2 PIN 2.54 MM MALE FEMALE JST CONNECTOR

Price 4 INR/ Pair

Get a Price/Quote

MOQ : 1000 Pairs

2 PIN 2.54 MM MALE FEMALE JST CONNECTOR Specification

Temperature
-25°C to +85°C

Application
Battery connections, PCB interface, electronics projects, RC gadgets

Connector
JST Connector

Capacity
Up to 3A

Female End Type
JST Receptacle

Connector Type
2 Pin JST Male/Female

Voltage Rating
Up to 250V AC/DC

Pairs
1 Pair (Male & Female)

Male End Type
JST Plug

Material
High-quality plastic housing, copper conductors

Jacket Material
PVC

Insulation
PVC

Cable Type
Flexible, Flat Cable

Flame Resistance Level
UL94V-0

Length
Typically 150mm (varies per supplier)

Outer Diameter
Approx. 1.2 mm (each wire)

Sheild
Unshielded

Number of Conductor
2

Wire Gauge
28 AWG

Color
Red and Black

Cable Length
150 mm (standard)

Pitch
2.54 mm

Insertion/Extraction Force
10-50N

RoHS Compliance
Yes

Insulation Resistance
>=1000 M @ 500V DC

Mounting Type
Cable Mount

Package Contents
1 x Male Connector, 1 x Female Connector with pre-crimped wires

Durability
1,500 mating cycles

Suitable Wire Size
AWG 22-28

Contact Resistance
20 m

2 PIN 2.54 MM MALE FEMALE JST CONNECTOR Trade Information

Minimum Order Quantity
1000 Pairs

Sample Available
Yes

Sample Policy
Sample costs shipping and taxes has to be paid by the buyer

Main Domestic Market
All India

About 2 PIN 2.54 MM MALE FEMALE JST CONNECTOR

Telecom/Data/Network	HOUSING /AND TERMINAL RELIMATE CONNECTOR
Brand	IMPORTED
Connector Gender	MALE FEMALE
Contact Material	PLASTIC
Maximum Operating Temperature	AS PER USE
Mounting Type	PCB
Minimum Order Quantity	200 Piece

The Molex KF2510 series connector range is suitable for a range of wire-to-board connecting applications. The series consists of PCB headers, receptacle housings and contacts termina

Robust and Versatile JST Connections

Designed for seamless electrical connections, this connector set offers strong durability and convenience. The package includes one pair (male and female) with pre-crimped 28 AWG PVC wires, making them ready for quick installation. Their 2.54 mm pitch and flat cable design suit a broad range of electronics and DIY projects, ensuring both efficiency and reliability for hobbyists and professionals alike.

High Electrical Performance and Safety

With a low contact resistance of 20 m and high insulation resistance of 1000 M at 500V DC, this JST connector assures stable, secure connections. Compliant with RoHS and flame resistance rated UL94V-0, it is engineered for both performance and safety across different applications. The robust materials withstand up to 1,500 mating cycles, offering long service life and consistent quality.

FAQs of 2 PIN 2.54 MM MALE FEMALE JST CONNECTOR:

Q: How do I connect the 2 PIN 2.54 MM JST connectors to my circuit?

A: Simply insert the pre-crimped wire ends from the included male and female connectors into your circuit points, observing proper polarity (red for positive, black for negative). Ensure the connectors are securely mated for reliable contact.

Q: What applications are these JST connectors best suited for?

A: These connectors are ideal for battery connections, PCB interfaces, robotics, RC gadgets, and general electronics projects due to their compact design, reliable performance, and high current/voltage capacity.

Q: When should I consider using this connector over others?

A: Choose this connector when you require a compact, reliable connection with up to 3A current and 250V AC/DC rating, especially where ease of cable mounting and repeatable mating cycles (up to 1,500) are important.

Q: Where can I purchase these JST connectors and are they available in India?

A: These connectors are available from distributors, exporters, importers, manufacturers, and traders across India and through various electronics component suppliers online.

Q: What wire sizes and types are compatible with these JST connectors?

A: This connector supports wire sizes from AWG 22 to 28, though it typically comes with pre-crimped 28 AWG flexible, flat PVC-insulated wires for ease of installation.

Q: How durable are these connectors during repeated use?

A: They are rated for at least 1,500 mating cycles, ensuring long-lasting durability for projects requiring frequent connection and disconnection.

Q: What are the key benefits of using this JST connector set?

A: Benefits include quick installation, robust electrical and flame resistance, RoHS compliance, and suitability for a wide range of electronics applications, all in a compact and user-friendly cable-mount form factor.
