2+1+1+1+ TORCH SWITCH

Price 3.0 INR/ Piece

Get a Price/Quote

MOQ : 10000 Pieces

2+1+1+1+ TORCH SWITCH Specification

Circuit Type
SPST/DPST (configurable)

Response Time
<10 ms

Mechanical Life
>10,000 Cycles

Protection Level
IP20

Rated Voltage
250V

Number of Module
Single Module

Finish Type
Matte

Max. Current
10A

Automation Grade
Manual

Temperature Range
-10C to 55C

Product Type
2+1+1+ Torch Switch

Material
High Grade Plastic Body, Copper Contacts

Insulation Resistance
100 M at 500VDC

Contact Resistance
50 m

Max. Voltage
250V AC/DC

Operating Temperature
-10C to 55C

Stoke
Short Travel Action

Size
Compact (approx. 60mm x 32mm)

Color
Black & Orange

Weight
Approx. 30g

Mounting Type
Panel Mount

Current Rating
10A at 250V

No Of Poles
4

Standards Compliance
CE Certified

Storage Temperature
-30C to +70C

Contact Material
Copper Alloy

Terminal Type
Screw Terminals

Operating Force
2N

Switch Actuator Style
Push Button

Switch Function
ON/OFF

Humidity Tolerance
95% RH non-condensing

Switch Configuration
2+1+1+1

Dielectric Strength
1500V AC for 1 min

Environmental Resistance
Dust Resistant

2+1+1+1+ TORCH SWITCH Trade Information

Minimum Order Quantity
10000 Pieces

Sample Available
Yes

Main Domestic Market
All India

About 2+1+1+1+ TORCH SWITCH

Material/Body	Plastic
Switch Type	Push
Number Of Switch Positions	2
Usage/Application	Industrial
Model Name/Number	MLISLN14
Color	Black
Minimum Order Quantity	1000

Pins:4
Color(s):Black
Functioning:push to on/off
Used with:Toys, Torch Lights

Panel-Mount Versatility and Durability

This TORCH SWITCH offers a versatile solution for industrial panels or torch assemblies. Its IP20-rated body provides basic dust resistance, while the high-grade plastic encasing and copper alloy contacts guarantee extended lifespan and stability, even in high-frequency use. Its push button actuator style ensures easy, error-free toggling.

Reliable Operation in Challenging Conditions

Engineered to perform in challenging environments, the switch tolerates extremes of storage and operation temperatures (from -30C up to +70C in storage, and -10C to 55C in operation) and handles humidity up to 95% RH (non-condensing). This makes it well-suited for a range of climates often encountered in industrial and commercial locations.

Certified Quality and Safety

CE certification reassures users of compliance with international quality and safety standards. Enhanced insulation resistance and dielectric strength contribute to secure, stable performance, making this switch a safe choice for high-reliability operations in electrical circuits up to 250V AC/DC.

FAQs of 2+1+1+1+ TORCH SWITCH:

Q: How is the 2+1+1+1 TORCH SWITCH installed?

A: The switch is designed for panel mounting and features screw type terminals, making installation straightforward. Simply mount the switch through a compatible panel cutout and secure it with the provided screws. Connect the electrical wires to the designated screw terminals, ensuring tight and proper connections for reliable performance.

Q: What are the primary applications of this TORCH SWITCH?

A: This switch is commonly used in industrial control panels, torch assemblies, and various electrical devices needing an ON/OFF push button operation. Its robust construction and dust resistance make it suitable for both commercial and industrial environments.

Q: When should I choose this push button switch over toggle or rocker switches?

A: Opt for this push button switch when you require rapid response (<10 ms), compact design, and easy integration into control panels. Its short travel action and low operating force (2N) are ideal for repetitive use and environments where quick toggling is essential.

Q: Where is this TORCH SWITCH manufactured and distributed?

A: Manufactured in India, the switch is available through various distributors, exporters, importers, manufacturers, and traders across the country. This ensures wide availability and support for both domestic and international customers.

Q: What is the benefit of copper alloy contacts in the switch?

A: Copper alloy contacts offer excellent electrical conductivity, low contact resistance (50 m), and greater durability. This ensures efficient power transmission and reduces the likelihood of heat generation or contact wear during frequent switching.

Q: How does the TORCH SWITCH ensure user safety?

A: With CE certification, high dielectric strength (1500V AC for 1 min), and insulation resistance (100 M at 500VDC), the switch is designed to prevent electrical leakage and provide secure, safe operation for users, even under demanding conditions.

Q: What is the process for configuring the switch circuit type (SPST/DPST)?

A: The switchs internal terminals can be wired according to your desired configurationeither as SPST (Single Pole Single Throw) or DPST (Double Pole Single Throw). Refer to the wiring diagram provided with the product to select and connect the relevant terminals during installation.
