OVER LOAD SWITCH

Price 4 INR/ Piece

Get a Price/Quote

MOQ : 1000 Pieces

OVER LOAD SWITCH Specification

Mechanical Life
>10,000 operations

Rated Voltage
415V AC

Finish Type
Matte

Automation Grade
Manual

Response Time
<0.5 sec

Circuit Type
Three Phase

Protection Level
IP20

Max. Current
32A

Temperature Range
-10C to +60C

Number of Module
1

Product Type
Over Load Switch

Material
High-grade Polycarbonate & Copper

Insulation Resistance
>100 M at 500V DC

Contact Resistance
50 m

Max. Voltage
690V AC

Operating Temperature
-10C to +60C

Stoke
Standard Stroke Mechanism

Size
75mm x 45mm x 65mm

Color
Black

Weight
210g

Mounting Type
DIN Rail

Current Rating
0.1A to 32A

No Of Poles
3

Trip Class
Class 10

Reset Type
Manual & Automatic

Application
Motor Protection

Frequency
50/60 Hz

Terminal Type
Screw Type

Dielectric Strength
>2000V AC for 1 min

Ambient Humidity
90% RH

OVER LOAD SWITCH Trade Information

Minimum Order Quantity
1000 Pieces

Payment Terms
Paypal

Sample Available
Yes

Sample Policy
Sample costs shipping and taxes has to be paid by the buyer

Main Domestic Market
All India

About OVER LOAD SWITCH

Take advantage of the sought-after OVER LOAD SWITCH, designed to deliver radiant motor protection for industrial applications. Spotlighting a robust build, it operates triumphantly across a wide temperature range (-10C to +60C) and accommodates ambient humidity up to 90% RH. Crafted from high-grade polycarbonate and copper, its matte finish and screw terminals assure durability and easy installation. Featuring both manual and automatic reset, quick trip response (<0.5 sec), and reliable dielectric and insulation strengths, this three-phase switch (Class 10) is ideal for new or replacement installations. Its triumphant performance is appreciated by distributors, exporters, importers, manufacturers, traders, and end-users throughout India.

Application & Features of the Over Load Switch

The OVER LOAD SWITCH is engineered for motor protection on three-phase circuits, making it suitable for factories, processing plants, and commercial installations. Its surface is processed with a matte finish for increased durability. Other features include an IP20 protection level, DIN rail mounting, and compatibility with voltages up to 690V AC. With standard stroke mechanism operation, manual or automatic resets, and robust mechanical life, this switch ensures safe operation in demanding environments.

Sample Policy & Domestic Supply Information

Our OVER LOAD SWITCH sample policy ensures quick dispatch of evaluation units, allowing you to perform accurate valuation before bulk procurement. Samples are available and can be supplied across India's main domestic markets. Distributors, exporters, importers, manufacturers, and traders can easily request samples for review. Dependable supply logistics and transparent sample handling help streamline your selection process and accelerate your decision-making for project and industrial uses.

FAQ's of OVER LOAD SWITCH:

Q: How does the OVER LOAD SWITCH protect motors in three-phase circuits?

A: The OVER LOAD SWITCH monitors motor current and disconnects the circuit during overloads, preventing damage to motors by quickly responding in less than 0.5 seconds to excessive current conditions.

Q: What are the operating conditions for the OVER LOAD SWITCH?

A: This switch operates effectively in temperatures from -10C to +60C, ambient humidity up to 90% RH, and with dielectric strength surpassing 2000V AC for 1 minute, ensuring consistent performance in varied environments.

Q: When should I consider installing a Class 10 overload switch?

A: Class 10 overload switches should be installed when precise motor protection is required in industrial or commercial settings, especially for frequent startup or variable load applications.

Q: Where can the OVER LOAD SWITCH be mounted?

A: It can be mounted on standard DIN rails, making it compatible with most industrial electrical panel systems, streamlining installation and maintenance.

Q: What is the process to obtain a sample for evaluation?

A: You can request a sample as per our sample policy, which offers quick dispatch and supply within major domestic markets. Contact your distributor or company representative for details.
