MAGNET CONNECTOR

Price 88 INR/ Piece

Get a Price/Quote

MOQ : 1000 Pieces

MAGNET CONNECTOR Specification

Application
Power and Data Transfer

Material
ABS, Copper

Temperature
-40C to +85C

Connector Type
Circular Magnetic

Capacity
3A Max

Pairs
2 Pairs

Connector
Magnet Connector, Gold-plated Contacts

Female End Type
Socket

Male End Type
Pin

Voltage Rating
300V

Outer Diameter
5 mm

Flame Resistance Level
UL 94V-0

Color
Black

Insulation
PVC

Wire Gauge
24 AWG

Jacket Material
PVC

Sheild
Yes

Length
1 Meter

Number of Conductor
4

Cable Type
Multi-core Cable

Cable Length
1 Meter

Magnet Force
2N

Waterproof Rating
IP67

Mounting Type
Panel Mount / Cable Mount

Mating Cycles
5000 Cycles

Storage Temperature
-55C to +125C

Insulation Resistance
100 M

Operating Humidity
10% ~ 90% RH

Contact Resistance
20 m

MAGNET CONNECTOR Trade Information

Minimum Order Quantity
1000 Pieces

Sample Available
Yes

Sample Policy
Sample costs shipping and taxes has to be paid by the buyer

Main Domestic Market
All India

About MAGNET CONNECTOR

Wattage	9W
Lighting Color	STEEL
Shape	Round
Light Bulb Types	Metal Halide
Material	Copper
Model Name/Number	MOTOR
Base Type	STANDARD
Usage/Application	TOYS
Body Material	Aluminium
IP Rating	IP40
Dimensions	STANDARD
Warranty	NO
Color Temperature	COOL
Input Voltage	NORMAL
Luminous Flux	AS PER PHOTO
Operating Temperature	STANDARD
Pieces Per Unit	PICES
Minimum Order Quantity	200 Piece

Magnetic connectors arean electrical connection method that relies on a magnetic force to both make and maintain a connection. The two parts, both the plug and the socket have corresponding magnets or magnetic faces that enable a self-aligning connection to be made allowing the connectors pins to mate.

Reliable Magnetic Connectivity

This connector uses strong magnetic force (2N) and gold-plated contacts to provide secure and stable connections for power and data. Designed for panel or cable mounting, it supports up to 5000 mating cycles, making it highly reliable for frequent connection and disconnection.

Enhanced Durability and Safety

Constructed from ABS and copper, the MAGNET CONNECTOR is flame resistant (UL 94V-0) and has a robust waterproof rating of IP67. Its wide operating temperature and humidity ranges suit it well for both indoor and outdoor applications, offering dependable performance in demanding environments.

Versatile Design for Diverse Applications

With a shielded 4-conductor, 2-pair cable and a 1-meter length, this connector is suitable for various data and power transfer situations. The panel and cable mount options provide flexibility for system integration, while black PVC insulation adds protection and a sleek finish.

FAQs of MAGNET CONNECTOR:

Q: How do I install the MAGNET CONNECTOR in my system?

A: You can install the MAGNET CONNECTOR using either panel mount or cable mount configurations. Ensure correct wiring of the 4-conductor (2-pair) cable, and secure the connector firmly to maintain the waterproof seal and optimal magnetic connection.

Q: What environments is the MAGNET CONNECTOR suitable for?

A: The connector boasts an IP67 waterproof rating and is constructed with flame-resistant materials, making it ideal for outdoor, industrial, and moisture-prone environments. It operates reliably in temperatures from -40C to +85C and humidity levels between 10% and 90% RH.

Q: When should I consider using a magnetic connector over traditional options?

A: Magnetic connectors offer quick, secure connections, reduce wear from repetitive mating cycles ( 5000 cycles), and are easier to use in tight or hard-to-reach spaces, making them preferable for applications requiring frequent connect/disconnect cycles or enhanced safety.

Q: Where can this connector be used for power and data transfer?

A: The MAGNET CONNECTOR can be integrated into a variety of electrical systems including machinery, industrial equipment, outdoor devices, and electronics, supporting both low-power (3A max) and high-integrity data transmission needs.

Q: What are the key benefits of the 4-conductor, shielded, multi-core cable?

A: The 4-conductor, shielded, PVC-insulated multi-core cable minimizes interference, ensures consistent signal transmission, and allows simultaneous power and data transfer across two pairs, providing enhanced functionality and reliability.

Q: How does the waterproof and flame-resistant design enhance safety?

A: With an IP67 waterproof rating and flame resistance up to UL 94V-0, the MAGNET CONNECTOR delivers protection against dust, water ingress, and fire hazards, ensuring the safety and longevity of your electrical connections even in challenging conditions.
