105C. Nickel-plated brass contacts ensure long-lasting electrical performance even in challenging conditions.

Easy and Secure Mounting Options

Designed with both through-hole and surface screw mounting options, the 9.5mm pitch barrier terminal connector easily integrates into electrical panels and PCBs. The screw clamp system, complete with M3 steel screws, simplifies the process of securing wires for robust and stable connections.

FAQ's of 9.5 MM PITCH 6 PIN BARRIER TERMINAL CONNECTOR:

Q: How do I mount the 9.5 MM Pitch 6 Pin Barrier Terminal Connector onto my panel or PCB?

A: This terminal connector supports both through-hole mounting for PCBs and screw mounting for panels. Position the connector onto your panel or circuit board, align the mounting holes, and secure with appropriate screws for panel mount, or solder the pins for PCB use.

Q: What wire sizes are compatible with this terminal connector?

A: The connector accepts wire gauges ranging from 16 to 22 AWG, making it versatile for various wiring applications in industrial control and electrical panels.

Q: When should I use this barrier terminal block in my projects?

A: You should use this terminal block when you need a reliable, high-current (up to 16A per pin), and secure wire connection solution for electrical panels, PCBs, or industrial control equipment, particularly where safety and durability are priorities.

Q: Where can I purchase or source this specific connector?

A: The 9.5 MM Pitch 6 Pin Barrier Terminal Connector is available through exporters, distributors, importers, manufacturers, and traders, especially within India's industrial supply chain networks.

Q: What safety benefits does the connector offer?

A: With its flame-resistant UL 94V-0 polycarbonate housing, nickel-plated brass contacts, and high insulation resistance (1000M), the connector reduces fire risk and provides enhanced electrical safety for demanding applications.

Q: How does the screw clamp system benefit installation and maintenance?

A: The screw clamp system with M3 steel screws enables fast, secure, and tool-friendly wire attachment and removal, allowing for easy maintenance, reconfiguration, or wiring updates without specialized skills.
